On January 19, the evaluation results of Model No. 29 of China New Car Evaluation Regulation (C-NCAP) were announced, and the scoring rate of Lantu FREE occupant protection sub-item was 94.39%, the scoring rate of pedestrian protection sub-item was 75.09%, and the score rate of active safety sub-item was 100%, with a comprehensive score rate of 92.3%, it won the "five-star" evaluation of C-NCAP test, and ranked first in the comprehensive score of new energy models of Chinese brands.
On January 5, 2022, in response to the needs of users, Lantu applied to the China Automobile Center to allow users to witness the whole process of Lantu FREE participating in the C-NCAP crash test, which comprehensively demonstrated the technological innovation and excellent quality of Lantu Automobile in the field of safety. As one of the most authoritative and open automotive safety evaluation standards, C-NCAP and Euro NCAP in Europe and IIHS in the United States are the most complete and stringent in the world.
Occupant protection score rate of 94.39% Lantu FREE defines a five-star safety standard
In the part of occupant protection that users value most, Lantu FREE scored 94.39%. Among them, the complete frontal collision test score was 18.675 (out of 20 points), the frontal 40% bias crash test score was 17.854 (out of 20 points), the side collision test scored 20 points, and the whipping test score was 4.541 (out of 5 points). After the complete frontal crash test and the front 40% bias crash test, the Lantu FREE double flash is automatically opened, the front airbag of the main and co-pilot is smoothly ejected, and the dummy is in full contact with the airbag, the A column is almost invisible, the crew compartment has no obvious intrusion deformation, and the door can be opened normally. This stems from the cage cockpit skeleton super strong body structure adopted by Lantu FREE, the vehicle's high-strength steel accounts for 75%, of which the thermoformed steel proportion is 31%, and the A-pillar adopts the world's first TRP+Patch composite structure thermoforming process, the strength is as high as 1500MPa, which can achieve five-star safety protection for the occupants of the car.
After the side impact test, the entire side body structure of the Landu FREE was fully absorbed and deformed, the living space of the occupants in the car was not significantly invaded, the seat side airbags and head air curtains were smoothly unfolded in time, and enough protective areas avoided direct contact between the head and the window glass and interior parts. At the same time, the B-pillar of the TRB thermoforming process used by Lantu FREE and the door anti-collision beam of 2000MPa aluminum-silicon coating material used for the first time in the global model effectively improve the stiffness and strength of the vehicle. The upper end of the B-pillar of Lantu FREE is invisible, and the matching design of the lower end of the B-pillar and the anti-collision beam of the door makes the collision energy reasonably absorbed and dispersed, effectively ensuring the living space of the passengers in the car.
In the whipping test, Landu FREE scored 4.541 out of 5. This is thanks to the Landu FREE ergonomic seat and headrest, which can provide good comfort and support, reduce the head swing backwards caused by inertia, prevent cervical spine overflexion and extension injuries, and bring better protection for passengers in the back bump. In the evaluation of the bonus points, because the front and rear rows of all lantu FREE models are equipped with seat belts without wearing reminder functions and side head air curtains, all the assessment requirements of the extra points are met, and all the scores of the bonus points are obtained.
It is worth mentioning that after all the crash tests, the battery pack located under the chassis of Landu FREE did not find leakage, and the battery of the whole vehicle did not smoke, fire or explode. This is due to the high-strength body-in-white body and vehicle structure of Landu FREE that provides good protection for the battery, and the native intelligent electric architecture of ESSA independently developed by Lando, which lays the battery flat in the center of the vehicle to avoid collisions as much as possible, thereby reducing the damage to the three-electric system.
Front cabin structural space optimization Pedestrian protection score rate 75.09%
The pedestrian protection test is done by simulating the degree of injury to the pedestrian after a vehicle collides with a pedestrian, including a head crash test and a leg crash test. Lantu fully considers the safety of pedestrians after the collision, and provides a full range of safety for pedestrians through the optimization of space and structure from the styling design to the front cabin layout. After testing, Lantu FREE has a good effect on the protection of the head and legs of pedestrians outside the car, with a score of 11.263 points (out of 15 points), with a scoring rate of 75.09%.
The design of the FRONT BUMPER fully considers the protection of the human leg, increases the contact area between the front bumper and the leg, and can disperse and reduce leg injury. In addition, the integrated assembly design of the front bumper and headlights is more likely to deform in collisions, and is also conducive to protecting pedestrian thighs and pelvic bones. The energy absorption design of the LAND FREE hood and the ample variable space in the lower part provide maximum protection for children's and adults' heads. The use of industry-advanced two-color injection molding process ventilation cover and collapsible wiper design, can also greatly reduce the head injury of cyclists.
Active security configuration pulls full Active security test scoring rate 100%
The entire series of Landu FREE is equipped with an L2-level intelligent driver assistance system, and the whole vehicle is equipped with 24 intelligent sensors, which can realize 20 intelligent driving assistance functions, whether from driving safety warning to active intervention, it can assist safe driving. In the active safety test, Landu FREE scored a full score of 15 points, with a scoring rate of 100%.
In the automatic braking capability (AEB-CCR) test and vehicle-to-pedestrian automatic braking capability (AEB-VRU-PED) test, Lantu Automatic Emergency Braking System (AEB-P) performed well, with the mature millimeter wave radar and camera fusion program, real-time monitoring and early warning of pedestrians, vehicle collision risk, emergency braking accurate intervention, the implementation of active multi-layer three-dimensional protection. In the stability (ESC) test of the vehicle in an emergency, Landu FREE also received full marks, and the industry-leading Bosch iBooster 2.0 braking system and ESP 9.3Hev body stabilization system made land-to-life FREE's AEB braking performance better, ensuring the stability and calmness of the vehicle during intense operation.
The ultimate strict quality verification of the whole scene to create the "most secure high-end electric SUV"
In order to create the "most secure high-end electric SUV", Landu takes the most stringent C-NCAP five-star and the IIHS G evaluation standard of the American Highway Safety Insurance Association as the design standard to create a safe and zero anxiety product in an all-round way. In the past year or so, Lantu has done many rigorous tests on driving safety in various harsh scenarios and road conditions such as high temperature and extreme cold, as well as body safety and battery safety, etc., to achieve zero anxiety about the safety of electric vehicles.
In R&D testing, production and manufacturing, Landu passed the extreme environmental tests of more than 3 million kilometers, 1,000 road conditions, minus 40 °C, high temperature 50 °C, etc., and the battery system has undergone 80 major items and 150 small items of rigorous verification tests. In the battery system crowd test challenge conducted by the China Automobile Center in September last year, the two battery systems of Lantu were "not water, no smoke, no fire, and no explosion". Landu FREE also successfully challenged the world's first electric vehicle after wading bottom crash test, showing the hard core strength of "no insulation alarm, no water ingress, no smoke, no fire, no explosion".
With the continuous advancement of safety technology, Lantu has 35 body patents and more than 60 battery patents, and the safety quality has been widely recognized by the industry. Landu FREE won the Special Medal of Honor of the 2020 China Body Conference and won the two awards of "China's Top Ten Body Bodies" and "Best Craftsmanship Award" at the 2021 China Body Conference. As a "new strength of China's car manufacturing", Lantu will continue to innovate and explore in the field of safety, providing users with a full range of five-star protection from the aspects of vehicle safety such as body safety, battery safety, cockpit safety and safety assistance, and creating a high-end electric travel experience with zero safety and zero anxiety.
