I believe that everyone has heard of the "black box", which is the common name of the aircraft flight data recorder (FDR), which can provide evidence to investigators and help them understand the truth of the accident.
Nowadays, the popularity of automobiles is getting higher and higher, various types of automobile accidents are emerging in an endless stream, and the safety of automobiles has received widespread attention. The "black box" that originated in the aviation field is also gradually being applied to the automotive field and will become an essential component.
National policy introduced: new cars will be mandatory to install EDR
A few days ago, GB 7258--2017 "Motor Vehicle Operation Safety Technical Conditions" National Standard No. 2 amendment order was released, starting from January 1, 2022, newly produced passenger cars are required to be equipped with EDR (that is, Event Data Recorder, automotive event data recording system).
With the introduction of national policies, it has become inevitable that cars will be equipped with EDR in the future.
Automotive EDR collection information diagram
China's EDR standard (C-EDR) has also been determined at the end of November 2019, and is divided into two stages: A and B.
The first phase will be implemented in 2021, requiring newly applied models to be able to record and read Class A data elements, and the second phase will be implemented from 2023, requiring newly applied models to record and read Class A B data elements.
Trigger conditions, basic reference to American standard.
EDR – the real "black box" on the car
Someone asked, I have installed a driving recorder (DVR), is it still necessary to install EDR?
Now many car owners will spontaneously install a driving recorder on their cars in preparation for restoring the truth of the accident, which is commendable. However, the dashcam can only record simple GPS and video data, and does not record the key data of vehicle operation at the time of the accident (vehicle speed, steering angle of the steering wheel, airbag status, vehicle braking status, etc.).
Driving recorder monitoring screen of a traffic accident
EDR can record the vehicle's operation key data (such as vehicle speed, vehicle collision acceleration, steering wheel steering angle, engine operation status, airbag status, driver assistance system, driver's reaction action when the event occurs, and other important information) in the three stages of the vehicle before, during and after the collision.
Workflow diagram of automotive EDR
It should be mentioned here that the trigger condition for the Event of EDR is a drastic change in the speed of the vehicle laterally or vertically. The reference American standard threshold is a change of 8KM/h within 125ms. However, the trigger does not mean that there must be a collision or accident, and the EDR standard also has a locking standard, once locked, the record data cannot be changed. China EDR standard locking conditions: irreversible restraint device (generally refers to any air bag) unfolded; the speed change of the vehicle in the X axis direction in the 150ms time interval is not less than 25km/h.
Installing EDR can play an important role in curbing serious traffic violations, as well as restraining drivers' bad driving behavior, preventing road traffic accidents, ensuring the safety of vehicles, and providing raw data for accident analysis and identification.
EDR faces the cost problem
For car companies, after the mandatory installation of EDR, it can greatly reduce the negative public opinion impact caused by unclear responsibilities after the accident; for consumers, after having EDR, there will be no unreasonable phenomenon after encountering an accident. But with the large-scale installation of EDR, there is also a question: who will bear this cost?
Regarding the cost of EDR, Tesla previously launched the EDR data extraction kit on the official websites of the United States and Canada, which was priced at $1200 (about 7768 yuan). After the "brake failure" incident, Tesla launched the event data logger EDR query software on its official website in the United States, and this service is currently only available in North America, and domestic Tesla users cannot use it temporarily.
For such a nearly 8,000 yuan of equipment, its high cost is obviously a great burden for car companies, consumers are more sensitive to price, if the price of new cars is greatly increased, it may lead to sluggish sales, but internal digestion, which is not to make money for their own car companies.
Although from the perspective of the entire environment, the state's mandatory installation of car "black boxes" is a very positive thing, if there is no corresponding subsidy to car companies, will the implementation of car companies be greatly reduced? If enforcement is not in place, is there a corresponding penalty? These are all questions worth thinking about in the relevant departments.
In fact, the mandatory installation of the car "black box" in one step is indeed gratifying. You know, in the past few years, many domestic car companies have not been active in the mandatory installation of related safety equipment, just like these years have been advocating mandatory installation of tire pressure monitoring and ESP is currently only waiting for the mandatory installation of tire pressure monitoring, the most important ESP currently has no more news.
The importance of ESP needless to say, whether it is the official media or all kinds of self-media and car companies have publicized its importance, although the state has also been advocating, but the current ESP has not been widely popularized, in some cheap cars or beggar versions of the model, ESP is still a relatively rare equipment.
Compared with the price of nearly 8,000 yuan for the "black box" of the car, the ESP between 2,000 yuan and 5,000 yuan has not been fully popularized, and the mandatory installation of the "black box" of the car may also face great difficulties.
Write at the end
It can be said that the advantages and disadvantages of the "black box" are very obvious, and the cost will be the biggest obstacle to its implementation. Some people believe that this car "black box" is likely to be a transitional product, especially with the deepening of the development of smart cars, everything is data, the data in the record is uploaded to the cloud, and the importance of the car "black box" will be greatly reduced. For relevant departments, after the introduction of the compulsory installation policy of the "black box" of the car, balancing the interests of all parties will be the most important problem to be solved next. I hope that this good policy can be truly implemented, and it will not just become a blank piece of paper.
