A few days ago, we saw the motherboard design corresponding to the AMD Zen4 architecture Xiaolong 7004 processor, and we can see the huge SP5 LGA6096 socket and 12 DDR5 memory slots. Today, we saw for the first time the internal design of the Zen4 Dragon processor, confirming previous speculations.
The picture comes from the promotional photo of the Packaging Factory of Fortis Chaowei (TF-AMD) in Penang, Malaysia, which is the AMD packaging and testing factory acquired by Fortis Microelectronics, the authenticity is not a problem, but the probability should be a model.
It can be seen that the Zen4 Xiaolong processor is still a chiplet chip design inside, integrating as many as 13 chips, including 12 CCDs and 1 IOD, the former is a group of 3 every 3, around the IOD.
Zen4 CCD is also a set of CCX per ccx, 8 CPU cores, that is, a total of up to 96 cores and 192 threads.
Compare The Zen3 8+1
Due to the new 5nm process and the new Zen4 architecture, the area of the CCD has been reduced from 80 square millimeters to 72 square millimeters, the IOD has also been reduced from 416 square millimeters to about 397 square millimeters, and the socket socket has expanded from LGA4094 by about 37% to LGA6096, so it is not a problem to accommodate so many small chips, but the arrangement is also more dense.
In addition, Zen4 Xiaolong will also support 12 channels of DDR5 memory, a maximum capacity of 12TB per channel, and support 128 PCIe 5.0 buses.
Zen4 Dragon front
Zen4 Dragon back: 6096 contacts
