On March 23, whistleblower Max Weinbach shared the relevant design schematic diagrams of the newly surfaced iPhone 14 Pro and iPhone 14 Pro Max, showing that Apple's upcoming iPhone Pro series may have a more prominent camera and a thicker appearance.
Someone also shared some information about the iPhone 14 Pro last week, but Weinbach shared it in more detail and provided some specific parameters for future iPhones. According to the schematic, the width of the iPhone 14 Pro Max is 77.58 mm, which is slightly smaller than the 78.1 mm of the iPhone 13 Pro Max. The height is almost the same as the 13 Pro Max, which is 160.7 mm and 160.8 mm, respectively.
In terms of thickness, the iPhone 14 Pro Max has a thickness of 7.85 millimeters, which is thicker than the current iPhone, which is only 7.65 millimeters.
Another trend is that the area behind the new phone will continue to increase, and Apple has greatly increased the size of the back camera area in the iPhone 13 Pro and iPhone 13 Pro Max. In 2022, similar trends will return.
According to Apple's guidelines for accessory manufacturers, the camera area on the iPhone 13 Pro Max is currently raised at 3.60mm. According to the iPhone 14 Pro Max parameter diagram shared by Weinbach, the camera area bulge on the 2022 iPhone Pro series will be 4.17 mm.
The length and width of the camera area will also increase from the current 35.01x36.24 mm to 36.73x38.21 mm. In addition, compared with the iPhone 13 Pro, the size of the iPhone 14 Pro has not changed much, with a width of 71.45 mm and a height of 47.46 mm, which remains basically unchanged, and the camera area is more prominently raised, at 4.17 mm.
