Today, I would like to introduce you to a "Hundred Variable Star King" material
In life, we can actually see ta often
TA is foamed polypropylene (EPP)
What are the applications of EPP?
What are the main manufacturers?
Let's take a look
Polypropylene plastic foam material (EPP) used in industry is composed of two phases of solid and gas, black, pink or white granular, and the diameter size is generally between φ2 and 7mm. The outer wall of the EPP particles is closed and filled with gas inside. Usually, its solid phase composition accounts for only 2% to 10% of the total weight, and the rest is gas.
In recent years, the application of EPP has "exploded" and grown
It can be said that where you need TA, there is TA figure ~ ~
EPP's "Changeable Show"
EPP has good heat resistance, good dimensional stability, cushioning performance, low temperature characteristics, oil resistance, chemical resistance, and 100% degradable, recyclable and many other advantages. This "little round bean" has penetrated into all aspects of our lives.
<h1 class="pgc-h-decimal" data-index="01" data-track="29" > automotive field</h1>
With the development of automobile lightweighting, material lightweighting plays a pivotal role in automobile weight reduction. EPP is a closed bubble structure, which can fully absorb fugitive energy to buffer and resist earthquakes; extremely high stability, rapid recovery when deformation; heat insulation and moisture-proof, noise reduction; extremely light in quality and environmentally friendly materials, therefore, the application of EPP in automobiles has increased year by year.
Foamed polypropylene materials are used for example. According to statistics: the average amount of plastic used in cars is currently 100 to 130 kg / car, of which 4 ~ 6 kg / car is used in foam polypropylene.
▲EPP material visor on the car
▲EPP material product display on the car
<h1 class="pgc-h-decimal" data-index="02" data-track="211" > packaging field</h1>
01. Fresh cold chain
As early as 2016, SF recycled the EPP-made incubator as a cold chain.
EPP circulation incubator has the characteristics of heat preservation, heat resistance, corrosion resistance, insulation, etc., is a kind of environmentally friendly cold chain packaging that can be digested after heating, suitable for fruit, frozen meat, ice cream and other food transportation, instead of traditional cold transport foam box, partition, etc.
SF also designed a pink EPP cold chain box for cherry transportation▼
According to the data, in 2016, SF Cold Transport EPP circulating incubators were invested in a total of 120,000 batches, with a cumulative number of uses of 1.57 million times. If these quantities are converted according to the equivalent size, it is equivalent to saving 1.57 million foam boxes + 1.57 million cartons + 3.14 million ice packs! This means that about 20.45 million yuan in packaging material costs and 720,000 kilograms of carbon emissions are saved, which is equivalent to cutting down 9,100 trees. It is worth noting that each EPP incubator can be reused more than 250 times.
There are also many world-renowned catering companies that also choose EPP as their own insulated food delivery boxes.
02. Buffer packaging
In addition, as a buffer packaging, EPP can also protect products that are easy to be "injured" such as fruits, refrigerators, and ceramic products during transportation.
▲ EPP fruit packaging, filmed at the CHINAPLAS scene
▲Redmi TV is packaged in EPP packaging
▲EPP on the toilet can reuse structural inserts for transportation
03. Electronics
The lightweight, antistatic, conductive and anti-voltage cushioning properties of EPP parts can minimize electrostatic damage and collision damage during transfer or transportation of electronic products.
<h1 class="pgc-h-decimal" data-index="03" data-track="213" > sports and leisure</h1>
EPP is a non-toxic, harmless and recyclable environmentally friendly material that avoids poisoning caused by children nibbling on toys. Its products have moderate hardness, good flexibility, no need to worry about bumps or scratches, give children gentle protection, anti-slip insulation and changeable play experience, is an emerging children's toy material. EPP has better seismic energy absorption performance and is more often used to make child safety seats.
At the same time, EPP is also the preferred material for more and more household goods manufacturers advocating environmentally friendly life.
▲ EPP bench, filmed at THE CHINAPLAS scene
As a mattress material, EPP has many advantages such as light weight, safety and non-toxicity, good flexibility and support, can make complex heterosexual structures, can be washed, and is not easy to breed bacteria.
EPP is applied in the middle layer of the helmet to play a cushioning and shockproof role.
Oak found it while searching for information
Innovative application of EPP
Nothing can be done, only the unthinkable
EPP materials are used in fresh air systems
△ Fresh fan EPP shell
EPP bee breeding bins
EPP wind power paddles
△ Splicing structure, wind power station on-site assembly, to solve the problem of paddles is difficult to transport.
<h1 class="pgc-h-decimal" data-index="04" data-track="214" >what EPP manufacturers? </h1>
Currently, JSP, Kaneka and BASF are the leading players in the market among the world's major EPP raw material manufacturers.
1
JSP Co., Ltd.
Founded in 1962, JSP Japan Co., Ltd. was the first in the world to develop the particle method EPP in 1981, and in 1982, it first applied ARPRO/P-BLOCK to the energy absorber block of automobile bumpers, and has since been widely used in production and sales around the world. JSP has a share of about 60% of the global market. The batch EPP preparation technology of the autoclave is patented by the JSP.
2
Kaneka
3
BASF
BASF Neopolen® P (EPP) foamed polypropylene combines its light weight and high energy reception to make no major changes even after multiple impact loads, and is used in automotive safety protection components such as bumpers, driving stick packing, impact pads, headrests and knee pads.
△ Application of Neopolen® P in automobiles
Except for overseas companies
In recent years, a number of chinese have also emerged
EPP raw material production enterprises
4
Wuxi Huitong Lightweight Materials Co., Ltd
China's first national high-tech enterprise with the core technology of foamed polypropylene (EPP) and expanded polyethylene (EPE) materials and research and development, production and sales, with an annual output of 25,000 tons of EPP, 5,000 tons of EPE capabilities.
5
CGN Juner New Materials Co., Ltd
CGN Juner EPP polypropylene foam material is successfully developed by the company's Suzhou Bofan subsidiary, after years of intensive research. In addition to the advantages of light weight, thermal insulation and elasticity of the foam material, the material also has the characteristics of high strength, temperature resistance and environmental protection, and its characteristics of both rigidity and flexibility make it the leader in foam plastics.
△ Photographed at THE CHINAPLAS scene
6
Shandong Haozhi New Material Technology Co., Ltd
China is one of the companies in china that industrially mass-produces high melt strength polypropylene, mainly producing high melt strength polypropylene (HMSPP), polypropylene (PP) blowing agent/ masterbatch, polyethylene (PE) blowing agent/ masterbatch, polystyrene (PS) blowing agent / masterbatch, composite AC modified blowing agent, ethylene-vinyl acetate copolymer (EVA) blowing agent / masterbatch, polyvinyl chloride (PVC) blowing agent / masterbatch, microsphere blowing agent / masterbatch, thermoplastic elastomer blowing agent / masterbatch, etc.
△ Polypropylene (PP) blowing agent
7
Suzhou Delong Composite Materials Co., Ltd
Founded in 2009, it focuses on the three major development directions of energy conservation and environmental protection, bio-based degradable materials and automotive lightweight materials. The company's main products are: EPP, PEPP, ETPU, EPLA and other materials and molding products.
8
Suzhou Xianghou New Material Technology Co., Ltd
One of the suppliers of foamed polypropylene (EPP), always dedicated to the development and production of EPP. The products have successfully applied for IMDS and been used by well-known automobile brands for the production of parts, providing assistance for a large number of automobile companies.
△ EPP beads
9
Lotte Engineering Plastics (Jiaxing) Co., Ltd
Founded in 2006, with the technical strength and global competitiveness of its parent company Rakuten Chemical, and a very strong background in raw material production technology, Lotte Group also has several modified enterprises in China. The main products of Lotte Engineering Plastics (Jiaxing) Co., Ltd. are TPO, EPP, LFT, adhesive resin, etc., with an annual production capacity of tens of thousands of tons.
10
Wuhan Deguan New Material Technology Co., Ltd
A high-tech enterprise specializing in the lightweight, high-performance and environmental protection of polymer materials. PP831 kettle pressure foam grade polypropylene is a kind of bead grain foam grade polypropylene specially developed by Deguan Company for the production of bead industry foam products by kettle pressure method. It has the characteristics of no eyelet plugging, good elasticity of foamed particles, and low welding temperature.
If there is any omission in the above, welcome to leave a message to correct ~
Everyone is also welcome to COME next year at CHINAPLAS
Discover more EPP materials and applications!
END
(Materials from: Aibang polymer, UTPE elastomer portal, DT new materials, Wuxi Huitong Lightweight Materials Co., Ltd., the official websites of various enterprises, etc., comprehensively sorted out by CHINAPLAS, please indicate when reprinting.) ）
