Stepway and Acceleration Technology officially signed a cooperation agreement to jointly develop a high-speed image acquisition and test system!

Recently, Stepway (Shanghai) Electronic Technology Co., Ltd. (hereinafter referred to as "Stepway") will carry out further in-depth cooperation with Hangzhou Acceleration Technology Co., Ltd. (hereinafter referred to as "Acceleration Technology") to jointly develop a high-speed image acquisition test system for the high-speed interface test of ultra-high resolution and ultra-high frame rate image sensors. The high-speed image acquisition test system is expected to reach a data transmission rate of 3.5Gsps, which will help Stepwell accelerate the mass production process of high-end CMOS image sensors such as smartphone main cameras, drones, 8K smart security cameras and high-speed industrial cameras to better meet customer needs.

C-PHY 3.5Gsps

In recent years, as CMOS image sensors continue to develop towards the trend of high frame rate and high pixelation, the amount of data transmitted by cameras has continued to rise. For efficient signal transmission, mipi D-PHY and MIPI C-PHY transmission interfaces are commonly used. D-PHY adopts a separate clock synchronization line + data Lane transmission structure, each Lane is composed of 2 differential lines, anti-interference ability and driving ability is strong; while C-PHY is a complex transmission structure composed of 3 leads without independent clocks, anti-interference and driving ability is weak, so there are higher requirements for IC design capabilities. However, mipi C-PHY can provide higher throughput due to its 5-based transmission, which is better than the binary of D-PHY, with a transmission volume of 2.28 times, which is mostly used by high-end mobile phone platforms.

At present, Stepway has developed a deeply customized CIS test solution with Acceleration Technology, which can meet the needs of high-speed signal near and far scene layout testing, support multi-site parallel measurement expansion and product testing upgrade iteration, and the solution has been mass-produced to support D-PHY 2.5Gbps and C-PHY 2.5Gsps. In order to speed up the testing and mass production process of Stevie's subsequent high-end CMOS image sensor products, the two sides will jointly develop the CIS high-speed image acquisition and test system in the future, and plan to achieve a data test rate of C-PHY 3.5Gsps.

Excellent RX and TX port design

The eye diagram can intuitively reflect the impact of code-to-code crosstalk and noise on the transmission signal, and is an important indicator for evaluating the performance of a baseband transmission system. Due to the shortening of the unit time interval and the low-pass characteristics of the data path, it will become difficult to ensure sufficient eye width and eye height, and the design difficulty will be greatly improved. When the signal reaches the RX at the receiving end from the transmitter TX, if a large loss is generated, the RX cannot correctly restore and decode the signal, and even the eye diagram is completely closed.

At present, Steway has the ability to design high-speed data transmission interface of image sensors, and further optimizes the design of TX and RX ports to ensure the quality of the transmission signal, and can maximize the transmission data rate and ensure the stability of data transmission in the process of large data acquisition and transmission of ultra-high resolution and ultra-high frame rate image sensors.
