At 10:00 p.m. on January 26, NVIDIA's rookie GeForce RTX 3050 was officially unbanned! This new 1899 yuan entry-level light chasing graphics card has attracted the attention of countless gamers with its excellent price-performance ratio. Today we will bring you an RTX3050 black gold extreme edition graphics card disassembly from the first-line AIC Yingzhong (INNO3D) for the first time, and feel the unique charm of this entry rookie.
The appearance of the INNO3DRTX 3050 Black Gold Supreme Edition follows the RTX30 series family metal design language, and the silver and gray color scheme is more sharp in appearance, all of which highlight the unparalleled leadership temperament.
Dual 90mm diameter large fans support intelligent fan shutdown function. The body size is only 240*120*38mm, the thickness is only a dual-slot design, and the chassis is more compatible. However, due to the positioning price-performance ratio, the LOGO lamp design was not added.
The video interface is DP*3+HDMI*1, which requires an 8Pin external power supply.
RTX3050 Black Gold Extreme Edition adopts a huge heat sink and an S-shaped single heat pipe combination, which almost covers the card body, expands the contact area with the air, and disperses the accumulated waste heat of the graphics card into the air in time through the fan, effectively preventing the video card temperature from being controlled at a low level.
In addition, in order to protect the graphics card PCB and enhance heat dissipation, the graphics card is also designed with a one-piece metal backplane, a large-area cutout design, which can be combined with the chassis vertical duct design to discharge heat from the chassis out of the chassis.
The graphics card adopts the public PCB scheme design, equipped with 4 + 1 power phase design, Japanese high-quality capacitors, ferritic inductance are standard materials, in addition, the graphics card also needs an 8Pin external power supply, TDP is 130W, it is recommended to use a power supply rated 500W or more.
In terms of core specifications, GA106-150 cores, 2560 CUDA cores, core frequency of 1552 ~ 1777MHz, memory specification of 8GB128BIT GDDR6, frequency of 14Gbps.
It is reported that Yingzhong INNO3D RTX 3050 Black Gold Supreme Edition will officially land on the domestic market on January 27, priced at 1899 yuan. For friends who want to start a graphics card in the near future, you may wish to pay close attention to it.
