After the first 6 K/KF series overclockable models, Intel today completed the 12th generation Core desktop version family, up to the i9, down to the Celeron, there are as many as 22 models, the entire family has reached 28 models.
Specifically, these include —
i9三款：Core i9-12900、i9-12900F、i9-12900T
i7三款：Core i7-12700、i7-12700F、i7-12700T
i5七款：Core i5-12600、i5-12600T、i5-12500、i5-12500T、i5-12400、i5-12400F、i5-12400T
i3五款：Core i3-12300、i3-12300T、i3-12100、i3-12100F、i3-12100T
Pentium two: Pentium G7400, G7400T
Celeron two models: Celeron G6900, G6900T
The specific specifications of each model are not interpreted one by one, or the familiar product line layout, to summarize the following:
Number of cores:
The i9 and i7 series are both large and small core hybrid architectures (C0), including the previous i5-12600K/12600KF, the i5 series and below only large core (H0), in addition to the Celeron, all support hyper-threading.
Specifically, the i9 8 big 8 small, the i7 8 big 4 small, the i5 6 big, the i3 4 big, the Pentium/Celeron 2 big.
L2 cache:
i9 14MB, i7 12MB, i5 7.5MB, i3 5MB, Pentium/Celeron 2.5MB.
L3 cache:
i9 30MB,i7 25MB,i5 18MB,i3 12MB,奔腾6MB,赛扬4MB。
frequency:
Both the i9 and i7 cores support Turbo Max 3.0, of which the large core can reach up to 5.1GHz and the small core can reach up to 3.8GHz.
i5 and i3 both support Turbo 3.0, while Pentium and Celeron continue to support Turbo.
Nuclear display:
This generation and the 11th generation have changed almost nothing, mainly because the name has been upgraded, and of course the F series has no core display.
The i9, i7, i5-12600/12500 series are all UHD 770 (32 units), the i5-12400 series, i3 are UHD 730, and the Pentium and Celeron are UHD 710.
memory:
Unified support dual channel DDR5-4800, DDR4-3200, the maximum capacity of 128GB, Celeron has not been downgraded.
Pcie:
Unified support for 20 PCIe 5.0, Celeron is no exception.
Reference power consumption:
In the standard version, the i9, i7, and i5 are all 65W, i3 60W, but the i3-12100F 58W, Pentium, and Celeron are all 46W.
The T series energy-saving version is 35W.
Maximum acceleration power consumption:
In the standard version, i9 202W, i7 180W, i5 117W, i3 89W.
Energy saving version, i9 106W, i7 99W, i5 74W, i3 69W.
Pentium and Celeron do not have this indicator because they do not support turbo acceleration.
Price:
At present, there are only North American prices, and the reference value is not very large.
The most concerned i5-12400, i5-12400F are 192 US dollars, 167 US dollars, respectively, the National Bank of China should be around 1300 yuan, with B660 motherboard, DDR4 memory, a word fragrance.
In terms of performance, the official i9-12900 is up to 55% higher than the previous generation i9-11900 content creation, and the game performance is up to 21%.
Comparing competitors, it is strange to use i9-12900 and i5-12600 to hit Ryzen™ 7 5700G, but only compared productivity and content creation, and there is no comparison.
At the same time, Intel also officially released three new original radiators, from low to high:
Laminar RS1：
Very plain, used for galloping, celeron.
Laminar RM1：
The bottom copper core, the top added a blue band, known as low noise as 3.9 decibels, for i7, i5, i3.
Laminar RH1：
Large copper core at the bottom, copper heat dissipation fins, customizable ARGB lighting effects, noise as low as only 2.6 dB, for i9.
