According to media reports, Intel will conduct a new product launch at CES 2022 in the early morning of January 5, Beijing time.
At the press conference, Intel will launch the 12th generation Core mobile model, non-K series desktop model, as well as the H670, B660, H610 for the mainstream and entry markets will also appear. However, according to the latest exposure, the H670 motherboard may be cancelled.
Founded in 1985, the board brand with 36 years of rich experience so far, Meijie, from this generation, officially renamed its motherboard series, in addition to the previously released flagship Legend (commemorative edition) series, for the mid-range SAGA (heritage edition) and entry-level Classic (classic edition) series, there is no more product news for the time being. However, from its flagship product SY-LegendZ690 WiFi released earlier, it can be seen that Metrohm has a sophisticated production level of motherboard products.
The motherboard is dark black overall, the standard ATX version, power supply, M.2 area are covered with a large area of alloy heat dissipation armor, and the armor is embellished with RGB lighting effects.
The power supply part adopts a high-level power supply scheme, RAA229131PWM chip, 19+1 phase flagship power supply, with 90A direct out ISL99390Dr.MOS, fully squeeze the complete performance of the 12th generation Core i9.
Such a sharp power supply module is indispensable with an excellent heat dissipation system. The power supply part of the motherboard is heat dissipated, plus the copper tube is connected, and the heat energy generated by the 12th generation Core processor is fully loaded! And the M.2 slot and PCH part are also equipped with thermal armor, and the coverage of the large area takes into account both MOS and inductance, which further improves the stability of the motherboard.
The alloy armor on the MOS and PCH has a dot matrix design of the "Meijie logo" RGB lighting effect, preset a variety of lighting effect modes, and can use the on-board lighting effect button to achieve the control of the motherboard lighting effect. The motherboard also provides 2 ARGB pins and 1 RGB pin, providing more external device lighting linkage such as chassis, cooling fan, etc.
What's even more surprising is that the back of the motherboard is also equipped with an alloy backplane, which further improves the protection and durability level of the motherboard.
In terms of expansion slots, there are 2 PCIe graphics card slots equipped with alloy armor, and PCIe5.0 near the CPU side. There are also 3 PCIex1s for other extensions.
4 x DDR5 memory slots support the new DDR5 memory with higher memory frequencies, optimized voltage and motherboard routing for better performance.
In terms of storage interfaces, the motherboard has 3 M.2 interfaces, one is PCIex4 4.0 channel (CPU direct connection), 2280 length specification, the other two are PCIex4 4.0 (PCH direct connection), 22110 length specification; there are 4 traditional SATA interfaces.
In terms of network cards, the motherboard is equipped with RT8125B dual 2.5G wired network cards, which support the formation of link aggregation, network redundancy, software routing, etc.; can increase the bandwidth of the upstream and downstream, ensure network stability, and facilitate the formation of home LAN and NAS. Coupled with the AX211WiFi6E wireless network card, players can experience rapid interconnection anytime, anywhere.
In the I/O interface part, the motherboard provides 9 USB3.2 interfaces, of which 8 are Type-A and 1 is Type-C; DP+HDMI video output interface is one each.
The motherboard also provides intimate humanized function design, RGB lighting effect switching button, change color at will; CLR_CMOS physical button, one-click recovery BIOS settings; FlashBios button, can be free to install CPU, memory, hard disk and other update BIOS; digital display Debug lamp + traditional Debug lamp combination, can quickly determine the fault location of the motherboard, at a glance.
What has changed is the name of the product series, but what has not changed is that Meijie has insisted on focusing on product quality for 36 years, so let us look forward to the arrival of more new products of Meijie.
