采用booth算法實作兩個8bit實數的乘法運算

/*******************************************************************************************************

作者：lidong

時間：2015.7.18

郵箱：[email protected]

功能：采用booth算法實作兩個8bit實數的乘法運算

**********************************************************************************************************/

module mult

(

sys_clk,

sys_rst_n,

ina,

inb,

yout,

start_sig,

done_sig

);

/*********************************************************************/

//input

input sys_clk;//system clock 50MHz

input sys_rst_n;//reset signal 0:valid

input [ 15:0 ]ina;

input [ 15:0 ]inb;

input start_sig;//enable signal 1:valid

//output

output done_sig;

output [ 31:0 ]yout;//result

/***********************************************************************/

reg [ 2:0 ]i;

reg [ 15:0 ]A;//reverse result ina

reg [ 32:0 ]p;//operation register

reg [ 5:0 ]cnt;

reg isDone;

always @( posedge sys_clk or negedge sys_rst_n )

if( sys_rst_n == 0 ) begin

i <= ‘h0;

A <= ‘h0;

p <= ‘h0;

isDone <= ‘h0;

cnt <= ‘h0; end

else if( start_sig == 1 )

case( i )

0: begin A <= ~ina + 1’b1; p <= { 16’d0,inb,1’b0 }; i <= i + 1’b1; end

1: if( cnt == 16 ) begin cnt <= 'h0; i <= i + 2; end
        else if( p[ 1:0 ] == 2'b01 ) begin p <= { p[ 32:17 ] + ina,p[ 15:0 ]}; i <= i + 1'b1; end
        else if( p[ 1:0 ] == 2'b10 ) begin p <= { p[ 32:17 ] + A,p[ 15:0 ]}; i <= i + 1'b1; end
        else i <= i + 1'b1;

    2: begin p <= { p[ 32 ],p[ 32:1 ] }; cnt <= cnt + 1'b1; i <= i - 1'b1; end

    3: begin isDone <= 1'b1; i <= i + 1'b1; end

    4: begin isDone <= 1'b0; i <= 'h0; end
    default: i <= 'h0;
endcase


/***************************************************************************************************/

assign done_sig = isDone;

assign yout = p[ 32:1 ];

endmodule

//激勵檔案

`timescale 1ps/1ps

module multi_test;

reg sys_clk;

reg sys_rst_n;

reg start_sig;

reg [ 15:0 ]a;

reg [ 15:0 ]b;

wire done_sig;

wire [ 31:0 ]q;

mult mul

(

.sys_clk( sys_clk ),

.sys_rst_n( sys_rst_n ),

.start_sig( start_sig ),

.done_sig( done_sig ),

.ina( a ),

.inb( b ),

.yout( q )

);

initial

begin

sys_clk = 1;

sys_rst_n = 0;

200

sys_rst_n = 1;

forever #50 sys_clk=~sys_clk;

end

reg [ 3:0 ]i;

always @( posedge sys_clk or negedge sys_rst_n )

if( sys_rst_n == 0 ) begin

i <= ‘h0;

a <= ‘h0;

b <= ‘h0;

start_sig <= 1’b0;

end

else case( i )

0: if( done_sig == 1 ) begin i <= i + 1’b1; start_sig <= 1’b0; end

else begin a <= 12; b <= 2; start_sig <= 1’b1; end

1: if( done_sig == 1 ) begin i <= i + 1’b1; start_sig <= 1’b0; end

else begin a <= -2; b <= 45; start_sig <= 1’b1; end

2: if( done_sig == 1 ) begin i <= i + 1’b1; start_sig <= 1’b0; end

else begin a <= 62; b <= 1; start_sig <= 1’b1; end

3: if( done_sig == 1 ) begin i <= i + 1’b1; start_sig <= 1’b0; end

else begin a <= 15; b <= -3; start_sig <= 1’b1; end

4: if( done_sig == 1 ) begin i <= i + 1’b1; start_sig <= 1’b0; end

else begin a <= -42; b <= -30; start_sig <= 1’b1; end

5: if( done_sig == 1 ) begin i <= i + 1’b1; start_sig <= 1’b0; end

else begin a <= 20; b <= 45; start_sig <= 1’b1; end

6: if( done_sig == 1 ) begin i <= i + 1’b1; start_sig <= 1’b0; end

else begin a <= 676; b <= 10; start_sig <= 1’b1; end

7: if( done_sig == 1 ) begin i <= i + 1’b1; start_sig <= 1’b0; end

else begin a <= 14; b <= 530; start_sig <= 1’b1; end

8: i <= i;

endcase

endmodule
