Buy the whole machine is also not square, MSI MAG Infinite RS emberless barebones system host into the pit sharing directly began to decompose (said) this barebones system host installed and the whole machine effect of the whole machine test installation summary

The whole e-commerce machine is cautious, and the whole machine is easy to overturn, which is what friends who used to toss the computer diy often hang on their lips. The main reason for this phenomenon is that some merchants use foreign garbage or second-hand configurations to sell at high prices after packaging, which really pits many players.

Of course, with the entry of brand machine merchants and the standardization of the e-commerce platform itself, the number of indiscriminate machines is obviously less, but most players still think that the "water" of the whole machine is very deep and dare not buy it easily. I don't believe in evil, I also took advantage of the recent bearish graphics card market to start a MSI mag infinite rs emberless barebones system host, and shared the actual test experience with everyone.

That's right, it's this big guy, cool black with bright red lines, and this package is strong enough.

The mood is somewhat urgent, directly unboxing to take out the whole machine body, while loving to tear Kimo (membrane) people on the line...

The barebones system host, in short, is a semi-finished host (usually no graphics card, memory, hard disk), of course, it can also be directly selected with missing accessories when placing an order. Because there is no shortage of accessories on hand, this time I only purchased the standard version of the emberless barebones system host. The configuration is as follows: Intel i9-10900K processor, MSI MEG Z490 ACE Ares motherboard, MSI MPG Sekira 100p Black Gold Peyron Axe 2 chassis, MPG A850GF Gold Medal full module power supply, mag coreliquid 240r all-in-one water cooling

The front of the machine is an aluminum metal panel, the metal drawing process is blessed, and the MSI Dragon Shield logo is dotted with it, and the overall texture is full.

Highly permeable tempered glass side panels on the left for a better display of internal hardware

MSI MPG Sekira 100p Black Gold Peron Axe 2 chassis has a large area heat sink design on the top

The chassis I/O panel is located on the top front, and the interface is also very rich, USB3.2 and type-c are all available

The side plate opening method is also relatively special, and it is necessary to remove the two screws at the end of the top cover first

The whole tempered glass side plate is raised upwards, and the advantage of this design is that it is anti-drop on the one hand, and on the other hand, it is stronger than the tempered glass of those drilled designs.

After removing the top dust screen, you can see that there is a very large hole spacing heat dissipation hole at the top of the chassis, the installed MSI mag coreliquid 240r integrated water cooling row is clearly visible, and the reserved screw hole position indicates that the top of the chassis should support a maximum of 280 specifications of cold drain.

The front face of the chassis as a whole adopts snap-on installation, and the disassembly is relatively simple, and 3 120mm lampless fans are also pre-installed here. If you need to install the 360 cold drain, you need to remove the pre-installed fan first.

To tell the truth, thanks to the continuous update of Intel's new products, I finally used the 10th generation of high-end i9 processing. With a 10-core and 20-thread configuration, the performance is good enough and the productivity is absolutely top-notch. It can also be perfectly played on the MSI meg z490 ace god of war motherboard.

MSI Z490 ACE Motherboard, standard ATX form factor, large area high value metal cooling vest cover design, belongs to MSI's top motherboard series, and is compatible with the 11th generation Intel Core platform after upgrading the BIOS. 16-phase all-digital power supply, which can perfectly meet the overclocking needs of the 10th generation and 11th generation Core i9. 4 metal-reinforced ddr4 memory slots support up to 4600mhz frequency and 128g large capacity. Coupled with the 2.5g network interface and wifi6 wireless network interface configuration, it is worthy of the name of the king of pile materials.

In terms of power supply, MPG a850gf gold medal full module power supply produced by MSI, 80plus gold certification, all-Japanese capacitor luxury configuration, full module design, and support 10 years warranty. The 850w capacity can meet the power consumption needs of the top graphics cards of the Intel Core i9 and NVIDIA RTX30 series.

In terms of heat dissipation, the same MSI's mag coreliquid 240r frost is integrated with water cooling, which is also enough to meet the heat dissipation needs of the 10th generation Core i9. The cold head adopts argb dragon pattern lighting effect design, the fan also supports argb lighting effect, and this water cooling also has a feature that integrates the water pump into the cold drain, which can effectively reduce the noise of the cold drain operation.

As for the back of the whole machine, although it looks messy, in fact, a little tidying can have a good line effect.

After the barebones system host has commented, it is time to prepare to find the accessories to install the machine. If you don't have a graphics card or don't plan to buy a graphics card for the time being, it's okay to play Tencent Family Bucket with this barebones system host.

First on the solid state, two 1t size shadow Chi Qing pcie3.0 m.2 solid state direct arrangement, one using the original heat dissipation vest to nearly the first m.2 slot, the other is directly hidden in the solid state body under the m.2 heat dissipation vest that comes with the motherboard.

In terms of memory, if the budget is sufficient, directly 4 full, but from the cost performance point of view, 8g * 2 groups of dual channels have been enough to play the performance of the whole machine. As for the frequency, the recommendation is to start at 3600mhz, 4000mhz is better, as for the higher frequency, if it is not the pursuit of extreme performance of the player is basically unnecessary. What I chose for myself was the Shadow Chi Hall of Fame ddr4-4000 8g*2 set, specially selected Samsung b-die particles, overclocking performance is strong, while the white metal heat dissipation vest, but also directly pull the face value full.

Finally, there is the installation of the graphics card, and today I chose the flagship RTX 3080ti hof extreme graphics card. Under the chaotic market, buying a graphics card has become the same as investment, and blood is worth saving money. Configuration: ga102-225 core, with 10240 stream processors, 1365mhz base frequency, 1785mhz acceleration frequency, equipped with 12g gddr6x memory 384-bit memory bit width, the overall performance has been able to touch the tail of 3090. For my 2K monitor, there's no pressure to play mainstream games at the basic extreme.

Such a large flagship graphics card, the graphics card bracket must not be less

The finished product is baked, the black and white panda color matching, the overall texture is also very good

After loading the machine, it is recommended to light it first, and then take the line (to prevent overturning). I don't need to, though! Pretended to straighten the line

Then install the whole machine side panel to see the effect

One light (if the wiring is loose during the whole machine express delivery process, it may not be able to light up, so even if you encounter a situation that cannot be lit, you can also calm down first to troubleshoot the problem, do not be impatient)

Although there is no plan to create a light pollution theme, the rgb lighting effect of the whole machine is also good. Of course, if you want to create a more dazzling rgb lighting effect, you must plan well when choosing accessories, and the platform itself supports MSI's own lighting effect system management synchronization.

Desktop effects, without rgb lighting effects, are very good from all angles.

Entering the whole machine performance test link, first of all, it must be the lu master running score that ordinary players are most concerned about, and the score of the whole machine close to 184w should be enough to prove its excellence.

In the cpu-z test, the 10900k single core score was 606.3, and the multi-core score was 7535.5, and the performance was not bad;

After opening xmp, the memory performance is tested, and the read and write and copy speeds are maintained at more than 50000mb/s, and the latency is directly as low as 49.1ns

Graphics card 3dmark test, ts project test, graphics card score 20341

Tse project test, graphics card score also reached 10339

FS project test, graphics card score 48887

FSE project test, graphics card score 24526

In the light chase test, it also got a high score of 13584

The environment in the chassis, room temperature 29 °, the graphics card for copy test, the maximum graphics card temperature is only 76 degrees, the power consumption is close to 400w

Because I currently only have a 2K monitor on hand, I can only use this configuration to run the game test at 2k resolution.

2K resolution, light chased to the highest, dlss turned on, Tomb Raider game average frame count of 123

2K resolution, gears of war 5 benchmark, the game average frame count can reach 159.0fps

2K resolution, light chasing to the highest, dlss quality mode, the average frame number of the whole game of "Watchdog Legion" is about 76 frames;

2K resolution, very high image quality, known as the graphics card killer of the Assassin's Creed Odyssey game average frame rate can also reach 86fps

In summary, it should be said that this is a "whole machine" purchase plus tossing experience that has not been overturned, and it has also been proved that not all the whole machine is unreliable; although the standard version of the MSI mag infinite rs emberless barebones system host is not a real machine, the above disassembly can be known that this is indeed a semi-finished product host with absolutely solid materials and absolutely excellent performance. With the rtx3080ti graphics card, it will also directly build the whole machine into an absolute high-end host in the current situation. The measured results also prove that the whole machine can play extremely well under the condition of 2K resolution, and even at 4K resolution, it can reach the level of playing mainstream game masterpieces;

Of course, this may also be my fastest installation experience at present, maybe three or five minutes is good, and there is no rollover in the whole process, which can be said to be very comfortable. For those players who want to toss the computer diy but are not sure, this semi-finished barebones system host should be a good choice; of course, if you can't install at all, you can also apply for MSI to Fuxing service, not only can help install on-site, but also enjoy the privilege of three years of free on-site service;

As for whether it is really time to buy a graphics card? Personally, I think that after waiting for such a long time, why wait for a double 11, you say?
