I. Introduction
Recently, there have been a lot of very creative chassis products in the chassis market, not only in terms of appearance design is very creative, but also in the chassis air duct, there are some very bold innovations, and these innovations are very interesting.
For example, the power train has just released the wind master chassis that has just been released on the market, on the side of the chassis, the side of the chassis is creatively divided into two parts, and the lower part adds a heat dissipation grille in the position of the graphics card, which is very interesting to take care of the heat dissipation of the graphics card part.
The power train brand is an old brand, founded in 2010, has been launching a variety of very good products in the fields of chassis, power supply, radiator, display and so on. In addition, its chassis product line is very rich, including Wind Master, Titanium Series, Thunder, etc., everyone is very familiar with it.
Second, the power train wind master chassis unpacking
▼ The packaging of the chassis is very simple, the middle is the chassis name, and the lower right corner is some chassis introduction. Among them, this GSTS graphics card cooling system is very interesting, and we can look at this later.
▼ The side of the chassis is a parameter, with detailed specifications and compatible data.
▼Inside the carton, in addition to the chassis, there are some accessories and instructions.
Third, the power train wind master chassis appearance
▼ The appearance of the chassis is very distinctive, very novel, mushrooms have never seen this design.
▼ The position of the graphics card part on the side of the chassis has a large area of grille, which can directly inlet the air to take care of the heat dissipation of the graphics card part. In addition, the IO panel of the chassis is on the side, and the chassis is very easy to use when placed on the desktop.
▼ The front part of the chassis is a large area of metal grille, and the air intake area is huge.
▼The back side of the chassis, metal cover, left side of the heat dissipation grille.
▼ Chassis tail, familiar with the configuration of the ATX chassis.
▼ The top of the chassis has a significantly heightened design, and it will be very convenient to install water cooling on the top of the chassis.
▼ PCIe slot part, there are 7 horizontal, vertical three, support graphics card vertical installation, space is also very sufficient.
▼ The top of the chassis is also a large area of metal heat dissipation grille. In addition, the internal space of this chassis is very large, and the top and front parts support the installation of 360 water cooling.
▼ At the bottom of the chassis, there are four non-slip feet, the left side is the metal dustproof net of the power supply, and the right side is the fixed hole of the hard disk compartment.
▼ Remove the side-through glass and grille on the side of the chassis, and the structure inside the chassis is clearly visible.
▼ The side glass on the side of the chassis and the heat dissipation grille at the bottom are two pieces designed in segments and completely independent.
▼ The space inside the chassis is very traditional, the bottom is a separate power supply compartment, and the upper part is the motherboard fixed bit and the like.
▼ The top of the chassis supports 360 water cooling, and the rear has a chassis fan position, which supports the maximum 140mm specifications.
▼ The front of the chassis also supports 360 water cooling, and the right part of the motherboard has cable management holes, and there are also metal covers that cover the cable management holes.
▼ At the bottom of the chassis, there are two chassis fan positions in the upper part of the power supply compartment, and there is also a heat dissipation grille on the side of the power supply compartment.
▼ The grid position supports individual disassembly, magnetic + screw fixed, disassembly is very convenient. By the way, the IO panel part supports shenguang synchronization, which can synchronize the lighting effect with other hardware in the chassis.
▼ On the back of the chassis, there is plenty of space for walking the back line, and there are also some very good designs.
▼ The inside of the metal cover plate of the chassis is well made, and there is also a metal magnetic dustproof net on the inside of the grille.
▼ The back of the chassis is designed to be clear, and the bottom is the power supply compartment.
▼On the left side are various trace holes, all of which have a folded design. In the middle is the cable management space, with plastic cable management accessories.
▼ On the right side, there are two 2.5-inch hard disk fixed bits, which is easy to disassemble and install.
▼ The bottom of the chassis is a separate power supply bay, and on the left side is a hard disk slot.
Fourth, the power train wind master chassis is installed
▼ Then get ready to install the machine to see how this chassis performs.
▼ The water cooling is made of the DL240 of the power train, and this water-cooled water cooling head adopts a mirror design and is very beautiful.
▼ The water cooling is fixed to the motherboard here first, and then tucked into the chassis.
▼ The motherboard is fixed normally, and the water cooling row is directly fixed to the upper part of the chassis, which can be fixed very easily, and the top space of the chassis is indeed very sufficient.
▼ Then install the graphics card, Yingchi's RTX3070Ti HOF Pro graphics card, the heat dissipation module of this graphics card is white as a whole, very beautiful.
▼ The graphics card is installed vertically here, and how the design of this new chassis structure performs.
▼ By the way, the power train this wind master chassis comes standard with a graphics card bracket, which is very good.
▼When the graphics card is erected, it can also be braced at the tail of the graphics card to provide support.
▼ The power supply uses Antic's HCG850 gold medal full module power supply, which uses all-Japan capacitors and has a 10-year replacement warranty, which is still very reassuring to use.
▼In addition, the length of the power supply is only 140mm, and the compatibility performance of daily installation is particularly good. The 120mm specification of the cooling fan on the side of the power supply can almost completely occupy the side of the power supply, and the heat dissipation effect is also good.
▼ In addition to the power socket and switch at the tail of the power supply, there is also a power supply fan operation mode selection button, which can be switched between temperature control and mute modes, which is very convenient.
▼After the power supply is fixed, the power supply of each part is connected by hand.
▼ Finally, install a chassis fan in front of the chassis, inlet air, and assist other hardware inside the chassis to dissipate heat.
▼Finally cover all the side panels on both sides of the chassis, and the installation of the whole machine is completed.
▼ Boot, light up at once, the whole machine effect is still very good.
▼ The IO panel on the side of the chassis also has ARGB lighting effects, which looks good, and the interfaces and buttons are very clear.
▼ Through the side through glass at the top of the chassis, you can directly see the various hardware inside the chassis, and the effect is still quite praised.
▼ Power train this DL240 water-cooled water-cooled head lighting effect, very beautiful, the middle is the power train LOGO, mirror design, surrounded by a circle of ARGB lamp rings.
▼ Under the side-through glass is the GSTS grille cover, which directly shows the cooling fan of the graphics card.
▼ Three ARGB lighting fans are installed on the front of the chassis, and the appearance effect through the heat dissipation grille is still good.
▼ The motherboard uses MSI's Z690 Blade Ti motherboard, and the power supply part of the motherboard has a complete, large metal auxiliary heat sink, which looks very powerful. In addition, the metal heat dissipation surface on the left side has MSI's Dragon Shield LOGO, which has ARGB lighting effects, which is very beautiful.
▼ In addition, this motherboard has four M2 slots, and all of them are covered with metal heatsinks, which is convenient for daily use.
▼ The memory is zadak's SPARK, the memory vest is very beautiful, multi-segment RGB light strip design, the shape is like a small wing.
▼ Look closely, the top of the memory bar vest is made of silver aluminum alloy, and the side is black, which can be integrated with the motherboard.
Fifth, the power train wind master chassis test
▼ The whole machine configuration at a glance, the processor is 12400, the motherboard is MSI's Z690 Blade Ti, the memory is Zadak's SPARK, 8G*2 3600MHz, and the graphics card is Yingchi's RTX3070Ti HOF Pro.
▼ Simple to run a test, the whole machine score 153W, processor 55.3W, graphics card 61.5W, the performance is very good.
▼ Room temperature is about 20 °C, processor standby 26 °C, graphics card core temperature 32 °C, fan shutdown, solid state temperature 38 °C, south bridge part of the temperature 51 °C, the overall temperature performance is OK.
▼ Simple run a CPU-Z pressure test, the processor full core turbo frequency 4GHz, temperature 46 °C. The core temperature of the graphics card is 31°C, which drops a little.
▼ Single-baked FPU test, processor full core turbo frequency 4GHz, temperature 53 °C, the overall heat dissipation performance is good.
▼ 3Dmark stress test, frame rate stability rate of 98.9%, good and good.
▼ The core temperature of the graphics card is up to 69.7 °C, and the core temperature performance is good. The temperature of the processor fluctuates around 37 ° C, and the overall temperature does not rise significantly, indicating that the cold exhaust of the processor basically cannot absorb the exhaust of the graphics card part, which is good.
▼ Mushroom is curious about the power train this GSTS cooling system, try to turn it off, and then run a 3Dmark stress test on the side, TS mode.
▼ It can be clearly seen that after blocking the side of the chassis, the air intake of the graphics card is no longer smooth, and the core temperature has increased a lot. The core temperature of the graphics card has increased, the temperature of the blown out wind has also increased, the processor has also been affected, and the temperature has also increased significantly.
▼In addition, the bottom position of the side of this chassis can also be installed with a fixed chassis fan.
▼ In the case of vertical mounted graphics card, if the thickness of the graphics card is relatively thick and there is not enough space on the side of the chassis to install the chassis fan, then you can choose a horizontal graphics card, and the original graphics card bracket is supported on the tail.
▼There is a hole in the inside of the grille to fix the chassis fan, and the chassis fan can be directly fixed on it.
▼I put the grille of the air intake back, and through the metal dust screen, I can faintly see the chassis fan on the inside.
▼Finally covered with the effect of the side grille and side glass of the chassis, the overall look is not bad.
▼ Boot, light up at once, the whole machine effect is very beautiful.
▼ The chassis fan on the side supports ARGB lighting effects, and with the metal dustproof mesh on the outside, the overall appearance is very good.
▼ Power Train Wind Master This chassis can support a large number of chassis fans, the first three, side three, top three, rear one, the next two, a total of 12 chassis fans can be installed, very powerful.
▼After adding a side fan, the full load temperature of the graphics card is reduced by about 2 °C, and the performance is still very good. In addition, the standby temperature reduction is more obvious, after all, in the case of standby, there are more fans blowing through the video card cooling module.
6. Summary
The power train this wind master chassis is still quite good, the overall design is very bold and creative, in the side of the chassis of the side through part of the bold design, divided into two parts of side through and air intake. The upper part is used for side transparency to ensure the appearance value, and the lower half is used for air intake to ensure heat dissipation. In addition, in some details, the design is also quite good.
This chassis supports vertical mounting of the graphics card, and there is a special heat dissipation grille directly on the side of the graphics card, which is convenient for air intake and ensures the heat dissipation of the graphics card part, which is very good. In terms of internal space, the front and upper part support the installation of fixed 360 water cooling, and the expansion ability is excellent.
In terms of installation experience, the side glass of the chassis, side panels, etc. all support tool-free disassembly, and it is very convenient to upgrade the hardware and the like.
Oh, in addition to the black and gray color, this chassis also has white gray, white blue, pure white and other colors, when choosing with their own hardware, the effect of the whole machine is still very online.
Thank you!
