前言
豐密面單，就是隐藏了使用者個人資訊的順豐快遞面單。該面單可将寄、收件人名字、手機、位址等部分資訊隐藏，讓個人資訊不再直接暴露。
我們先看2張面單效果圖。
圖一:
圖一是一張二聯150MM的電子面單模闆，寄件人和收件人手機是可見的。
圖二
圖二也是一張二聯150MM的電子面單模闆，寄件人和收件人手機是标星不看見的。這樣的面單安全可靠，主要是保護客戶隐私，強烈推薦客戶使用，下面我們就來講解實作過程。
1.完成前期準備工作
1.1,去快遞鳥免費注冊一個對接賬号
1.2,免費獲得一個apiKey(接口權限驗證需要)
1.3,完成實名認證流程
1.4,訂購一個免費套餐
1.5,申請順豐速運月結賬号
順豐月結賬号需要線下與當地順豐分部簽訂收派合同，簽定後順豐會提供10位數字的順豐月結賬号，用于發貨結算運費；
注：快遞鳥官網背景顯示的資訊和狀态（如：“我的物流服務商”頁面不顯示順豐或順豐月結賬号）并不影響接口的使用，也不需要在背景添加要使用的客戶号，直接通過接口傳值下單即可；
1.6,準備列印機、列印紙
- 列印機：
電子面單模闆對列印機品牌、型号等沒有要求，隻要是熱敏列印機即可，常見品牌如：斑馬、得力、快麥、漢印、佳博等。
列印機可由快遞網點提供或者在淘寶京東上購買，安裝列印機及驅動程式聯系列印機提供方；
- 列印紙：
順豐速運使用的列印紙有100mm*150mm（切點90/60）、100mm*180mm（切點110/70）、100mm*210mm（切點90/60/60）三種，
列印紙可由快遞網點提供或者在淘寶京東上購買，購買時可選擇全白熱敏 紙。
2.API接口
2.1,測試調用位址：http://sandboxapi.kdniao.com:8080/kdniaosandbox/gateway/exterfaceInvoke.json
2.2,正式調用位址：http://api.kdniao.com/api/EOrderService
2.3,請求方式：POST
2.4,編碼格式(utf-8)：application/x-www-form-urlencoded;charset=utf-8
2.5,傳回類型：JSON
2.6,調試頁面：http://kdniao.com/UserCenter/v2/SandBox/TrackQuery.aspx
2.7,調試工具：去調試（使用快遞鳥賬号登入）
3.請求參數（Headers）
| 參數名稱 | 類型 | 說明 | 必須要求 |
|---|---|---|---|
| RequestData | String | 請求内容需進行URL(utf-8)編碼,請求内容JSON格式，須和DataType一緻 | 必填 |
| EBusinessID | String | 使用者ID，檢視使用者ID和ApiKey | 必填 |
| RequestType | String | 請求指令類型：1007 | 必填 |
| DataSign | String | 簽名資料，(Body+ApiKey)進行MD5加密，再進行Base64編碼，最後進行URL(utf-8)編碼 | 必填 |
| DataType | String | 求、傳回資料類型：2-json ，預設Json | 選填 |
4.請求參數（Body）
| 參數名稱 | 類型 | 說明 | 是否必須 | |
|---|---|---|---|---|
| MemberID | String（50） | ERP系統、電商平台等系統或平台類型使用者的會員ID或店鋪賬号等唯一性辨別，用于區分其使用者 | O | |
| CustomerName | String(50) | 電子面單客戶号，需要下載下傳《快遞鳥電子面單客戶号參數對照表.xlsx》，參考對應字段傳值 | O | |
| CustomerPwd | String(30) | O | ||
| SendSite | String(30) | O | ||
| SendStaff | String(30) | C | ||
| MonthCode | String | C | ||
| CustomArea | String(500) | 商家自定義區域 | C | |
| WareHouseID | String(30) | 發貨倉編碼 | O | |
| TransType | Int(1) | 運輸方式 1- 陸運 2- 空運 不填預設為1 | O | |
| ShipperCode | String(10) | 快遞公司編碼 詳細編碼參考《快遞鳥接口支援快遞公司編碼.xlsx》 | R | |
| LogisticCode | String(30) | 快遞單号(僅宅急送可用) | O | |
| ThrOrderCode | String(50) | 第三方訂單号 (ShipperCode為JD且ExpType為1時必填) | C | |
| OrderCode | String(30) | 訂單編号(自定義，不可重複) | R | |
| PayType | Int(1) | 郵費支付方式:1-現付，2-到付，3-月結，4-第三方支付(僅SF支援) | R | |
| ExpType | String(2) | 快遞類型：1-标準快件 ,詳細快遞類型參考《快遞公司快遞業務類型.xlsx》 | R | |
| IsReturnSignBill | Int(1) | 是否要求簽回單 1- 要求 0-不要求 | O | |
| OperateRequire | String(20) | 簽回單操作要求(如：簽名、蓋章、身份證影印件等) | O | |
| Cost | Cost Double(5) | 快遞運費 | O | |
| OtherCost | Double(5) | 其他費用 | O | |
| Receiver | Company | String(30) | 收件人公司 | O |
| Name | String(30) | 收件人 | R | |
| Tel | String(20) | 電話與手機，必填一個 | R | |
| Mobile | String(20) | |||
| PostCode | String(10) | 收件人郵編 | c | |
| ProvinceName | String(20) | 收件省 (如廣東省，不要缺少“省”；如是直轄市，請直接傳北京、上海等； 如是自治區，請直接傳廣西壯族自治區等) | R | |
| CityName | String（20） | 收件市(如深圳市，不要缺少“市”； 如果是市轄區，請直接傳北京市、上海市等) | R | |
| ExpAreaName | String（20） | 收件區/縣(如福田區，不要缺少“區”或“縣”) | R | |
| Address | String(100) | 收件人詳細位址 | R | |
| Sender | Company | String(30) | 發件人公司 | O |
| Name | String(30) | 發件人 | R | |
| Tel | String(20) | 電話與手機，必填一個 | R | |
| Mobile | String(20) | |||
| PostCode | String(10) | 發件地郵編(ShipperCode為EMS、YZPY、YZBK時必填) | C | |
| ProvinceName | String(20) | 發件省 (如廣東省，不要缺少“省”； 如是直轄市，請直接傳北京、上海等； 如是自治區，請直接傳廣西壯族自治區等) | R | |
| CityName | String(20) | 發件市(如深圳市，不要缺少“市； 如是市轄區，請直接傳北京市、上海市等”) | R | |
| ExpAreaName | String(20) | 發件區/縣(如福田區，不要缺少“區”或“縣”) | R | |
| Address | String(100) | 發件人詳細位址 | R | |
| IsNotice | Int(1) | 是否通知快遞員上門攬件 0- 通知 1- 不通知 不填則預設為1 | O | |
| StartDate | Date | 上門取貨時間段:"yyyy-MM-dd HH:mm:ss"格式化，本文中所有時間格式相同 | O | |
| EndDate | Date | O | ||
| Weight | Double(10,3) | 包裹總重量kg 當為快運的訂單時必填，不填時快遞鳥将根據各個快運公司要求傳對應的預設值 | C | |
| Quantity | Int(2) | 包裹數(最多支援30件) 一個包裹對應一個運單号，如果是大于1個包裹，傳回則按照子母件的方式傳回母運單号和子運單号 | R | |
| Volume | Double(20,3) | 包裹總體積m3 當為快運的訂單時必填，不填時快遞鳥将根據各個快運公司要求傳對應的預設值 | C | |
| Remark | String(60) | 備注 | O | |
| AddServices | ||||
| AddService | Name | String(20) | 增值服務名稱(數組形式，可以有多個增值服務) | C |
| Value | String(30) | 增值服務值 | C | |
| CustomerID | String(30) | 客戶辨別（選填） | O | |
| Commoditys | ||||
| Commodity | GoodsName | String(100) | 商品名稱 | R |
| GoodsCode | String(100) | 商品編碼 | O | |
| Goodsquantity | Int(5) | 商品數量 | O | |
| GoodsPrice | Double(10) | 商品價格 | O | |
| GoodsWeight | Double(10,3) | 商品重量kg | O | |
| GoodsDesc | String(50) | 商品描述 | O | |
| GoodsVol | Double(15,3) | 商品體積m3 | O | |
| IsReturnPrintTemplate | String(1) | 傳回電子面單模闆：0-不需要；1-需要 | O | |
| IsSendMessage | Int(1) | 是否訂閱短信：0-不需要；1-需要 | O | |
| TemplateSize | String(10) | 模闆規格(預設的模闆無需傳值，非預設模闆傳對應模闆尺寸) 二聯150豐密面單(TemplateSize傳值15001)三聯210豐密面單(TemplateSize傳值21001)二聯150(預設模闆，TemplateSize傳值為空)三聯210(TemplateSize傳值210)二聯180新(TemplateSize傳值180) | O | |
| PackingType | Int(2) | 包裝類型(快運字段)預設為0； 0- 紙 1- 纖 2- 木 3- 托膜 4- 木托 99-其他 | C | |
| DeliveryMethod | Int(1) | 送貨方式(快運字段)預設為0； 0- 自提 1- 送貨上門（不含上樓） 2- 送貨上樓 | C |
5.傳回參數（Return）
| 參數名稱 | 類型 | 說明 | 必須要求 | |
|---|---|---|---|---|
| EBusinessID | String(10) | 使用者ID | R | |
| Order | OrderCode | String(30) | 訂單編号 | R |
| ShipperCode | String(10) | 快遞公司編碼 | R | |
| LogisticCode | String(400) | 快遞單号 | R | |
| MarkDestination | String(20) | 大頭筆 | O | |
| OriginCode | String(20) | 始發地區域編碼 | O | |
| OriginName | String(20) | 始發地/始發網點 | O | |
| DestinatioCode | String(20) | 目的地區域編碼 | O | |
| DestinatioName | String(20) | 目的地/到達網點 | O | |
| SortingCode | String(20) | 分揀編碼 | O | |
| PackageCode | String(20) | 集包編碼 | O | |
| PackageName | String(50) | 集包地 | O | |
| DestinationAllocationCentre | String(50) | 目的地分類 | O | |
| Success | Bool(10) | 成功與否(true/false) | R | |
| SignWaybillCode | String(15) | 簽回單單号 | O | |
| ResultCode | String(5) | 傳回編碼 | R | |
| Reason | String(50) | 失敗原因 | O | |
| UniquerRequestNumber | String(50) | 唯一辨別 | R | |
| PrintTemplate | String | 面單列印模闆内容(html格式) | O | |
| EstimatedDeliveryTime | Date | 訂單預計到貨時間yyyy-mm-dd | O | |
| SubCount | Int(5) | 子單數量 | O | |
| SubOrders | String(400) | 子單單号 | O | |
| SubPrintTemplates | String(2000) | 子單模闆内容(html格式) | O | |
| SignBillPrintTemplate | String(2000) | 簽回單模闆内容(html格式) | O | |
| ReceiverSafePhone | String(20) | 收件人安全電話 | O | |
| SenderSafePhone | String(20) | 收件人安全電話 | O | |
| DialPage | String(50) | 撥号頁面網址(轉換成二維碼可掃描撥号) | O |
6.請求封包（示例）
{
"OrderCode": "012657018199",
"ShipperCode": "SF",
"PayType": 1,
"MonthCode": "1234567890",
"ExpType": 1,
"Cost": 1.0,
"OtherCost": 1.0,
"Sender": {
"Company": "LV",
"Name": "Taylor",
"Mobile": "15018442396",
"ProvinceName": "上海",
"CityName": "上海市",
"ExpAreaName": "青浦區",
"Address": "明珠路"
},
"Receiver": {
"Company": "GCCUI",
"Name": "Yann",
"Mobile": "15018442396",
"ProvinceName": "北京",
"CityName": "北京市",
"ExpAreaName": "朝陽區",
"Address": "三裡屯街道"
},
"Commodity": [
{
"GoodsName": "鞋子",
"GoodsQuantity": 1,
"GoodsWeight": 1.0
},
{
"GoodsName": "衣服",
"GoodsQuantity": 1,
"GoodsWeight": 1.0
},
],
"AddService": [
{
"Name": " INSURE ",
"Value": "1000"
},
{
"Name": "COD",
"Value": "1020"
" CustomerID ": "1234567890"
}
],
"Weight": 1.0,
"Quantity": 1,
"Volume": 0.0,
"Remark": "小心輕放"
} 複制
7.成功傳回封包（示例）
{
"EBusinessID": "1237100",
"Order": {
"OrderCode": "012657700387",
"ShipperCode": "HTKY",
"LogisticCode": "50002498503427",
"MarkDestination": "京-朝陽(京-1)",
"OriginCode": "200000",
"OriginName": "上海分撥中心",
"PackageCode": "北京"
},
"PrintTemplate":"列印模闆HTML内容後面單獨列出",
"EstimatedDeliveryTime":"2016-03-06",
"Success": true,
"ResultCode": "100",
"Reason": "成功"
} 複制
8.失敗傳回封包（示例）
{
"EBusinessID": "1237100",
"ResultCode": "106",
"Reason": "該訂單号已下單成功"，
"UniquerRequestNumber":"5e66486b-8fbc-4131-b875-9b13d2ad1354"
} 複制
9.分步講解（C#版本）
9.1，請求資料包結構
9.2,C#調用代碼示例
技術支援：QQ:510997342
//電商ID
string eEBusinessID = "test1617571";
//電商加密私鑰，快遞鳥提供，注意保管，不要洩漏
string appKey= "554343b2-7252-439b-b4eb-1af42c8f2175";
//請求url
string reqURL = "http://sandboxapi.kdniao.com:8080/kdniaosandbox/gateway/exterfaceInvoke.json";
//請求指令
string reqType="1007";
//2-json
string dataType = "2";
//字元編碼采用UTF-8
string charset = "UTF-8";
//JSON字元串string
string jsonStr =
"{
\"OrderCode\": \"012657018199\",
\"ShipperCode\": \"SF\",
\"PayType\": 1,
\"MonthCode\": \"1234567890\",
\"ExpType\": 1,
\"Cost\": 1.0,
\"OtherCost\": 1.0,
\"Sender\": {
\"Company\": \"LV\",
\"Name\": \"Taylor\",
\"Mobile\": \"15018442396\",
\"ProvinceName\": \"上海\",
\"CityName\": \"上海市\",
\"ExpAreaName\": \"青浦區\",
\"Address\": \"明珠路\"
},
\"Receiver\": {
\"Company\": \"GCCUI\",
\"Name\": \"Yann\",
\"Mobile\": \"15018442396\",
\"ProvinceName\": \"北京\",
\"CityName\": \"北京市\",
\"ExpAreaName\": \"朝陽區\",
\"Address\": \"三裡屯街道\"
},
\"Commodity\": [
{
\"GoodsName\": \"鞋子\",
\"GoodsQuantity\": 1,
\"GoodsWeight\": 1.0
},
{
\"GoodsName\": \"衣服\",
\"GoodsQuantity\": 1,
\"GoodsWeight\": 1.0
},
],
\"AddService\": [
{
\"Name\": \" INSURE \",
\"Value\": \"1000\"
},
{
\"Name\": \"COD\",
\"Value\": \"1020\"
\" CustomerID \": \"1234567890\"
}
],
\"Weight\": 1.0,
\"Quantity\": 1,
\"Volume\": 0.0,
\"Remark\": \"小心輕放\"
}" ;
//把(jsonStr+APIKey)進行MD5加密
string md5Str=MD5(jsonStr + apiKey, charset);
//把md5Str 進行Base64編碼
string base64Str=base64(md5Str,charset);
//進行URL編碼 (utf-8)
string datasign = HttpUtility.UrlEncode(base64Str, charset);
//請求封包參數
string postStr = "RequestType=reqType&EBusinessID= eEBusinessID&RequestData=jsonStr
&DataSign= datasign&DataType=dataType";
//通訊協定使用Http協定Post請求方式 傳回軌迹資料
string post = SendPost(reqURL, postStr);
//擷取到的post資料就是快遞鳥傳回的完整封包，接下來自己寫一個解析json的方法就能擷取到裡面的字段資訊。 複制
9.3,C#調用方法
///<summary>
/// 字元串MD5加密
///</summary>
///<param name="str">要加密的字元串</param>
///<param name="charset">編碼方式</param>
///<returns>密文</returns>
private string MD5(string str, string charset)
{
byte[] buffer = System.Text.Encoding.GetEncoding(charset).GetBytes(str);
try
{
System.Security.Cryptography.MD5CryptoServiceProvider check;
check = new System.Security.Cryptography.MD5CryptoServiceProvider();
byte[] somme = check.ComputeHash(buffer);
string ret = "";
foreach (byte a in somme)
{
if (a < 16)
ret += "0" + a.ToString("X");
else
ret += a.ToString("X");
}
return ret.ToLower();
}
catch
{
throw;
}
}
/// <summary>
/// base64編碼
/// </summary>
/// <param name="str">内容</param>
/// <param name="charset">編碼方式</param>
/// <returns></returns>
private string base64(String str, String charset)
{
return Convert.ToBase64String(System.Text.Encoding.GetEncoding(charset).GetBytes(str));
}
/// <summary>
/// Post方式送出資料，傳回網頁的源代碼
/// </summary>
/// <param name="url">發送請求的 URL</param>
/// <param name="postData">請求封包參數</param>
/// <returns>遠端資源的響應結果</returns>
private string SendPost(string url, string postData)
{
string result = "";
byte[] byteData = Encoding.GetEncoding("UTF-8").GetBytes(postData.ToString());
try
{
HttpWebRequest request = (HttpWebRequest)WebRequest.Create(url);
request.ContentType = "application/x-www-form-urlencoded";
request.Referer = url;
request.Accept = "*/*";
request.Timeout = 30 * 1000;
request.UserAgent = "Mozilla/4.0 (compatible; MSIE 6.0; Windows NT 5.1; SV1; .NET CLR 2.0.50727; .NET CLR 3.0.04506.648; .NET CLR 3.0.4506.2152;
.NET CLR 3.5.30729)";
request.Method = "POST";
request.ContentLength = byteData.Length;
Stream stream = request.GetRequestStream();
stream.Write(byteData, 0, byteData.Length);
stream.Flush();
stream.Close();
HttpWebResponse response = (HttpWebResponse)request.GetResponse();
Stream backStream = response.GetResponseStream();
StreamReader sr = new StreamReader(backStream, Encoding.GetEncoding("UTF-8"));
result = sr.ReadToEnd();
sr.Close();
backStream.Close();
response.Close();
request.Abort();
}
catch (Exception ex)
{
result = ex.ToString();
}
return result;
} 複制
10.順豐電子面單列印模闆内容（HTML）
<!DOCTYPE html>
<html lang="zh-CN">
<!--100*150,90-->
<head>
<meta charset="UTF-8">
<style>
* {
margin: 0;
padding: 0;
font-family: "simsun";
}
.print_paper {
font-size: 14px;
border: none;
border-collapse: collapse;
width: 375px;
margin-top: -1px;
table-layout: fixed;
}
.print_paper td {
border: solid #000 1px;
padding: 0 5px;
}
.table_first {
margin-top: 0;
}
.print_paper .x1 {
font-size: 32px;
font-weight: bold;
text-align: center;
letter-spacing: 5px;
line-height: 0.95;
font-family: "Microsoft YaHei";
}
.print_paper .x4 {
font-size: 20px;
font-weight: bold;
font-family: "Microsoft YaHei";
}
.print_paper .xx8 {
font-size: 8px;
line-height: 0.8;
}
.print_paper .xx10 {
font-size: 10px;
}
.print_paper .xx12 {
font-size: 12px;
font-weight: bold;
}
.print_paper .xx14 {
font-size: 14px;
font-weight: bold;
font-family: "SimHei";
}
.print_paper .xx16 {
font-size: 16px;
font-weight: bold;
font-family: "Microsoft YaHei";
}
.print_paper .xx48 {
font-size: 40px;
font-weight: bold;
text-align: center;
font-family: "Microsoft YaHei";
}
.no_border {
width: 100%;
height: 100%;
font-size: 14px;
}
.no_border td {
border: none;
vertical-align: top;
}
.print_paper .fwb {
font-weight: bold;
}
.print_paper .f24 {
font-family: "Arial";
font-size: 24pt;
}
.print_paper .f20 {
font-family: "Arial";
font-size: 20pt;
}
.print_paper .p0 {
padding: 0;
}
/*增加類*/
.print_paper .p0 .sp {
position: absolute;
left: 3px;
top: 110px;
}
.print_paper .ovh {
overflow: hidden;
}
.print_paper .ov {
overflow: visible;
}
.print_paper .f10 {
font-size: 10px;
}
.print_paper .f13 {
font-size: 13px;
}
.print_paper .bln {
border-left: none;
}
.print_paper .brn {
border-right: none;
}
</style>
</head>
<body>
<table class="print_paper table_first">
<tr height="53">
<td>
<table class="no_border">
<tr>
<td style="vertical-align: middle;">
<img class="logo" height="35" alt=""
</td>
<td style="vertical-align: middle;" colspan="2">
<!-- -->
<div class="f20"
style="font-weight: bold;">
</div>
</td>
<!--<td style="vertical-align:middle;"> </td>-->
<td style="vertical-align: middle; text-align: right; position: absolute; left: 264px">
<img height="35" class="phone" alt=""
</td>
</tr>
</table>
</td>
</tr>
</table>
<table class="print_paper">
<tr height="65">
<td class="p0" width="249" style="text-align: center;">
<img width="249px"
style="font-size: 11px;display: none">1 / 1</span>
<br />
<div style="font-size: 11px; font-weight: bold;">
<span style="display: none">子單号 555555555<br />母單号 888888888888</span>
<span style="display: block;margin-top: 3px;">運單号 5622033142418</span>
<span style="display: none;margin-top: 10px;">簽回單号 3552033142418</span>
</div>
</td>
<td class="xx16 p0">
<div style="height: 74px;">
順豐标快 <br /> <span class="xx10">目的地：</span>
<div class="f24">010</div>
</div>
</td>
</tr>
</table>
<table class="print_paper" height="50">
<tr>
<td width="50" style="padding: 0;" class="xx16 brn">收方:</td>
<td class="bln">
<div style="height: 59px; overflow: hidden;">
北京北京市朝陽區******<br />
<span style="width: 297px;display: inline-block;">楊** 1590****89</span>
</div>
</td>
</tr>
</table>
<table class="print_paper" height="58">
<tr>
<td rowspan="2" style="vertical-align: top;" class="f13">
月結帳号：3434555 <br /> 支付方式：寄付月結 <br />
<div style="display: none">聲明價值：0</div>
<div style="display: none">簽單傳回單号：${SignWaybillCode}</div>
<div style="display: none">操作要求：${OperateRequire}</div>
</td>
<td height="45">
代收貨款：￥0元<br />卡号：
</td>
</tr>
<tr>
<td>
運費：-<br />費用合計：-
</td>
</tr>
</table>
<table class="print_paper" height="68" width="100%">
<tr>
<td class="xx14 brn" width="50" style="padding: 0; ">
寄方:
</td>
<td class="ov bln" style="width: 136px;">
<div class="xx10" style="width: 115px; height: 66px;">
<div style="height: 40px; overflow: hidden">
廣東省東莞市清溪鎮******
</div>
<div style="width: 140px;overflow: hidden;">
<span style="width: 52px;display: inline-block;">鞋襪廠</span>13288****80
</div>
<div class="xx10" style="margin-left: -45px; position: absolute;top: 337px;">原寄地：339</div>
</div>
</td>
<td class="xx10" width="86">
收件員：<br />寄件日期：2020-02-05 11:34:24
</td>
<td class="xx10">
收方簽署:<br /> <br />日期：
</td>
</tr>
</table>
<table class="print_paper table_first" height="60">
<tr height="55">
<td>
<img class="logo" height="30"
alt="" /> <img class="phone" height="30"
alt="" />
</td>
<td style="text-align: center;">
<span style="display: none">子單号 234234234</span>
<span style="display: block">234234</span>
<span style="display: none">243234324</span>
</td>
</tr>
</table>
<table class="print_paper ">
<tr height="76">
<td class="brn" style="padding: 0; width: 16px;">
寄<br />方:
</td>
<td class="xx10 bln">
<div style="height: 67px; overflow: hidden;">
廣東省東莞市清溪鎮******<br />
<span style="width: 164px;display: inline-block;">
<span style="width: 52px;display: inline-block;">鞋襪廠</span>13288****80
</span>
</div>
</td>
<td style="padding: 0; width: 16px;" class="fwb brn">
收<br />方:
</td>
<td class="xx10 bln">
<div style="height: 67px; overflow: hidden">
北京北京市朝陽區******<br />
<span style="width: 164px;display: inline-block;">
<span style="width: 52px;display: inline-block;">楊**</span>1590****89
</span>
</div>
</td>
</tr>
</table>
<table class="print_paper">
<tr height="18">
<td width="36" style="padding: 0; text-align: center;">數量</td>
<td width="254" style="padding: 0; text-align: center;">托寄物</td>
<td style="padding: 0; text-align: center;">備注</td>
</tr>
<tr height="34">
<td> </td>
<td>嬰兒用品</td>
<td>
<div class="f10 ovh" style="height: 33px"></div>
</td>
</tr>
<tr height="40">
<td colspan="2">
<table class="no_border">
<tr>
<td>訂單号</td>
<td class="xx14"
style="vertical-align: middle; text-align: center;">
<br />2355334314
</td>
</tr>
</table>
</td>
<td style="text-align: center;">
費用合計：<br />- 元
</td>
</tr>
</table>
</body>
</html> 複制
複制以上HTML内容儲存為html格式的檔案，可以檢視模闆效果。
11.關于簽名
快遞鳥和第三方電子商務公司系統進行對接，有一定的安全機制。采用 IP 認證加簽名
的方式對接，具體方案如下：
防止資料被篡改
在 POST 請求中會傳遞 5 個必須(R)參數
RequestData==資料内容(URL 編碼:UTF-8)
EBusinessID==使用者 ID
RequestType=請求指令類型
DataSign== 資料内容簽名：把(請求内容(未編碼)+ApiKey)進行 MD5 加密，然後 Base64
編碼，最後進行 URL(utf-8)編碼
DataType==2(傳回資料類型為 json)
注：
DataSign 生成後，對方接收到資料後，以同樣的算法進行簽名(推送接口 RequestType 為
101/102 不需要進行 URL 編碼)，生成摘要，對比兩者的摘要是否相同，如果不同，說明傳遞過程中發生資料篡改。
調用接口的身份認證
注冊成為快遞鳥使用者後，會生成對應的使用者 ID 和 APIKey，使用者 ID 相當于使用者名，
APIKey 相當于密碼。
複制
