PostgreSQL 誰堵塞了誰（鎖等待檢測）- pg_blocking_pids, pg_safe_snapshot_blocking_pids

标簽

PostgreSQL , 鎖等待 , 隊列

https://github.com/digoal/blog/blob/master/201902/20190201_02.md#%E8%83%8C%E6%99%AF 背景

當一個程序處于等待（被堵塞）狀态時，是誰幹的？可以使用如下函數，快速得到搗蛋（堵塞别人）的PID。

1、請求鎖時被堵，是哪些PID堵的?

pg_blocking_pids(int)	int[]	Process ID(s) that are blocking specified server process ID from acquiring a lock


2、請求safe快照時被堵(SSI隔離級别，請求安全快照沖突)，是哪些PID堵的?

pg_safe_snapshot_blocking_pids(int)	int[]	Process ID(s) that are blocking specified server process ID from acquiring a safe snapshot


https://github.com/digoal/blog/blob/master/201902/20190201_02.md#%E4%BE%8B%E5%AD%90 例子

1、會話1

postgres=# begin;
BEGIN
postgres=# select * from tbl limit 1;
   id   | c1 | c2
--------+----+----
 918943 |  1 |  0
(1 row)

postgres=# select pg_backend_pid();
 pg_backend_pid
----------------
          30862
(1 row)


2、會話2

postgres=# begin;
BEGIN
postgres=# select pg_backend_pid();
 pg_backend_pid
----------------
          30928
(1 row)

postgres=# truncate tbl;

等待中


3、會話3

postgres=# begin;
BEGIN
postgres=# select pg_backend_pid();
 pg_backend_pid
----------------
          30936
(1 row)

postgres=# select * from tbl limit 1;

等待中


4、會話4

postgres=# select pg_backend_pid();
 pg_backend_pid
----------------
          30999
(1 row)

postgres=# select * from tbl limit 1;

等待中


5、檢視搗蛋PID

postgres=# select pid,pg_blocking_pids(pid),wait_event_type,wait_event,query from pg_stat_activity ;
  pid  | pg_blocking_pids | wait_event_type |     wait_event      |                                           query
-------+------------------+-----------------+---------------------+-------------------------------------------------------------------------------------------
 30862 | {}               | Client          | ClientRead          | select pg_backend_pid();
 30928 | {30862}          | Lock            | relation            | truncate tbl;
 30936 | {30928}          | Lock            | relation            | select * from tbl limit 1;
 30999 | {30928}          | Lock            | relation            | select * from tbl limit 1;


https://github.com/digoal/blog/blob/master/201902/20190201_02.md#%E4%BB%A3%E7%A0%81 代碼

src/backend/utils/adt/lockfuncs.c

/*
 * pg_blocking_pids - produce an array of the PIDs blocking given PID
 *
 * The reported PIDs are those that hold a lock conflicting with blocked_pid's
 * current request (hard block), or are requesting such a lock and are ahead
 * of blocked_pid in the lock's wait queue (soft block).
 *
 * In parallel-query cases, we report all PIDs blocking any member of the
 * given PID's lock group, and the reported PIDs are those of the blocking
 * PIDs' lock group leaders.  This allows callers to compare the result to
 * lists of clients' pg_backend_pid() results even during a parallel query.
 *
 * Parallel query makes it possible for there to be duplicate PIDs in the
 * result (either because multiple waiters are blocked by same PID, or
 * because multiple blockers have same group leader PID).  We do not bother
 * to eliminate such duplicates from the result.
 *
 * We need not consider predicate locks here, since those don't block anything.
 */
Datum
pg_blocking_pids(PG_FUNCTION_ARGS)
{


...............

/*
 * pg_safe_snapshot_blocking_pids - produce an array of the PIDs blocking
 * given PID from getting a safe snapshot
 *
 * XXX this does not consider parallel-query cases; not clear how big a
 * problem that is in practice
 */
Datum
pg_safe_snapshot_blocking_pids(PG_FUNCTION_ARGS)
{
...........


src/backend/storage/lmgr/predicate.c

/*
 * GetSafeSnapshotBlockingPids
 *              If the specified process is currently blocked in GetSafeSnapshot,
 *              write the process IDs of all processes that it is blocked by
 *              into the caller-supplied buffer output[].  The list is truncated at
 *              output_size, and the number of PIDs written into the buffer is
 *              returned.  Returns zero if the given PID is not currently blocked
 *              in GetSafeSnapshot.
 */
int
GetSafeSnapshotBlockingPids(int blocked_pid, int *output, int output_size)
{
        int                     num_written = 0;
        SERIALIZABLEXACT *sxact;

        LWLockAcquire(SerializableXactHashLock, LW_SHARED);

        /* Find blocked_pid's SERIALIZABLEXACT by linear search. */
        for (sxact = FirstPredXact(); sxact != NULL; sxact = NextPredXact(sxact))
        {
                if (sxact->pid == blocked_pid)
                        break;
        }

        /* Did we find it, and is it currently waiting in GetSafeSnapshot? */
        if (sxact != NULL && SxactIsDeferrableWaiting(sxact))
        {
                RWConflict      possibleUnsafeConflict;

                /* Traverse the list of possible unsafe conflicts collecting PIDs. */
                possibleUnsafeConflict = (RWConflict)
                        SHMQueueNext(&sxact->possibleUnsafeConflicts,
                                                 &sxact->possibleUnsafeConflicts,
                                                 offsetof(RWConflictData, inLink));

                while (possibleUnsafeConflict != NULL && num_written < output_size)
                {
                        output[num_written++] = possibleUnsafeConflict->sxactOut->pid;
                        possibleUnsafeConflict = (RWConflict)
                                SHMQueueNext(&sxact->possibleUnsafeConflicts,
                                                         &possibleUnsafeConflict->inLink,
                                                         offsetof(RWConflictData, inLink));
                }
        }

        LWLockRelease(SerializableXactHashLock);

        return num_written;
}


https://github.com/digoal/blog/blob/master/201902/20190201_02.md#%E5%8F%82%E8%80%83 參考

https://www.postgresql.org/docs/11/functions-info.html 《PostgreSQL 鎖等待排查實踐 - 珍藏級 - process xxx1 acquired RowExclusiveLock on relation xxx2 of database xxx3 after xxx4 ms at xxx》 《PostgreSQL 鎖等待監控 珍藏級SQL - 誰堵塞了誰》 《PostgreSQL 鎖等待跟蹤》
