PostgreSQL 大寬表，全列索引，高并發合并寫入(insert into on conflict, upsert, merge insert) - 實時adhoc query

标簽

PostgreSQL , 全列索引 , 大寬表 , 寫測試 , insert on conflict , upsert , merge insert , adhoc query

https://github.com/digoal/blog/blob/master/201901/20190112_01.md#%E8%83%8C%E6%99%AF 背景

OLAP系統中，adhoc query非常場景（任意次元查詢分析）。

adhoc query，通常來說，可以加GIN倒排，或者每一列都加一個索引來實作。

《PostgreSQL 設計優化case - 大寬表任意字段組合查詢索引如何選擇(btree, gin, rum) - (含單個索引列數超過32列的方法)》

加索引和不加索引，實時的upsert(有則更新，無則寫入)，性能差别如何呢？每列都有索引時是否可以支撐實時的合并寫入呢？

https://github.com/digoal/blog/blob/master/201901/20190112_01.md#%E6%B5%8B%E8%AF%95 測試

測試資料upsert合并寫入

https://github.com/digoal/blog/blob/master/201901/20190112_01.md#100%E4%B8%AA%E5%AD%97%E6%AE%B5%E4%B8%8D%E5%90%AB%E7%B4%A2%E5%BC%95 100個字段不含索引

do language plpgsql $$
declare
  sql text := 'create table tbl_test1( id int primary key,';
begin
  for i in 1..100 loop
    sql := sql||' c'||i||' int default random()*10000000,';
  end loop;
  sql := rtrim(sql,',');
  sql := sql || ')';
  execute sql;
end;
$$;


vi test1.sql
\set id random(1,100000000)
\set c1 random(1,20000)
insert into tbl_test1 (id, c1) values (:id,:c1) on conflict(id) do update set c1=excluded.c1;


pgbench -M prepared -n -r -P 1 -f ./test1.sql -c 32 -j 32 -T 120

transaction type: ./test1.sql
scaling factor: 1
query mode: prepared
number of clients: 32
number of threads: 32
duration: 120 s
number of transactions actually processed: 14433112
latency average = 0.266 ms
latency stddev = 3.919 ms
tps = 120275.287837 (including connections establishing)
tps = 120303.256409 (excluding connections establishing)
statement latencies in milliseconds:
         0.001  \set id random(1,100000000)
         0.000  \set c1 random(1,20000)
         0.265  insert into tbl_test1 (id, c1) values (:id,:c1) on conflict(id) do update set c1=excluded.c1;


https://github.com/digoal/blog/blob/master/201901/20190112_01.md#100%E4%B8%AA%E5%AD%97%E6%AE%B5%E5%90%AB%E7%B4%A2%E5%BC%95 100個字段含索引

do language plpgsql $$
declare
  sql text := 'create table tbl_test2( id int primary key,';
begin
  for i in 1..100 loop
    sql := sql||' c'||i||' int default random()*10000000,';
  end loop;
  sql := rtrim(sql,',');
  sql := sql || ')';
  execute sql;
  for i in 1..100 loop
    execute 'create index idx_tbl_test2_'||i||' on tbl_test2 (c'||i||')';
  end loop;
end;
$$;


vi test2.sql
\set id random(1,100000000)
\set c1 random(1,20000)
insert into tbl_test2 (id, c1) values (:id,:c1) on conflict(id) do update set c1=excluded.c1;


pgbench -M prepared -n -r -P 1 -f ./test2.sql -c 32 -j 32 -T 120




https://github.com/digoal/blog/blob/master/201901/20190112_01.md#%E5%88%86%E5%8C%BA%E8%A1%A8%E5%A4%A7%E5%AE%BD%E8%A1%A8%E5%85%A8%E7%B4%A2%E5%BC%95%E6%B5%8B%E8%AF%95 分區表大寬表，全索引測試

do language plpgsql $$
declare
  sql text := 'create table tbl_test3(sid int, id int,';
begin
  for i in 1..100 loop
    sql := sql||' c'||i||' int default random()*10000000,';
  end loop;
  sql := rtrim(sql,',');
  sql := sql || ') partition by list (sid)';
  execute sql;
end;
$$;

建立索引和唯一限制

alter table tbl_test3 add constraint uk_tbl_test3 unique (sid,id);

do language plpgsql $$
declare
begin
  for i in 1..100 loop
    execute 'create index idx_tbl_test3_'||i||' on tbl_test3 (c'||i||')';
  end loop;
end;
$$;

建立分區

do language plpgsql $$
declare
begin
  for sid in 1..60 loop
    execute format('create table tbl_test3_%s partition of tbl_test3 for values in (%s)', sid, sid);
  end loop;
end;
$$;

合并寫的文法

insert into tbl_test3 values (1,1)
on conflict (sid,id)
do update
set c1=excluded.c1;

create or replace function upsert_tbl_test3 (v_sid int, v_id int) returns void as $$
declare

begin
  execute format('execute p_%s (%s, %s)', v_sid, v_sid, v_id);
  exception when others then
    execute format('prepare p_%s (int,int) as insert into tbl_test3_%s(sid,id) values ($1,$2) on conflict (sid,id) do update set c1=excluded.c1', v_sid, v_sid);
    execute format('execute p_%s (%s, %s)', v_sid, v_sid, v_id);
end;
$$ language plpgsql strict;


vi test.sql
\set id random(1,2000000000)
\set sid random(1,60)
select upsert_tbl_test3(:sid,:id);

pgbench -M prepared -n -r -P 1 -f ./test.sql -c 28 -j 28 -T 120


優化

《PostgreSQL 分區表如何支援多列唯一 - 枚舉、hash哈希 分區, 多列唯一, insert into on conflict, update, upsert, merge insert》

https://github.com/digoal/blog/blob/master/201901/20190112_01.md#%E6%80%A7%E8%83%BD%E5%AF%B9%E6%AF%94 性能對比

場景	合并寫入QPS
1個索引	120303
101個索引	19485

小結：

1、瓶頸分析，多個索引時，注意瓶頸在索引的RT上面，為提升性能，可以使用分區表，将RT打平，提升整體寫入吞吐。

2、頻繁更新可能導緻索引膨脹，如果發現索引膨脹嚴重，在空閑期間需要對索引進行rebuild操作（是一樣concurrently并發建立，不影響DML）。

《PostgreSQL CREATE INDEX CONCURRENTLY 的原理以及哪些操作可能堵塞索引的建立》 《PostgreSQL 垃圾回收原理以及如何預防膨脹 - How to prevent object bloat in PostgreSQL》

https://github.com/digoal/blog/blob/master/201901/20190112_01.md#%E5%8F%82%E8%80%83 參考

《PostgreSQL 快速給指定表每個字段建立索引 - 2 (近乎完美)》 《PostgreSQL 快速給指定表每個字段建立索引 - 1 (不夠完美)》
