Apache Flink 零基礎入門（四）：用戶端操作的 5 種模式1.環境說明2.課程概要3.Flink 用戶端操作4.結束

作者：周凱波

1.環境說明

在前面幾期的課程裡面講過了

Flink 開發環境的搭建和應用的部署以及運作

，今天的課程主要是講 Flink 的用戶端操作。本次講解以實際操作為主。這次課程是基于社群的 Flink 1.7.2 版本，作業系統是 Mac 系統，浏覽器是 Google Chrome 浏覽器。有關開發環境的準備和叢集的部署，請參考「

開發環境搭建和應用的配置、部署及運作

」的内容。

2.課程概要

如下圖所示，Flink 提供了豐富的用戶端操作來送出任務和與任務進行互動，包括 Flink 指令行，Scala Shell，SQL Client，Restful API 和 Web。Flink 首先提供的最重要的是指令行，其次是 SQL Client 用于送出 SQL 任務的運作，還有就是 Scala Shell 送出 Table API 的任務。同時，Flink 也提供了Restful 服務，使用者可以通過 http 方式進行調用。此外，還有 Web 的方式可以送出任務。

在 Flink 安裝目錄的 bin 目錄下面可以看到有 flink, start-scala-shell.sh 和 sql-client.sh 等檔案，這些都是用戶端操作的入口。

3.Flink 用戶端操作

3.1 Flink 指令行

Flink 的指令行參數很多，輸入 flink - h 能看到完整的說明：

flink-1.7.2 bin/flink -h

如果想看某一個指令的參數，比如 Run 指令，輸入：

flink-1.7.2 bin/flink run -h

本文主要講解常見的一些操作，更詳細的文檔請參考:

Flink 指令行官方文檔

。

3.1.1 Standalone

首先啟動一個 Standalone 的叢集：

flink-1.7.2 bin/start-cluster.sh
Starting cluster.
Starting standalonesession daemon on host zkb-MBP.local.
Starting taskexecutor daemon on host zkb-MBP.local.

打開

http://127.0.0.1:8081

能看到 Web 界面。

Run

運作任務，以 Flink 自帶的例子 TopSpeedWindowing 為例：

flink-1.7.2 bin/flink run -d examples/streaming/TopSpeedWindowing.jar
Starting execution of program
Executing TopSpeedWindowing example with default input data set.
Use --input to specify file input.
Printing result to stdout. Use --output to specify output path.
Job has been submitted with JobID 5e20cb6b0f357591171dfcca2eea09de

運作起來後預設是 1 個并發:

點左側「Task Manager」，然後點「Stdout」能看到輸出日志：

或者檢視本地 Log 目錄下的 *.out 檔案：

List

檢視任務清單：

flink-1.7.2 bin/flink list -m 127.0.0.1:8081
Waiting for response...
------------------ Running/Restarting Jobs -------------------
24.03.2019 10:14:06 : 5e20cb6b0f357591171dfcca2eea09de : CarTopSpeedWindowingExample (RUNNING)
--------------------------------------------------------------
No scheduled jobs.

Stop

停止任務。通過 -m 來指定要停止的 JobManager 的主機位址和端口。

flink-1.7.2 bin/flink stop -m 127.0.0.1:8081 d67420e52bd051fae2fddbaa79e046bb
Stopping job d67420e52bd051fae2fddbaa79e046bb.
------------------------------------------------------------
The program finished with the following exception:
  org.apache.flink.util.FlinkException: Could not stop the job   d67420e52bd051fae2fddbaa79e046bb.
  at org.apache.flink.client.cli.CliFrontend.lambda$stop$5(CliFrontend.java:554)
  at org.apache.flink.client.cli.CliFrontend.runClusterAction(CliFrontend.java:985)
  at org.apache.flink.client.cli.CliFrontend.stop(CliFrontend.java:547)
  at org.apache.flink.client.cli.CliFrontend.parseParameters(CliFrontend.java:1062)
  at org.apache.flink.client.cli.CliFrontend.lambda$main$11(CliFrontend.java:1126)
  at java.security.AccessController.doPrivileged(Native Method)
  at javax.security.auth.Subject.doAs(Subject.java:422)
  at org.apache.hadoop.security.UserGroupInformation.doAs(UserGroupInformation.java:1836)
  at org.apache.flink.runtime.security.HadoopSecurityContext.runSecured(HadoopSecurityContext.java:41)
  at org.apache.flink.client.cli.CliFrontend.main(CliFrontend.java:1126)
Caused by: java.util.concurrent.ExecutionException: org.apache.flink.runtime.rest.util.RestClientException: [Job termination (STOP) failed: This job is not stoppable.]
  at java.util.concurrent.CompletableFuture.reportGet(CompletableFuture.java:357)
  at java.util.concurrent.CompletableFuture.get(CompletableFuture.java:1915)
  at org.apache.flink.client.program.rest.RestClusterClient.stop(RestClusterClient.java:392)
  at org.apache.flink.client.cli.CliFrontend.lambda$stop$5(CliFrontend.java:552)
... 9 more
Caused by: org.apache.flink.runtime.rest.util.RestClientException: [Job termination (STOP) failed: This job is not stoppable.]
  at org.apache.flink.runtime.rest.RestClient.parseResponse(RestClient.java:380)
  at org.apache.flink.runtime.rest.RestClient.lambda$submitRequest$3(RestClient.java:364)
  at java.util.concurrent.CompletableFuture.uniCompose(CompletableFuture.java:952)
  at java.util.concurrent.CompletableFuture$UniCompose.tryFire(CompletableFuture.java:926)
  at java.util.concurrent.CompletableFuture$Completion.run(CompletableFuture.java:442)
  at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1149)
  at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:624)
  at java.lang.Thread.run(Thread.java:748)

從日志裡面能看出 Stop 指令執行失敗了。一個 Job 能夠被 Stop 要求所有的 Source 都是可以 Stoppable 的，即實作了 StoppableFunction 接口。

/**
 * 需要能 stoppable 的函數必須實作這個接口，例如流式任務的 source。
 * stop() 方法在任務收到 STOP 信号的時候調用。
 * source 在接收到這個信号後，必須停止發送新的資料且優雅的停止。
 */
@PublicEvolving
public interface StoppableFunction {
    /**
      * 停止 source。與 cancel() 不同的是，這是一個讓 source 優雅停止的請求。
     * 等待中的資料可以繼續發送出去，不需要立即停止。
      */
    void stop();
}

Cancel

取消任務。如果在 conf/flink-conf.yaml 裡面配置了 state.savepoints.dir，會儲存 Savepoint，否則不會儲存 Savepoint。

flink-1.7.2 bin/flink cancel -m 127.0.0.1:8081 5e20cb6b0f357591171dfcca2eea09de

Cancelling job 5e20cb6b0f357591171dfcca2eea09de.
Cancelled job 5e20cb6b0f357591171dfcca2eea09de.

也可以在停止的時候顯示指定 Savepoint 目錄。

flink-1.7.2 bin/flink cancel -m 127.0.0.1:8081 -s /tmp/savepoint 29da945b99dea6547c3fbafd57ed8759

Cancelling job 29da945b99dea6547c3fbafd57ed8759 with savepoint to /tmp/savepoint.
Cancelled job 29da945b99dea6547c3fbafd57ed8759. Savepoint stored in file:/tmp/savepoint/savepoint-29da94-88299bacafb7.

  flink-1.7.2 ll /tmp/savepoint/savepoint-29da94-88299bacafb7
total 32K
-rw-r--r-- 1 baoniu 29K Mar 24 10:33 _metadata

取消和停止（流作業）的差別如下：

  • cancel() 調用，立即調用作業算子的 cancel() 方法，以盡快取消它們。如果算子在接到 cancel() 調用後沒有停止，Flink 将開始定期中斷算子線程的執行，直到所有算子停止為止。
  • stop() 調用，是更優雅的停止正在運作流作業的方式。stop() 僅适用于 Source 實作了 StoppableFunction 接口的作業。當使用者請求停止作業時，作業的所有 Source 都将接收 stop() 方法調用。直到所有 Source 正常關閉時，作業才會正常結束。這種方式，使作業正常處理完所有作業。

Savepoint

觸發 Savepoint。

flink-1.7.2 bin/flink savepoint -m 127.0.0.1:8081 ec53edcfaeb96b2a5dadbfbe5ff62bbb /tmp/savepoint
Triggering savepoint for job ec53edcfaeb96b2a5dadbfbe5ff62bbb.
Waiting for response...
Savepoint completed. Path: file:/tmp/savepoint/savepoint-ec53ed-84b00ce500ee
You can resume your program from this savepoint with the run command.

說明：Savepoint 和 Checkpoint 的差別（

詳見文檔

）：

  • Checkpoint 是增量做的，每次的時間較短，資料量較小，隻要在程式裡面啟用後會自動觸發，使用者無須感覺；Checkpoint 是作業 failover 的時候自動使用，不需要使用者指定。
  • Savepoint 是全量做的，每次的時間較長，資料量較大，需要使用者主動去觸發。Savepoint 一般用于程式的版本更新（ ），Bug 修複，A/B Test 等場景，需要使用者指定。

通過 -s 參數從指定的 Savepoint 啟動：

flink-1.7.2 bin/flink run -d -s /tmp/savepoint/savepoint-f049ff-24ec0d3e0dc7 ./examples/streaming/TopSpeedWindowing.jar
Starting execution of program
Executing TopSpeedWindowing example with default input data set.
Use --input to specify file input.
Printing result to stdout. Use --output to specify output path.

檢視 JobManager 的日志，能夠看到類似這樣的 Log：

2019-03-28 10:30:53,957 INFO  org.apache.flink.runtime.checkpoint.CheckpointCoordinator
- Starting job 790d7b98db6f6af55d04aec1d773852d from savepoint /tmp/savepoint/savepoint-f049ff-24ec0d3e0dc7 ()
2019-03-28 10:30:53,959 INFO  org.apache.flink.runtime.checkpoint.CheckpointCoordinator
 - Reset the checkpoint ID of job 790d7b98db6f6af55d04aec1d773852d to 2.
2019-03-28 10:30:53,959 INFO  org.apache.flink.runtime.checkpoint.CheckpointCoordinator
- Restoring job 790d7b98db6f6af55d04aec1d773852d from latest valid checkpoint: Checkpoint 1 @ 0 for 790d7b98db6f6af55d04aec1d773852d.

Modify

修改任務并行度。

為了友善示範，我們修改 conf/flink-conf.yaml 将 Task Slot 數從預設的 1 改為 4，并配置 Savepoint 目錄。（Modify 參數後面接 -s 指定 Savepoint 路徑目前版本可能有 Bug，提示無法識别）

taskmanager.numberOfTaskSlots: 4
state.savepoints.dir: file:///tmp/savepoint

修改參數後需要重新開機叢集生效，然後再啟動任務：

flink-1.7.2 bin/stop-cluster.sh && bin/start-cluster.sh
Stopping taskexecutor daemon (pid: 53139) on host zkb-MBP.local.
Stopping standalonesession daemon (pid: 52723) on host zkb-MBP.local.
Starting cluster.
Starting standalonesession daemon on host zkb-MBP.local.
Starting taskexecutor daemon on host zkb-MBP.local.

  flink-1.7.2 bin/flink run -d examples/streaming/TopSpeedWindowing.jar
Starting execution of program
Executing TopSpeedWindowing example with default input data set.
Use --input to specify file input.
Printing result to stdout. Use --output to specify output path.
Job has been submitted with JobID 7752ea7b0e7303c780de9d86a5ded3fa

從頁面上能看到 Task Slot 變為了 4，這時候任務的預設并發度是 1。

通過 Modify 指令依次将并發度修改為 4 和 3，可以看到每次 Modify 指令都會觸發一次 Savepoint。

flink-1.7.2 bin/flink modify -p 4 7752ea7b0e7303c780de9d86a5ded3fa
Modify job 7752ea7b0e7303c780de9d86a5ded3fa.
Rescaled job 7752ea7b0e7303c780de9d86a5ded3fa. Its new parallelism is 4.

  flink-1.7.2 ll /tmp/savepoint
total 0
drwxr-xr-x 3 baoniu 96 Jun 17 09:05 savepoint-7752ea-00c05b015836/

  flink-1.7.2 bin/flink modify -p 3 7752ea7b0e7303c780de9d86a5ded3fa
Modify job 7752ea7b0e7303c780de9d86a5ded3fa.
Rescaled job 7752ea7b0e7303c780de9d86a5ded3fa. Its new parallelism is 3.

  flink-1.7.2 ll /tmp/savepoint
total 0
drwxr-xr-x 3 baoniu 96 Jun 17 09:08 savepoint-7752ea-449b131b2bd4/

檢視 JobManager 的日志，可以看到：

2019-06-17 09:05:11,179 INFO  org.apache.flink.runtime.checkpoint.CheckpointCoordinator     - Starting job 7752ea7b0e7303c780de9d86a5ded3fa from savepoint file:/tmp/savepoint/savepoint-790d7b-3581698f007e ()
2019-06-17 09:05:11,182 INFO  org.apache.flink.runtime.checkpoint.CheckpointCoordinator     - Reset the checkpoint ID of job 7752ea7b0e7303c780de9d86a5ded3fa to 3.
2019-06-17 09:05:11,182 INFO  org.apache.flink.runtime.checkpoint.CheckpointCoordinator     - Restoring job 790d7b98db6f6af55d04aec1d773852d from latest valid checkpoint: Checkpoint 2 @ 0 for 7752ea7b0e7303c780de9d86a5ded3fa.
2019-06-17 09:05:11,184 INFO  org.apache.flink.runtime.checkpoint.CheckpointCoordinator     - No master state to restore
2019-06-17 09:05:11,184 INFO  org.apache.flink.runtime.executiongraph.ExecutionGraph        - Job CarTopSpeedWindowingExample (7752ea7b0e7303c780de9d86a5ded3fa) switched from state RUNNING to SUSPENDING.
org.apache.flink.util.FlinkException: Job is being rescaled.

Info

Info 指令是用來檢視 Flink 任務的執行計劃（StreamGraph）的。

flink-1.7.2 bin/flink info examples/streaming/TopSpeedWindowing.jar
----------------------- Execution Plan -----------------------
{"nodes":[{"id":1,"type":"Source: Custom Source","pact":"Data Source","contents":"Source: Custom Source","parallelism":1},{"id":2,"type":"Timestamps/Watermarks","pact":"Operator","contents":"Timestamps/Watermarks","parallelism":1,"predecessors":[{"id":1,"ship_strategy":"FORWARD","side":"second"}]},{"id":4,"type":"Window(GlobalWindows(), DeltaTrigger, TimeEvictor, ComparableAggregator, PassThroughWindowFunction)","pact":"Operator","contents":"Window(GlobalWindows(), DeltaTrigger, TimeEvictor, ComparableAggregator, PassThroughWindowFunction)","parallelism":1,"predecessors":[{"id":2,"ship_strategy":"HASH","side":"second"}]},{"id":5,"type":"Sink: Print to Std. Out","pact":"Data Sink","contents":"Sink: Print to Std. Out","parallelism":1,"predecessors":[{"id":4,"ship_strategy":"FORWARD","side":"second"}]}]}
--------------------------------------------------------------

拷貝輸出的 Json 内容，粘貼到這個網站：

http://flink.apache.org/visualizer/

可以和實際運作的實體執行計劃對比：

3.1.2 Yarn per-job

單任務 Attach 模式

預設是 Attach 模式，即用戶端會一直等待直到程式結束才會退出。

  • 通過 -m yarn-cluster 指定 Yarn 模式
  • Yarn 上顯示名字為 Flink session cluster，這個 Batch 的 Wordcount 任務運作完會 FINISHED。
  • 用戶端能看到結果輸出
[[email protected] /home/admin/flink/flink-1.7.2]
$echo $HADOOP_CONF_DIR
/etc/hadoop/conf/

[[email protected] /home/admin/flink/flink-1.7.2]
$./bin/flink run -m yarn-cluster ./examples/batch/WordCount.jar

2019-06-17 09:15:24,511 INFO  org.apache.hadoop.yarn.client.RMProxy                         - Connecting to ResourceManager at z05c05217.sqa.zth.tbsite.net/11.163.188.29:8050
2019-06-17 09:15:24,690 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-06-17 09:15:24,690 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-06-17 09:15:24,907 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Cluster specification: ClusterSpecification{masterMemoryMB=1024, taskManagerMemoryMB=1024, numberTaskManagers=1, slotsPerTaskManager=4}
2019-06-17 09:15:25,430 WARN  org.apache.hadoop.hdfs.shortcircuit.DomainSocketFactory       - The short-circuit local reads feature cannot be used because libhadoop cannot be loaded.
2019-06-17 09:15:25,438 WARN  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - The configuration directory ('/Users/baoniu/Documents/work/tool/flink/flink-1.7.2/conf') contains both LOG4J and Logback configuration files. Please delete or rename one of them.
2019-06-17 09:15:36,239 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Submitting application master application_1532332183347_0724
2019-06-17 09:15:36,276 INFO  org.apache.hadoop.yarn.client.api.impl.YarnClientImpl         - Submitted application application_1532332183347_0724
2019-06-17 09:15:36,276 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Waiting for the cluster to be allocated
2019-06-17 09:15:36,281 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Deploying cluster, current state ACCEPTED
2019-06-17 09:15:40,426 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - YARN application has been deployed successfully.
Starting execution of program
Executing WordCount example with default input data set.
Use --input to specify file input.
Printing result to stdout. Use --output to specify output path.
(a,5)
(action,1)
(after,1)
(against,1)
(all,2)
... ...
(would,2)
(wrong,1)
(you,1)
Program execution finished
Job with JobID 8bfe7568cb5c3254af30cbbd9cd5971e has finished.
Job Runtime: 9371 ms
Accumulator Results:
- 2bed2c5506e9237fb85625416a1bc508 (java.util.ArrayList) [170 elements]

如果我們以 Attach 模式運作 Streaming 的任務，用戶端會一直等待不退出，可以運作以下的例子試驗下：

./bin/flink run -m yarn-cluster ./examples/streaming/TopSpeedWindowing.jar

單任務 Detached 模式

  • 由于是 Detached 模式，用戶端送出完任務就退出了
  • Yarn 上顯示為 Flink per-job cluster
$./bin/flink run -yd -m yarn-cluster ./examples/streaming/TopSpeedWindowing.jar

2019-06-18 09:21:59,247 INFO  org.apache.hadoop.yarn.client.RMProxy                         - Connecting to ResourceManager at z05c05217.sqa.zth.tbsite.net/11.163.188.29:8050
2019-06-18 09:21:59,428 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-06-18 09:21:59,428 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-06-18 09:21:59,940 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Cluster specification: ClusterSpecification{masterMemoryMB=1024, taskManagerMemoryMB=1024, numberTaskManagers=1, slotsPerTaskManager=4}
2019-06-18 09:22:00,427 WARN  org.apache.hadoop.hdfs.shortcircuit.DomainSocketFactory       - The short-circuit local reads feature cannot be used because libhadoop cannot be loaded.
2019-06-18 09:22:00,436 WARN  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - The configuration directory ('/Users/baoniu/Documents/work/tool/flink/flink-1.7.2/conf') contains both LOG4J and Logback configuration files. Please delete or rename one of them.
^@2019-06-18 09:22:12,113 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Submitting application master application_1532332183347_0729
2019-06-18 09:22:12,151 INFO  org.apache.hadoop.yarn.client.api.impl.YarnClientImpl         - Submitted application application_1532332183347_0729
2019-06-18 09:22:12,151 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Waiting for the cluster to be allocated
2019-06-18 09:22:12,155 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Deploying cluster, current state ACCEPTED
2019-06-18 09:22:16,275 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - YARN application has been deployed successfully.
2019-06-18 09:22:16,275 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - The Flink YARN client has been started in detached mode. In order to stop Flink on YARN, use the following command or a YARN web interface to stop it:
yarn application -kill application_1532332183347_0729
Please also note that the temporary files of the YARN session in the home directory will not be removed.
Job has been submitted with JobID e61b9945c33c300906ad50a9a11f36df

3.1.3 Yarn session

啟動 Session

./bin/yarn-session.sh -tm 2048 -s 3

表示啟動一個 Yarn session 叢集，每個 TM 的記憶體是 2 G，每個 TM 有 3 個 Slot。(注意：-n 參數不生效)

flink-1.7.2 ./bin/yarn-session.sh -tm 2048 -s 3
2019-06-17 09:21:50,177 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.rpc.address, localhost
2019-06-17 09:21:50,179 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.rpc.port, 6123
2019-06-17 09:21:50,179 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.heap.size, 1024m
2019-06-17 09:21:50,179 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: taskmanager.heap.size, 1024m
2019-06-17 09:21:50,179 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: taskmanager.numberOfTaskSlots, 4
2019-06-17 09:21:50,179 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: state.savepoints.dir, file:///tmp/savepoint
2019-06-17 09:21:50,180 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: parallelism.default, 1
2019-06-17 09:21:50,180 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: rest.port, 8081
2019-06-17 09:21:50,644 WARN  org.apache.hadoop.util.NativeCodeLoader                       - Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
2019-06-17 09:21:50,746 INFO  org.apache.flink.runtime.security.modules.HadoopModule        - Hadoop user set to baoniu (auth:SIMPLE)
2019-06-17 09:21:50,848 INFO  org.apache.hadoop.yarn.client.RMProxy                         - Connecting to ResourceManager at z05c05217.sqa.zth.tbsite.net/11.163.188.29:8050
2019-06-17 09:21:51,148 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Cluster specification: ClusterSpecification{masterMemoryMB=1024, taskManagerMemoryMB=2048, numberTaskManagers=1, slotsPerTaskManager=3}
2019-06-17 09:21:51,588 WARN  org.apache.hadoop.hdfs.shortcircuit.DomainSocketFactory       - The short-circuit local reads feature cannot be used because libhadoop cannot be loaded.
2019-06-17 09:21:51,596 WARN  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - The configuration directory ('/Users/baoniu/Documents/work/tool/flink/flink-1.7.2/conf') contains both LOG4J and Logback configuration files. Please delete or rename one of them.
^@2019-06-17 09:22:03,304 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Submitting application master application_1532332183347_0726
2019-06-17 09:22:03,336 INFO  org.apache.hadoop.yarn.client.api.impl.YarnClientImpl         - Submitted application application_1532332183347_0726
2019-06-17 09:22:03,336 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Waiting for the cluster to be allocated
2019-06-17 09:22:03,340 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Deploying cluster, current state ACCEPTED
2019-06-17 09:22:07,722 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - YARN application has been deployed successfully.
2019-06-17 09:22:08,050 INFO  org.apache.flink.runtime.rest.RestClient                      - Rest client endpoint started.
Flink JobManager is now running on z07.sqa.net:37109 with leader id 00000000-0000-0000-0000-000000000000.
JobManager Web Interface: http://z07.sqa.net:37109

用戶端預設是 Attach 模式，不會退出：

  • 可以 ctrl + c 退出，然後再通過 ./bin/yarn-session.sh -id application_1532332183347_0726 連上來；

  • 或者啟動的時候用 -d 則為 detached 模式

    Yarn 上顯示為 Flink session cluster；

  • 在本機的臨時目錄（有些機器是 /tmp 目錄）下會生成一個檔案：
flink-1.7.2 cat /var/folders/2b/r6d49pcs23z43b8fqsyz885c0000gn/T/.yarn-properties-baoniu
#Generated YARN properties file
#Mon Jun 17 09:22:08 CST 2019
parallelism=3
dynamicPropertiesString=
applicationID=application_1532332183347_0726

送出任務

./bin/flink run ./examples/batch/WordCount.jar

将會根據 /tmp/.yarn-properties-admin 檔案内容送出到了剛啟動的 Session。

flink-1.7.2 ./bin/flink run ./examples/batch/WordCount.jar
2019-06-17 09:26:42,767 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - Found Yarn properties file under /var/folders/2b/r6d49pcs23z43b8fqsyz885c0000gn/T/.yarn-properties-baoniu.
2019-06-17 09:26:42,767 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - Found Yarn properties file under /var/folders/2b/r6d49pcs23z43b8fqsyz885c0000gn/T/.yarn-properties-baoniu.
2019-06-17 09:26:43,058 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - YARN properties set default parallelism to 3
2019-06-17 09:26:43,058 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - YARN properties set default parallelism to 3
YARN properties set default parallelism to 3
2019-06-17 09:26:43,097 INFO  org.apache.hadoop.yarn.client.RMProxy                         - Connecting to ResourceManager at z05c05217.sqa.zth.tbsite.net/11.163.188.29:8050
2019-06-17 09:26:43,229 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-06-17 09:26:43,229 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-06-17 09:26:43,327 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Found application JobManager host name 'z05c07216.sqa.zth.tbsite.net' and port '37109' from supplied application id 'application_1532332183347_0726'
Starting execution of program
Executing WordCount example with default input data set.
Use --input to specify file input.
Printing result to stdout. Use --output to specify output path.
^@(a,5)
(action,1)
(after,1)
(against,1)
(all,2)
(and,12)
... ...
(wrong,1)
(you,1)
Program execution finished
Job with JobID ad9b0f1feed6d0bf6ba4e0f18b1e65ef has finished.
Job Runtime: 9152 ms
Accumulator Results:
- fd07c75d503d0d9a99e4f27dd153114c (java.util.ArrayList) [170 elements]

運作結束後 TM 的資源會釋放。

送出到指定的 Session

通過 -yid 參數來送出到指定的 Session。

$./bin/flink run -d -p 30 -m yarn-cluster -yid application_1532332183347_0708 ./examples/streaming/TopSpeedWindowing.jar

2019-03-24 12:36:33,668 INFO  org.apache.hadoop.yarn.client.RMProxy                         - Connecting to ResourceManager at z05c05217.sqa.zth.tbsite.net/11.163.188.29:8050
2019-03-24 12:36:33,773 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-03-24 12:36:33,773 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-03-24 12:36:33,837 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Found application JobManager host name 'z05c05218.sqa.zth.tbsite.net' and port '60783' from supplied application id 'application_1532332183347_0708'
Starting execution of program
Executing TopSpeedWindowing example with default input data set.
Use --input to specify file input.
Printing result to stdout. Use --output to specify output path.
Job has been submitted with JobID 58d5049ebbf28d515159f2f88563f5fd

注：

Blink版本

的 Session 與 Flink 的 Session 的差別：

  • Flink 的 session -n 參數不生效，而且不會提前啟動 TM；
  • Blink 的 session 可以通過 -n 指定啟動多少個 TM，而且 TM 會提前起來；

3.2 Scala Shell

官方文檔：

https://ci.apache.org/projects/flink/flink-docs-release-1.7/ops/scala_shell.html

3.2.1 Deploy

Local

$bin/start-scala-shell.sh local
Starting Flink Shell:
Starting local Flink cluster (host: localhost, port: 8081).
Connecting to Flink cluster (host: localhost, port: 8081).
... ...
scala>

任務運作說明：

  • Batch 任務内置了 benv 變量，通過 print() 将結果輸出到控制台；
  • Streaming 任務内置了 senv 變量，通過 senv.execute("job name") 來送出任務，且 Datastream 的輸出隻有在 Local 模式下列印到控制台；

Remote

先啟動一個 yarn session cluster：

$./bin/yarn-session.sh  -tm 2048 -s 3

2019-03-25 09:52:16,341 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.rpc.address, localhost
2019-03-25 09:52:16,342 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.rpc.port, 6123
2019-03-25 09:52:16,342 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.heap.size, 1024m
2019-03-25 09:52:16,343 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: taskmanager.heap.size, 1024m
2019-03-25 09:52:16,343 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: taskmanager.numberOfTaskSlots, 4
2019-03-25 09:52:16,343 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: parallelism.default, 1
2019-03-25 09:52:16,343 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: state.savepoints.dir, file:///tmp/savepoint
2019-03-25 09:52:16,343 INFO  org.apache.flink.configuration.GlobalConfiguration
… ...
Flink JobManager is now running on z054.sqa.net:28665 with leader id 00000000-0000-0000-0000-000000000000.
JobManager Web Interface: http://z054.sqa.net:28665

啟動 scala shell，連到 jm：

$bin/start-scala-shell.sh remote z054.sqa.net 28665
Starting Flink Shell:
Connecting to Flink cluster (host: z054.sqa.net, port: 28665).
... ...
scala>

Yarn

$./bin/start-scala-shell.sh yarn -n 2 -jm 1024 -s 2 -tm 1024 -nm flink-yarn

Starting Flink Shell:
2019-03-25 09:47:44,695 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.rpc.address, localhost
2019-03-25 09:47:44,697 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.rpc.port, 6123
2019-03-25 09:47:44,697 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: jobmanager.heap.size, 1024m
2019-03-25 09:47:44,697 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: taskmanager.heap.size, 1024m
2019-03-25 09:47:44,697 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: taskmanager.numberOfTaskSlots, 4
2019-03-25 09:47:44,698 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: parallelism.default, 1
2019-03-25 09:47:44,698 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: state.savepoints.dir, file:///tmp/savepoint
2019-03-25 09:47:44,698 INFO  org.apache.flink.configuration.GlobalConfiguration            - Loading configuration property: rest.port, 8081
2019-03-25 09:47:44,717 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - Found Yarn properties file under /tmp/.yarn-properties-admin.
2019-03-25 09:47:45,041 INFO  org.apache.hadoop.yarn.client.RMProxy                         - Connecting to ResourceManager at z05c05217.sqa.zth.tbsite.net/11.163.188.29:8050
2019-03-25 09:47:45,098 WARN  org.apache.hadoop.util.NativeCodeLoader                       - Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
2019-03-25 09:47:45,266 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - No path for the flink jar passed. Using the location of class org.apache.flink.yarn.YarnClusterDescriptor to locate the jar
2019-03-25 09:47:45,275 INFO  org.apache.flink.yarn.cli.FlinkYarnSessionCli                 - The argument yn is deprecated in will be ignored.
2019-03-25 09:47:45,357 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Cluster specification: ClusterSpecification{masterMemoryMB=1024, taskManagerMemoryMB=1024, numberTaskManagers=2, slotsPerTaskManager=2}
2019-03-25 09:47:45,711 WARN  org.apache.hadoop.hdfs.shortcircuit.DomainSocketFactory       - The short-circuit local reads feature cannot be used because libhadoop cannot be loaded.
2019-03-25 09:47:45,718 WARN  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - The configuration directory ('/home/admin/flink/flink-1.7.2/conf') contains both LOG4J and Logback configuration files. Please delete or rename one of them.
2019-03-25 09:47:46,514 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Submitting application master application_1532332183347_0710
2019-03-25 09:47:46,534 INFO  org.apache.hadoop.yarn.client.api.impl.YarnClientImpl         - Submitted application application_1532332183347_0710
2019-03-25 09:47:46,534 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Waiting for the cluster to be allocated
2019-03-25 09:47:46,535 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - Deploying cluster, current state ACCEPTED
2019-03-25 09:47:51,051 INFO  org.apache.flink.yarn.AbstractYarnClusterDescriptor           - YARN application has been deployed successfully.
2019-03-25 09:47:51,222 INFO  org.apache.flink.runtime.rest.RestClient                      - Rest client endpoint started.

Connecting to Flink cluster (host: 10.10.10.10, port: 56942).

按 CTRL + C 退出 Shell 後，這個 Flink cluster 還會繼續運作，不會退出。

3.2.2 Execute

DataSet

flink-1.7.2 bin/stop-cluster.sh
No taskexecutor daemon to stop on host zkb-MBP.local.
No standalonesession daemon to stop on host zkb-MBP.local.
  flink-1.7.2 bin/start-scala-shell.sh local
Starting Flink Shell:
Starting local Flink cluster (host: localhost, port: 8081).
Connecting to Flink cluster (host: localhost, port: 8081).

scala> val text = benv.fromElements("To be, or not to be,--that is the question:--")
text: org.apache.flink.api.scala.DataSet[String] = org.apache.flink.api.scala.DataSet@5b407336

scala> val counts = text.flatMap { _.toLowerCase.split("\\W+") }.map { (_, 1) }.groupBy(0).sum(1)
counts: org.apache.flink.api.scala.AggregateDataSet[(String, Int)] = org.apache.flink.api.scala.AggregateDataSet@6ee34fe4

scala> counts.print()
(be,2)
(is,1)
(not,1)
(or,1)
(question,1)
(that,1)
(the,1)
(to,2)

對 DataSet 任務來說，print() 會觸發任務的執行。

也可以将結果輸出到檔案（先删除 /tmp/out1，不然會報錯同名檔案已經存在），繼續執行以下指令：

scala> counts.writeAsText("/tmp/out1")
res1: org.apache.flink.api.java.operators.DataSink[(String, Int)] = DataSink '<unnamed>' (TextOutputFormat (/tmp/out1) - UTF-8)

scala> benv.execute("batch test")
res2: org.apache.flink.api.common.JobExecutionResult = org.apache.flink.api.common.JobExecutionResult@737652a9

檢視 /tmp/out1 檔案就能看到輸出結果。

flink-1.7.2 cat /tmp/out1
(be,2)
(is,1)
(not,1)
(or,1)
(question,1)
(that,1)
(the,1)
(to,2)

DataSteam

scala> val textStreaming = senv.fromElements("To be, or not to be,--that is the question:--")
textStreaming: org.apache.flink.streaming.api.scala.DataStream[String] = org.apache.flink.streaming.api.scala.DataStream@4970b93d

scala> val countsStreaming = textStreaming.flatMap { _.toLowerCase.split("\\W+") }.map { (_, 1) }.keyBy(0).sum(1)
countsStreaming: org.apache.flink.streaming.api.scala.DataStream[(String, Int)] = org.apache.flink.streaming.api.scala.DataStream@6a478680

scala> countsStreaming.print()
res3: org.apache.flink.streaming.api.datastream.DataStreamSink[(String, Int)] = org.apache.flink.streaming.api.datastream.DataStreamSink@42bfc11f

scala> senv.execute("Streaming Wordcount")
(to,1)
(be,1)
(or,1)
(not,1)
(to,2)
(be,2)
(that,1)
(is,1)
(the,1)
(question,1)
res4: org.apache.flink.api.common.JobExecutionResult = org.apache.flink.api.common.JobExecutionResult@1878815a

對 DataStream 任務，print() 并不會觸發任務的執行，需要顯示調用 execute(“job name”) 才會執行任務。

TableAPI

在 Blink 開源版本裡面，支援了 TableAPI 方式送出任務（可以用 btenv.sqlQuery 送出 SQL 查詢），社群版本 Flink 1.8 會支援 TableAPI:

https://issues.apache.org/jira/browse/FLINK-9555

3.3 SQL Client Beta

SQL Client 目前還隻是測試版，處于開發階段，隻能用于 SQL 的原型驗證，不推薦在生産環境使用。

3.3.1 基本用法

flink-1.7.2 bin/start-cluster.sh
Starting cluster.
Starting standalonesession daemon on host zkb-MBP.local.
Starting taskexecutor daemon on host zkb-MBP.local.

  flink-1.7.2 ./bin/sql-client.sh embedded
No default environment specified.
Searching for '/Users/baoniu/Documents/work/tool/flink/flink-1.7.2/conf/sql-client-defaults.yaml'...found.
Reading default environment from: file:/Users/baoniu/Documents/work/tool/flink/flink-1.7.2/conf/sql-client-defaults.yaml
No session environment specified.
Validating current environment...done.
… …

Flink SQL> help;
The following commands are available:

QUIT        Quits the SQL CLI client.
CLEAR        Clears the current terminal.
HELP        Prints the available commands.
SHOW TABLES        Shows all registered tables.
SHOW FUNCTIONS        Shows all registered user-defined functions.
DESCRIBE        Describes the schema of a table with the given name.
EXPLAIN        Describes the execution plan of a query or table with the given name.
SELECT        Executes a SQL SELECT query on the Flink cluster.
INSERT INTO        Inserts the results of a SQL SELECT query into a declared table sink.
CREATE VIEW        Creates a virtual table from a SQL query. Syntax: 'CREATE VIEW <name> AS <query>;'
DROP VIEW        Deletes a previously created virtual table. Syntax: 'DROP VIEW <name>;'
SOURCE        Reads a SQL SELECT query from a file and executes it on the Flink cluster.
SET        Sets a session configuration property. Syntax: 'SET <key>=<value>;'. Use 'SET;' for listing all properties.
RESET        Resets all session configuration properties.

Hint: Make sure that a statement ends with ';' for finalizing (multi-line) statements.

Select 查詢

Flink SQL> SELECT 'Hello World';

按 ”Q” 退出這個界面

能看到這條 Select 語句産生的查詢任務已經結束了。這個查詢采用的是讀取固定資料集的 Custom Source，輸出用的是 Stream Collect Sink，且隻輸出一條結果。

注意：如果本機的臨時目錄存在類似 .yarn-properties-baoniu 的檔案，任務會送出到 Yarn 上。

Explain

Explain 指令可以檢視 SQL 的執行計劃。

Flink SQL> explain SELECT name, COUNT(*) AS cnt FROM (VALUES ('Bob'), ('Alice'), ('Greg'), ('Bob')) AS NameTable(name) GROUP BY name;

== Abstract Syntax Tree ==        // 抽象文法樹
LogicalAggregate(group=[{0}], cnt=[COUNT()])
  LogicalValues(tuples=[[{ _UTF-16LE'Bob  ' }, { _UTF-16LE'Alice' }, { _UTF-16LE'Greg ' }, { _UTF-16LE'Bob  ' }]])

== Optimized Logical Plan ==     // 優化後的邏輯執行計劃
DataStreamGroupAggregate(groupBy=[name], select=[name, COUNT(*) AS cnt])
  DataStreamValues(tuples=[[{ _UTF-16LE'Bob  ' }, { _UTF-16LE'Alice' }, { _UTF-16LE'Greg ' }, { _UTF-16LE'Bob  ' }]])

== Physical Execution Plan ==   // 實體執行計劃
Stage 3 : Data Source
    content : collect elements with CollectionInputFormat

    Stage 5 : Operator
        content : groupBy: (name), select: (name, COUNT(*) AS cnt)
        ship_strategy : HASH

3.3.2 結果展示

SQL Client 支援兩種模式來維護并展示查詢結果：

  • table mode: 在記憶體中物化查詢結果，并以分頁 table 形式展示。使用者可以通過以下指令啟用 table mode;
SET execution.result-mode=table
  • changlog mode: 不會物化查詢結果，而是直接對 continuous query 産生的添加和撤回（retractions）結果進行展示。
SET execution.result-mode=changelog

接下來通過實際的例子進行示範。

Table mode

Flink SQL> SET execution.result-mode=table;
[INFO] Session property has been set.

Flink SQL> SELECT name, COUNT(*) AS cnt FROM (VALUES ('Bob'), ('Alice'), ('Greg'), ('Bob')) AS NameTable(name) GROUP BY name;

運作結果如下圖所示：

Changlog mode

Flink SQL> SET execution.result-mode=changelog;
[INFO] Session property has been set.

Flink SQL> SELECT name, COUNT(*) AS cnt FROM (VALUES ('Bob'), ('Alice'), ('Greg'), ('Bob')) AS NameTable(name) GROUP BY name;

其中 ‘-’ 代表的就是撤回消息。

3.3.3 Environment Files

目前的 SQL Client 還不支援 DDL 語句，隻能通過 yaml 檔案的方式來定義 SQL 查詢需要的表，UDF 和運作參數等資訊。

首先，準備 env.yaml 和 input.csv 兩個檔案。

flink-1.7.2 cat /tmp/env.yaml
tables:
  - name: MyTableSource
    type: source-table
    update-mode: append
    connector:
      type: filesystem
      path: "/tmp/input.csv"
    format:
      type: csv
      fields:
        - name: MyField1
          type: INT
        - name: MyField2
          type: VARCHAR
      line-delimiter: "\n"
      comment-prefix: "#"
    schema:
      - name: MyField1
        type: INT
      - name: MyField2
        type: VARCHAR
  - name: MyCustomView
    type: view
    query: "SELECT MyField2 FROM MyTableSource"
  - name: MyTableSink
    type: sink-table
    update-mode: append
    connector:
      type: filesystem
      path: "/tmp/output.csv"
    format:
      type: csv
      fields:
        - name: MyField1
          type: INT
        - name: MyField2
          type: VARCHAR
    schema:
      - name: MyField1
        type: INT
      - name: MyField2
        type: VARCHAR

# Execution properties allow for changing the behavior of a table program.

execution:
  type: streaming                   # required: execution mode either 'batch' or 'streaming'
  result-mode: table                # required: either 'table' or 'changelog'
  max-table-result-rows: 1000000    # optional: maximum number of maintained rows in
                                    #   'table' mode (1000000 by default, smaller 1 means unlimited)
  time-characteristic: event-time   # optional: 'processing-time' or 'event-time' (default)
  parallelism: 1                    # optional: Flink's parallelism (1 by default)
  periodic-watermarks-interval: 200 # optional: interval for periodic watermarks (200 ms by default)
  max-parallelism: 16               # optional: Flink's maximum parallelism (128 by default)
  min-idle-state-retention: 0       # optional: table program's minimum idle state time
  max-idle-state-retention: 0       # optional: table program's maximum idle state time
  restart-strategy:                 # optional: restart strategy
    type: fallback                  #   "fallback" to global restart strategy by default

# Deployment properties allow for describing the cluster to which table programs are submitted to.

deployment:
  response-timeout: 5000

  flink-1.7.2 cat /tmp/input.csv
1,hello
2,world
3,hello world
1,ok
3,bye bye
4,yes

啟動 SQL Client：

flink-1.7.2 ./bin/sql-client.sh embedded -e /tmp/env.yaml
No default environment specified.
Searching for '/Users/baoniu/Documents/work/tool/flink/flink-1.7.2/conf/sql-client-defaults.yaml'...found.
Reading default environment from: file:/Users/baoniu/Documents/work/tool/flink/flink-1.7.2/conf/sql-client-defaults.yaml
Reading session environment from: file:/tmp/env.yaml
Validating current environment...done.

Flink SQL> show tables;
MyCustomView
MyTableSink
MyTableSource

Flink SQL> describe MyTableSource;
root
 |-- MyField1: Integer
 |-- MyField2: String

Flink SQL> describe MyCustomView;
root
 |-- MyField2: String

Flink SQL> create view MyView1 as select MyField1 from MyTableSource;
[INFO] View has been created.

Flink SQL> show tables;
MyCustomView
MyTableSource
MyView1

Flink SQL> describe MyView1;
root
 |-- MyField1: Integer

Flink SQL> select * from MyTableSource;

使用 insert into 寫入結果表：

Flink SQL> insert into MyTableSink select * from MyTableSource;
[INFO] Submitting SQL update statement to the cluster...
[INFO] Table update statement has been successfully submitted to the cluster:
Cluster ID: StandaloneClusterId
Job ID: 3fac2be1fd891e3e07595c684bb7b7a0
Web interface: http://localhost:8081

查詢生成的結果資料檔案：

flink-1.7.2 cat /tmp/output.csv
1,hello
2,world
3,hello world
1,ok
3,bye bye
4,yes

也可以在 Environment 檔案裡面定義 UDF，在 SQL Client 裡面通過 「HOW FUNCTIONS」查詢和使用，這裡就不再說明了。

SQL Client 功能社群還在開發中，詳見

FLIP-24

3.4 Restful API

接下來我們示範如何通過 Rest API 來送出 Jar 包和執行任務。

更詳細的操作請參考 Flink 的 Restful API 文檔：

https://ci.apache.org/projects/flink/flink-docs-stable/monitoring/rest_api.html
flink-1.7.2 curl http://127.0.0.1:8081/overview
{"taskmanagers":1,"slots-total":4,"slots-available":0,"jobs-running":3,"jobs-finished":0,"jobs-cancelled":0,"jobs-failed":0,"flink-version":"1.7.2","flink-commit":"ceba8af"}%

  flink-1.7.2 curl -X POST -H "Expect:" -F "jarfile=@/Users/baoniu/Documents/work/tool/flink/flink-1.7.2/examples/streaming/TopSpeedWindowing.jar" http://127.0.0.1:8081/jars/upload
{"filename":"/var/folders/2b/r6d49pcs23z43b8fqsyz885c0000gn/T/flink-web-124c4895-cf08-4eec-8e15-8263d347efc2/flink-web-upload/6077eca7-6db0-4570-a4d0-4c3e05a5dc59_TopSpeedWindowing.jar","status":"success"}%
                                                                                                                                                                                                     flink-1.7.2 curl http://127.0.0.1:8081/jars
{"address":"http://localhost:8081","files":[{"id":"6077eca7-6db0-4570-a4d0-4c3e05a5dc59_TopSpeedWindowing.jar","name":"TopSpeedWindowing.jar","uploaded":1553743438000,"entry":[{"name":"org.apache.flink.streaming.examples.windowing.TopSpeedWindowing","description":null}]}]}%

  flink-1.7.2 curl http://127.0.0.1:8081/jars/6077eca7-6db0-4570-a4d0-4c3e05a5dc59_TopSpeedWindowing.jar/plan
{"plan":{"jid":"41029eb3feb9132619e454ec9b2a89fb","name":"CarTopSpeedWindowingExample","nodes":[{"id":"90bea66de1c231edf33913ecd54406c1","parallelism":1,"operator":"","operator_strategy":"","description":"Window(GlobalWindows(), DeltaTrigger, TimeEvictor, ComparableAggregator, PassThroughWindowFunction) -&gt; Sink: Print to Std. Out","inputs":[{"num":0,"id":"cbc357ccb763df2852fee8c4fc7d55f2","ship_strategy":"HASH","exchange":"pipelined_bounded"}],"optimizer_properties":{}},{"id":"cbc357ccb763df2852fee8c4fc7d55f2","parallelism":1,"operator":"","operator_strategy":"","description":"Source: Custom Source -&gt; Timestamps/Watermarks","optimizer_properties":{}}]}}%                                                                                                                                                      flink-1.7.2 curl -X POST http://127.0.0.1:8081/jars/6077eca7-6db0-4570-a4d0-4c3e05a5dc59_TopSpeedWindowing.jar/run
{"jobid":"04d80a24b076523d3dc5fbaa0ad5e1ad"}%

Restful API 還提供了很多監控和 Metrics 相關的功能，對于任務送出的操作也支援的比較全面。

3.5 Web

在 Flink Dashboard 頁面左側可以看到有個「Submit new Job」的地方，使用者可以上傳 Jar 包和顯示執行計劃和送出任務。Web 送出功能主要用于新手入門和示範用。

4.結束

本期的課程到這裡就結束了，我們主要講解了 Flink 的 5 種任務送出的方式。熟練掌握各種任務送出方式，有利于提高我們日常的開發和運維效率。

視訊回顧：

https://zh.ververica.com/developers/flink-training-course2/
Apache Flink 零基礎入門（四）：用戶端操作的 5 種模式1.環境說明2.課程概要3.Flink 用戶端操作4.結束
sql 資源排程 java apache 流計算 處理java資源排程 擷取網絡資源java 架構java資源排程 java資源調用 cache java使用
上一篇: 【MaxCompute季報】MaxCompute新功能釋出 2019Q1
下一篇: Apache Flink 零基礎入門（三）：DataStream API 程式設計

繼續閱讀
