1、痛點
Elasticsearch叢集管理中索引的管理非常重要。
資料量少的時候,一個或者幾個索引就能滿足問題。
但是一旦資料量每天幾TB甚至幾十TB的增長時,索引的生命周期管理顯得尤為重要。
痛點1:你是否遇到過磁盤不夠,要删除幾個月前甚至更早時間資料的情況?
如果沒有基于時間建立索引,單一索引借助delete_by_query結合時間戳,會越删磁盤空間越緊張,以至于對自己都産生了懷疑?
痛點2:你是否還在通過複雜的腳本管理索引?
1個增量rollover動态更新腳本,
1個定期delete腳本,
1個定期force_merge腳本,
1個定期shrink腳本,
1個定期快照腳本。
索引多了或者叢集規模大了,腳本的維護是一筆不菲的開銷。
如果以上痛點,你都遇到過了。
那麼,客官别走,本文利器curator會給你答案。
2、curator是什麼?

2.1 被Elastic收編的曆史
curator最早被稱為clearESindices.py。 它的唯一功能是删除索引,
而後重命名:logstash_index_cleaner.py。它在logstash存儲庫下作用:過期日志清理。
此後不久,原作者加入Elastic,它成為了Elasticsearch Curator,
Git位址:https://github.com/elastic/curator
2.2 收編後功能強大
curator允許對索引和快照執行許多不同的操作,包括:
- 從别名添加或删除索引(或兩者!)
- 更改分片路由配置設定更改分片路由配置設定
- 關閉索引關閉索引
- 建立索引建立索引
- 删除索引删除索引
- 删除快照删除快照
- 打開被關閉的索引打開被關閉的索引
- 對索引執行forcemerge段合并操作對索引執行forcemerge段合并操作
- reindex索引,包括來自遠端叢集的索引reindex索引,包括來自遠端叢集的索引
- 更改索引的每個分片的副本數 更改索引的每個分片的副本數
- rollover索引rollover索引
- 生成索引的快照(備份)生成索引的快照(備份)
- 還原快照還原快照
3、curator 版本
不同于Elasticsearch甚至ELKB的版本統一規範,curator有自己的一套版本規範。
簡化記錄如下:
6.XES使用 curator 5;
5.XES可以使用curator5 或者 curator4 ,
具體參考官網:http://t.cn/EGi2nLX
還等什麼,趕緊用起來!
4、Curator使用指南
4.1 curator安裝
curator可以通過多種方式安裝,具體取決于您的需求。
值得注意的是,Curator隻需要安裝在可通路Elasticsearch叢集中機器上就可以運作。 它不需要安裝在群集中的一個節點上。
我的機器是5.X版本,使用如下操作ok。
Step1:安裝:
1pip install elasticsearch-curator
centos6/7使用者更簡潔:
1yum install elasticsearch-curator
Step 2:更新至最新版本(非必須,根據自己需要):
1pip install -U elasticsearch-curator
驗證執行成功方法1:
1curator_cli show_indices
若成功,會顯示索引資訊。
4.2 curator用法講解
4.2.1 用法1:curator_cli 指令行
用法舉例:curatorcli 關閉全部一天前建立的索引名稱為logs*開頭的索引。
1curator_cli --host 192.168.1.2 --port 9200 close --filter_list '[{"filtertype":"age","source":"creation_date","direction":"older","unit":"days","unit_count":1},{"filtertype":"pattern","kind":"prefix","value":"logs_"}]'
好處:無需配置檔案,一行指令即可成功。
壞處:不能便捷的适應複雜的操作。
4.2.2 用法2:curator指令行
用法舉例:
1curator [--config CONFIG.YML] [--dry-run] ACTION_FILE.YML
解釋:
1、CONFIG.YML是配置檔案,用于配置ES叢集資訊。
CONFIG.YML樣例:
1[root@localhost .curator]# cat curator.yml
2# Remember, leave a key empty if there is no value. None will be a string,
3## not a Python "NoneType"
4
5client:
6 hosts: 192.168.1.1
7 port: 9200
8 url_prefix:
9 use_ssl: False
10 certificate:
11 client_cert:
12 client_key:
13 ssl_no_validate: False
14 http_auth:
15 timeout: 30
16 master_only: False
17
18logging:
19 loglevel: INFO
20 logfile: /home/curator/logs
21 logformat: default
22 blacklist: ['elasticsearch', 'urllib3']
核心配置:
1)叢集IP;
2)安全認證資訊;
3)日志資訊。
2、ACTION_FILE.YML 執行索引操作的配置資訊
由于支援的操作非常多,建議直接參考官網配置即可:
http://t.cn/EGiLwyk
http://t.cn/EGiL4EF
拿删除曆史索引舉例:
以下指令删除了30天前,以logs_*開頭的索引。
1[root@localhost .curator]# cat action.yml
2---
3# Remember, leave a key empty if there is no value. None will be a string,
4# not a Python "NoneType"
5#
6# Also remember that all examples have 'disable_action' set to True. If you
7# want to use this action as a template, be sure to set this to False after
8# copying it.
9actions:
10 1:
11 action: delete_indices
12 description: >-
13 Delete indices older than 20 days (based on index name), for logstash-
14 prefixed indices. Ignore the error if the filter does not result in an
15 actionable list of indices (ignore_empty_list) and exit cleanly.
16 options:
17 ignore_empty_list: True
18 disable_action: False
19 filters:
20 - filtertype: pattern
21 kind: prefix
22 value: logs_
23 - filtertype: age
24 source: name
25 direction: older
26 timestring: '%Y.%m.%d'
27 unit: days
28 unit_count: 30
如果執行多個任務怎麼辦呢?
注意:actions: 後面的,依次類推:
2:執行操作
3:執行操作
4:執行操作
N:執行操作
好處:1個配置搞定10+處操作,不費勁!
4.3 curator 實踐
經過4.2的配置,實踐執行如下:
curator --config config.yml 指定路徑/action.yml
4.4 周期性執行
借助crontab,每天零點5分執行
1$ crontab -e
加上如下的指令:
15 0 * * * curator --config config.yml action.yml
5、小結
-
切記:
curator适用于基于時間或者template其他方式建立的索引,
不适合單一索引存儲N久曆史資料的操作的場景。
-
思考:
遇到通用問題,不要重複造輪子,看看官方或者别人是否已經實作了,已經有更好的方案了。
如果有,就“拿來主義”,和自己業務不一緻,可以考慮優化。
比如:類似curator,有很多公司已經進一步加工為可視化工具,極大提高效率。
