【故障|監聽】TNS-12518、TNS-00517和 Linux Error：32：Broken pipe
各位技術愛好者，看完本文後，你可以掌握如下的技能，也可以學到一些其它你所不知道的知識，~O(∩_∩)O~：
① Linux Error: 32: Broken pipe的可能原因（重點）
② TNS-12518: TNS:listener could not hand off client connection的一般解決過程
③ SQL*Plus登入報錯：ORA-12537: TNS:connection closed
Tips：
③ 若網頁文章代碼格式有錯亂，請下載下傳pdf格式的文檔來閱讀。
④ 在本篇BLOG中，代碼輸出部分一般放在一行一列的表格中。
本文如有錯誤或不完善的地方請大家多多指正，ITPUB留言或QQ皆可，您的批評指正是我寫作的最大動力。
項目
source db
db 類型
單機
db version
11.2.0.3.0
db 存儲
ASM
OS版本及kernel版本
RHEL 6.5
登陸報錯：
[oracle@orcltest ~]$ sqlplus 'sys/"l@h\r/0"'@LHRDB as sysdba
SQL*Plus: Release 11.2.0.3.0 Production on Thu Mar 16 12:06:36 2017
Copyright (c) 1982, 2011, Oracle. All rights reserved.
ERROR:
ORA-12537: TNS:connection closed
查監聽日志（/u01/app/11.2.0/grid/network/admin/listener.ora），報錯如下：
16-MAR-2017 12:06:36 * (CONNECT_DATA=(SERVER=DEDICATED)(SERVICE_NAME=lhrdb)(CID=(PROGRAM=sqlplus)(HOST=orcltest)(USER=oracle))) * (ADDRESS=(PROTOCOL=tcp)(HOST=192.168.59.129)(PORT=12333)) * establish * lhrdb * 12518
TNS-12518: TNS:listener could not hand off client connection
TNS-12547: TNS:lost contact
TNS-12560: TNS:protocol adapter error
TNS-00517: Lost contact
Linux Error: 32: Broken pipe
根據MOS：Troubleshooting Guide for TNS-12518 TNS listener could not hand off client connection (文檔 ID 550859.1)中，
Error: 32: Broken pipe
Error stack in listener log:
TNS-12560: TNS:protocol adapter error
TNS-00517: Lost contact
IBM/AIX RISC System/6000 Error: 32: Broken pipe
Cause:
The error 32 indicates the communication has been broken while the listener is trying to hand off the client connection to the server process or dispatcher process.
Action:
1. One of reason would be processes parameter being low, and can be verified by the v$resource_limit view.
2. In Shared Server mode, check the 'lsnrctl services' output and see if the dispatcher has refused any connections, if so, then consider increasing the number of dispatchers.
3. Check the alert log for any possible errors.
4. Memory resource is also another cause for this issue. Check the swap, memory usage of the OS.
5. If RAC/SCAN or listener is running in separate home, check the following note:
Note: 1069517.1 ORA-12537 or TNS-12518 if Listener (including SCAN Listener) and Database are Owned by Different OS User
根據第5條，因為我的grid是11.2.0.1，而Oracle是11.2.0.3的，查詢MOS:ORA-12537 / ORA-12547 or TNS-12518 if Listener (including SCAN Listener) and Database are Owned by Different OS User (文檔 ID 1069517.1)，裡邊明确指出是由于$RDBMS_HOME/bin/oracle檔案的權限問題導緻。
$ORACLE_HOME/bin/oracle檔案的權限問題，應該為-rwsr-s--x，屬主應該是oracle:asmadmin。
解決辦法：
方法：
1、修改oracle的權限為6751
[root@orcltest bin]# ll /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
-rwxr-s--x. 1 oracle asmadmin 210823844 May 18 2014 /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
[root@orcltest ~]# chmod 6751 /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
-rwsr-s--x. 1 oracle asmadmin 210823844 May 18 2014 /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
[root@orcltest bin]#
2、重新用setasmgidwrap設定oracle
[root@orcltest ~]# /u01/app/11.2.0/grid/bin/setasmgidwrap -o /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
[root@orcltest bin]# stat /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
File: `/u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle'
Size: 210823844 Blocks: 411776 IO Block: 4096 regular file
Device: 802h/2050d Inode: 1717737 Links: 1
Access: (6751/-rwsr-s--x) Uid: ( 501/ oracle) Gid: ( 504/asmadmin)
Access: 2017-03-16 11:05:44.809363974 +0800
Modify: 2014-05-18 17:09:50.508549983 +0800
Change: 2017-03-16 12:33:15.733816820 +0800
重新連接配接：
SQL*Plus: Release 11.2.0.3.0 Production on Thu Mar 16 13:32:48 2017
Connected to:
Oracle Database 11g Enterprise Edition Release 11.2.0.3.0 - 64bit Production
With the Partitioning, Automatic Storage Management, OLAP, Data Mining
and Real Application Testing options
SYS@LHRDB>
如果可執行檔案$ORACLE_HOME/bin/oracle的屬主或權限設定出了問題，那麼可能會造成很多問題。例如：無法登陸到資料庫、ora-600錯誤、“TNS-12518: TNS:listener could not hand off client connection”、“Linux Error: 32: Broken pipe”、“ORA-12537: TNS:connection closed”、通路ASM磁盤出錯等。解決辦法很簡單，可以在grid使用者下運作setasmgidwrap指令重新配置$ORACLE_HOME/bin/oracle可執行檔案的權限和屬主或者直接将oracle檔案的權限修改為6751。$ORACLE_HOME/bin/oracle可執行檔案正确屬主應該是oracle:asmadmin，并且權限必須有s共享才可以，如下所示：
[root@orcltest ~]$ which setasmgidwrap
/u01/app/11.2.0/grid/bin/setasmgidwrap
[root@orcltest ~]$ setasmgidwrap -o /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
[root@orcltest ~]$ ll /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
-rwsr-s--x 1 oracle asmadmin 232399083 Apr 21 2015 /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
[root@orcltest ~]# ll /u01/app/11.2.0/grid/bin/oracle
-rwsr-s--x. 1 grid oinstall 203972117 Jan 5 2015 /u01/app/11.2.0/grid/bin/oracle
[root@orcltest ~]# chmod 6751 /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
[root@orcltest ~]# ll /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
[root@orcltest bin]# cd /u01/app/oracle/product/11.2.0/dbhome_1/bin/
[root@orcltest bin]# which stat
/usr/bin/stat
[root@orcltest bin]# stat oracle
File: `oracle'
Access: 2017-03-16 12:33:44.809363974 +0800
Change: 2017-03-16 11:05:15.733816820 +0800
問：在UNIX/LINUX環境中，oracle資料庫啟動後存在許多背景程序和前台程序，雖然相關程序産生一些trace檔案也是常有的事情，但是真正是什麼決定了oracle相關程序的屬性呢？
答：通常來說，oracle的背景程序的調用是依賴于$ORACLE_HOME/bin/oracle這個二進制檔案，但它從遠端連入而配置設定的伺服器程序（server process）相關屬主的屬性則是繼承自listener程序，而listener程序的屬主屬性同樣是程序自其啟動的使用者（分oracle使用者和grid使用者）$ORACLE_HOME/bin/oracle的屬主屬性。
其他原因：
啟動ORACLE監聽的時候 報錯 Linux Error: 32: Broken pipe
原因：原來/home/oracle/product/9.2.0.1.0/network/log/listener.log 檔案超過2G，監聽就會斷掉。
解決辦法：清空日志檔案
[oracle@localhost oracle]$ cd $ORACLE_HOME/network/log
[oracle@chicago log]$ cat listener.log
至此問題解決
有個指令可以對這個寫日志進行關閉
LSNRCTL> set log_status off
要繼續寫日志，隻需要
LSNRCTL> set log_status on
也可以在 listener.ora 檔案裡面添加一項
LOGGING_LISTENER = OFF
添加了這個之後無論你怎麼重新開機監聽，都不會寫日志了。
setasmgidwrap -o /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
chmod 6751 /u01/app/oracle/product/11.2.0/dbhome_1/bin/oracle
stat oracle
In this Document
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#PURPOSE" target="_blank">Purpose</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#TRBLSHOOT" target="_blank">Troubleshooting Steps</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section22" target="_blank">Section I: Steps to approach ORA-12518/TNS-12518 Error:</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section23" target="_blank">Section II: Commonly Known Errors:</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section24" target="_blank">Error: 32: Broken pipe</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section25" target="_blank">Error: 11: Resource temporarily unavailable</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section26" target="_blank">Error: Connection Pooling limit reached</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section27" target="_blank">Error: 24: Too many open files</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section28" target="_blank">Section III: Errors Specific to Windows</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section29" target="_blank">Error: 2: No such file or directory </a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section210" target="_blank">Error: 233: Unknown error</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section211" target="_blank">Error: 54: Unknown error</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#aref_section212" target="_blank">Error: 10022: Unknown error</a>
<a href="https://support.oracle.com/epmos/faces/DocumentDisplay?id=550859.1&_adf.ctrl-state=18wwzsdvut_4&_afrLoop=409416171451023#REF" target="_blank">References</a>
Oracle Net Services - Version 10.1.0.5 to 12.1.0.2 [Release 10.1 to 12.1]
Information in this document applies to any platform.
This article discusses how to troubleshoot the ORA-12518/TNS-12518 listener errors.
<a></a>
ORA-12518/TNS-12518 indicates a problem while listener hands off the client connection to the server process or dispatcher process.TNS-12518 is logged in the listener log. The client might receive ORA-12518 or some other disconnection errors like ORA-12537. Once TNS-12518 is noted in the listener log, follow the below steps to approach and resolve this error.
Let us have a small discussion about how actually database connections are made:
In Dedicated mode, database client contacts listener and supplies the SERVICE NAME of the database. Then listener spawns a dedicated server process and hands off the client connection to this dedicated server process. TNS-12518 indicates a problem while handing off the client connection to the server process.
In Shared Server mode, database client contacts listener and supplies the SERVICE NAME of the database. Then listener hands off the client connection to one of the dispatcher configured for that service. TNS-12518 indicates a problem while handing off the client connection to the dispatcher server process.
Though this error is logged in the listener log, the listener is just the messenger, ORA-12518/TNS-12518 is mostly related to RDBMS and OS resources.
Step 1. Is listener version compatible to the database
Check if you are using compatible listener version for your database version.
If the database is 8i then use 8i or 9i listeners only. 10g listeners are not compatible to work with 8i databases.
For 9i databases, 9i or 10g listeners can be used.
For 10g databases, only 10g listeners can be used.
The general rule is that use the higher version of the listener when there is a version mismatch between database and the listener.
Step 2. Gather more information from listener log
The first place you would look for the TNS-12518 error is the listener log. Usually the listener log would be located under $ORACLE_HOME/network/log directory. You can use 'lsnrctl status' command output to look for the location of the listener log file.
$lsnrctl status
- - -
Listener Parameter File /ora10g/home_ora10g/network/admin/listener.ora
Listener Log File /ora10g/home_ora10g/network/log/listener.log
- - -
listener log gives the complete error stack and the database service name to which the client tried to connect to.
19-SEP-2007 13:55:34 * (CONNECT_DATA=(CID=(PROGRAM=)(HOST=__jdbc__)(USER=))(SERVICE_NAME=test.oracle.com)) * (ADDRESS=(PROTOCOL=tcp)(HOST=10.10.10.3)(PORT=36030)) * establish * test.oracle.com * 12518
TNS-12518: TNS:listener could not hand off client connection
TNS-12547: TNS:lost contact
TNS-12560: TNS:protocol adapter error
TNS-00517: Lost contact
Linux Error: 32: Broken pipe
In the above example, listener log shows the complete error stack, the bottom error being 32 is the OS error. It also shows that the jdbc client from IP 10.10.10.3 has tried to connect to the database service 'test.oracle.com' and failed with the error 12518.
Look for the lowest error in the stack. That is the error we have to concentrate on and try to resolve it. In the above example, the lower error is 'Linux Error: 32: Broken pipe'.
Step 3. Are service handlers in blocked state
Check if the handlers are in blocked state. Check the output of the 'lsnrctl services'. Examine the status information under the database service name. From the listener log you would know which database service was affected by the 12518 error, now with the output of the 'lsnrctl services' under that service name gather more information.
Service "test.oracle.com" has 1 instance(s).
Instance "db10g", status READY, has 2 handler(s) for this service...
Handler(s):
"DEDICATED" established:9 refused:0 state:ready
LOCAL SERVER
"D000" established:10 refused:0 current:0 max:972 state:ready
DISPATCHER
(ADDRESS=(PROTOCOL=tcp)(HOST=oid.mohan.com)(PORT=33487))
The highlighted state should be in 'ready' state for the connection to be successful. If the state is in 'blocked' then the connection are not possible. The state of a handler could be in blocked state in the following scenario:
i. The database parameter processes reached its value.
ii. The database is in the process of startup or shutting down.
In shared server mode, the number of dispatchers should be set according to the load that you expect. 'lsnrctl services' output shows the maximum number(max:997) of connections that the dispatcher would accept and the number connections refused (refused:0) by this dispatcher. If any connections refused by the dispatcher, then consider increasing the number of dispatchers.
If you are using PFILE edit init.ora and increase the dispatchers parameter. If you are using SPFILE you can dynamically increase the dispatchers parameter by the'alter system set' command.
Step 4. Is a local BEQ connection successful
Check if local BEQ connection to the database works fine. It also verifies if the database is up and in good condition to accept the connection. If the database is down or in a hung state then a connection request to the database by the listener will not be possible.
Connect to the database server via telnet or ssh and check if a local bequeath SQL*Plus connection works. In other words, issue:
sqlplus username/password [Enter]
This connection bypasses the listener and directly connects to the database via the BEQ (bequeath) protocol. If this fails, then the TNS-12518 listener error is simply a result of the database issue.
One such error is:
ORA-12560: TNS:protocol adapter error
A possible cause for this error on Microsoft Windows servers, is that the Windows Database Service has not yet been created (common when creating a "standby" instance).
Resolution for this would be to create the Windows Service first by using the "oradim" command (see the Database Admin guide for details on oradim and service creation).
Step 5. Has number of processes reached its limit?
If local BEQ is successful, check the below query
SQL> select * from v$resource_limit;
RESOURCE_NAME CURRENT_UTILIZATION MAX_UTILIZATION INITIAL_AL LIMIT_VALU
-------------------- ------------------- --------------- ---------- ----------
processes 249 250 250 250
sessions 54 82 280 280
- - - - - -
Verify if the processes or sessions reached its limit value. If these database parameters reached its limit value, then consider increasing it accordingly.
In the above example, the processes parameter has been set to 250. It's MAX_UTILIZATION has reached the limit value of 250, so the processes parameter should be increased further to accomodate the number of incoming connections.
Edit the init.ora and set the processes parameter to a higher value. By default, if you just increase the processes it is enough, the sessions value would automatically be increased.
Check the alert.log for a corresponding error such as "ksvcreate" process failed, etc. Check timestamp against listener.log timestamps for causal relationship.
Step 6. Are OS kernel parameters configured for optimum?
Database is operated by a single user, normally it would be 'oracle' user. At the Operating System level, there is a limit for the number of process spawned by a user. And also there is a limit for the total number of process running on the entire OS.
The Oracle Database and the newly spawned processes would be owned by the 'oracle' user. And so make sure that these values are set accordingly.On Unix these values are configured through the configurable OS kernel parameters and is specific to Operating Systems. You will have check your corresponding OS documentation for your OS.
For example for HP-UX the configurable kernel parameters are,
maxuprc Maximum number of processes for each non-root user
nproc Maximum number of processes on the system
Step 7. Does alert log have any errors?
Look in alert log and look for any errors related to memory or process during the time the error TNS-12518 occurred in the listener log. If the alert log has any memory related errors, there there is a potential memory resource issue at the OS level.
OS memory issues can be addressed by the below:
i. Make sure that the OS has been configured with the enough Swap memory. In case of Windows it is called as Virtual Memory.
ii. Reduce the size of SGA, thus the newly spawned server process will have some more system memory available.
iii. Reduce the PGA size, so that the newly spawned server process would occupy less memory.
iv. If you are in DEDICATED mode, try switching to MTS mode.
If there are any memory or process related error in the alert log during the time the TNS-12518 is logged in the listener log, then those errors in the alert log should be focused on and should be solved at first. Because, the errors in the alert log is the base error for the TNS-12518 in the listener log.
However, the errors in the alert logs are not being discussed in this article, they are out of the scope of this article.
Step 8. If using a statically defined SID_DESC in the listener.ora file for your sid, ensure that it is configured properly.
A common mistake is to include a (PROGRAM=EXTPROC) parameter:
(SID_LIST=
(SID_DESC =
(GLOBAL_DBNAME = ORCL.oracle.com)
(SID_NAME = ORCL)
(PROGRAM=extproc)
(ORACLE_HOME = D:\oracle\product\10.2.0\db_1)))
This misconfiguration occurs when the PLSExtproc SID_DESC is copied, pasted and edited in the listener.ora file. The inclusion of the PROGRAM line will cause an ORA-12518 to be returned to the client. Here's the corrected SID_DESC for our example SID:
(SID_DESC =
(GLOBAL_DBNAME = ORCL.oracle.com)
(SID_NAME = ORCL)
(ORACLE_HOME = D:\oracle\product\10.2.0\db_1)))
This section lists some of the known and reported errors. It is also recommended that you refer the Section I above for a generic troubleshooting approach to the error TNS-12518.
Below shows example error stack that can be found in the listener log. The last line in the error stack shows the actual operating system name. Depending on the OS, only the operating system name would be different. For example, if you encounter error 32: Broken pipe, according to the OS, the last line in the error stack would be different only by the OS name, as shown below.
Solaris Error: 32: Broken pipe
HPUX Error: 32: Broken pipe
Linux Error: 32: Broken pipe
_______________________________________________________________________________________________________________________________________
Error stack in listener log:
TNS-12518: TNS:listener could not hand off client connection
TNS-12547: TNS:lost contact
TNS-12560: TNS:protocol adapter error
TNS-00517: Lost contact
IBM/AIX RISC System/6000 Error: 32: Broken pipe
Cause:
Action:
1. One of reason would be processes parameter being low, and can be verified by the v$resource_limit view.
2. In Shared Server mode, check the 'lsnrctl services' output and see if the dispatcher has refused any connections, if so, then consider increasing the number of dispatchers.
3. Check the alert log for any possible errors.
5. If RAC/SCAN or listener is running in separate home, check the following note:
______________________________________________________________________________________________________________________________________
TNS-12549: TNS:operating system resource quota exceeded
TNS-12560: TNS:protocol adapter error
TNS-00519: Operating system resource quota exceeded
IBM/AIX RISC System/6000 Error: 11: Resource temporarily unavailable
As the error indicates operating system resource has exceeded.
1. Increase the appropriate OS kernel parameters for 'maximum number of processes allowed per user'.
For example for HP-UX the parameters are maxuprc and nproc.
Error: 12: Not enough space
Error stack in listener log:
TNS-12518: TNS:listener could not hand off client connection
TNS-12549: TNS:operating system resource quota exceeded
TNS-12560: TNS:protocol adapter error
TNS-00519: Operating system resource quota exceeded
IBM/AIX RISC System/6000 Error: 12: Not enough space
This is a memory related issue. The error indicates that there is not enough memory available to spawn and hand off the client connections.
Typical problems are:
- Out of system memory / swap
- Out of process slots in the process table
- Streams resources depleted
- Out of File Handles
- sga memory usage
1. Check in the alert log for any possible memory related error.
2. Increase swap/Virtual memory if possible the available memory.
3. SGA and PGA can be reduced to address the memory consumption.
4. MTS mode can be used to reduce the amount of process and memory consumption.
________________________________________________________________________________________________________________________________________
TNS-12518 TNS:listener could not hand off client connection
TNS-12564 TNS:connection refused
TNS-12602 TNS: Connection Pooling limit reached
1. Try increasing initial number of dispatchers.
TNS-12518: TNS:listener could not hand off client connection
TNS-12560: TNS:protocol adapter error
TNS-00530: Protocol adapter error
Linux Error: 24: Too many open files
or
TNS-12518: TNS:listener could not hand off client connection
TNS-12560: TNS:protocol adapter error
Solaris Error: 24: Too many open files
Error Description:
Out of file descriptors
Can be caused by the following unpublished defect:
BUG 13078786 - LISTENER GOES DOWN SUDDENLY W/ LINUX ERROR: 32: BROKEN PIPE
Use prescribed workaround OR apply one-off patch to your environment if available.
_______________________________________________________________________________________________________________________________________
Error: 1: Not Owner
The listener doesn't own or have permissions to write a necessary file
The listener doesn't have adequate permission on socket files
TNS-00530: Protocol adapter error
HPUX Error: 1: Not owner
Action: Clear /var/tmp/.oracle/ directory
=========================================================================================================================
It is also recommended that you refer the Section I above for a generic troubleshooting approach to the error TNS-12518.
This section briefly describes about the errors that are encountered on Windows Operating System. TNS-12518 most commonly occurs on 32-bit OS due to its memory constraint, however TNS-12518 can occur on 64-bit OS as well. See Note 873752.1 for more information on Windows memory addressing and the 3GB switch.
_______________________________________________________________________________________________________________________________________
Error stack in listener log:
TNS-12518: TNS:listener could not hand off client connection
TNS-12560: TNS:proto adapter error
TNS-00530: Proto adapter error
32-bit Windows Error: 2: No such file or directory
Error Description: ERROR_FILE_NOT_FOUND 2 The system cannot find the file specified.
Cause: This indicates the database service is not actually available
Action: 1.Verify if the intended database really up and accepting local BEQ connections.
TNS-00530: Protocol adapter error
32-bit Windows Error: 233: Unknown error
Error Description:
ERROR_PIPE_NOT_CONNECTED
233
No process is on the other end of the pipe.
The communication has been broken while the listener is trying to hand off the client connection to the server process or dispatcher process.
TNS-12571: TNS:packet writer failure
TNS-00530: Protocol adapter error
32-bit Windows Error: 54: Unknown error
ERROR_NETWORK_BUSY
54
0x36
The network is busy.
This indicates a bottleneck at the network layer(TCP/IP).
1.Try increasing dispatchers and shared servers.
Error stack in listener log:
12518 TNS-12518: TNS:listener could not hand off client connection
TNS-12560: TNS:protocol adapter error TNS-00534: Failed to grant connection ownership to child
64-bit Windows Error: 10022: Unknown error
Error: 10022: Invalid Argument
An invalid argument was supplied.
Check the Control Panel Services Properties and confirm both listener and instance are started with same "Log on As" account.
Note that in 12c, the account would be the Oracle Home User.
Note that a JDBC Thin connection from a Windows client might also yield the 12518:
Macromedia}{Oracle JDBC Driver][Oracle]Connection refused, (DESCRIPTION=(TMP=)(VSNNUM=186646784)(ERR=12518)(ERROR_STACK= (ERROR=(CODE=12518)(EMFI=4))(ERROR=(CODE=12560)(EMFI=4))(ERROR=(CODE=530)(EMFI=4))(ERROR=(BUF='64-bit Windows Error:203: Unknown error'))))
<a>http://blog.csdn.net/killvoon/article/details/49420485</a>
本文轉自lhrbest 51CTO部落格，原文連結：http://blog.51cto.com/lhrbest/1907221，如需轉載請自行聯系原作者
