I. Introduction
A lot of times a lot of our needs are opposite, we want both the excellent scalability of the ATX motherboard and the small size of the mATX specification motherboard. But in fact, this demand is easy to meet, you only need a more creative internal space design of the chassis, you can perfectly in the mATX chassis volume, tucked into the ATX motherboard, but also have a good appearance, as well as expandability.
The Josper D40 is such a chassis, supporting the ATX specification of the motherboard, completely abandoning the design of the independent power compartment under the conventional ATX chassis, making full use of the space in the front of the chassis to place the power supply, so that the space inside the chassis is more compact, so that the chassis still has good compatibility in the case of being much smaller than the ordinary tower ATX chassis.
This kind of chassis design, Qiao Sibo used in many of its chassis products, but the design of many recent products has become more and more exquisite, the internal polishing is more in place, and the overall experience is better.
Second, JONSBO (JONSBO) D40 silver ATX chassis unboxed
▼ The packaging of the chassis is very familiar, and in the middle is the appearance and model of the chassis.
▼ On the back is an explosion diagram of the chassis, which shows the design of the interior of the chassis in detail.
▼ At the rear of the chassis, there are detailed parameters, including compatible specifications for each part of the hardware.
▼Inside the carton, in addition to the chassis, there are some explanatory documents, fixing screws, and the like.
Third, JONSBO D40 silver ATX chassis appearance
▼ The appearance of the chassis is very beautiful, with a large area of silver aluminum alloy material, with black, large area of side-through glass.
▼ The side-permeable glass on the side of the chassis has a blackening treatment, which can effectively suppress the light effect of the hardware inside the chassis.
▼ The front of the chassis is a whole aluminum alloy panel, and there are only several interfaces and button openings in the lower right corner.
▼The top is the power button, and the bottom has a USB3.0 interface, audio interface, and Type-C interface.
▼ The back of the chassis is also made of glass, but it seems to be pasted with a black film, and the overall appearance is all black and impenetrable.
▼ The rear of the chassis is very different from the conventional ATX chassis.
▼ The upper left corner of the top of the chassis is the power input interface, below which is the motherboard IO opening, next to the chassis rear chassis fan position. In addition, the top of the chassis has a raised design to facilitate the installation of fixed water cooling in the upper part.
▼ The bottom of the chassis is seven horizontal PCIe slots, directly to the bottom.
▼At the top of the chassis, a large area of heat dissipation grille, the metal dust mesh can be seen inside, and the reinforced grille can be seen.
▼ At the bottom of the chassis, there are four non-slip foot pads in the four corners, and in the middle is a large area of dust-proof metal mesh.
▼ The grille cover at the top of the chassis can be removed directly when pushed open, and the water-cooled fixing position below is.
▼ The details of the part of Josper has been doing a great job, the glass cover on the left and right sides of the chassis is fixed with screws, and each screw is under the gasket, very careful.
▼ The space inside the chassis is very regular, a whole piece.
▼ The left side is used to fix the motherboard, the upper part has a 240, 280 specifications of water cooling, chassis fan fixed position, and a 120mm size chassis fan position in the rear. In addition, in the upper part of the motherboard fixed position, there is a concave design to facilitate the back line.
▼The fixed position of the organic box fan at the bottom of the chassis, for the vertical air duct, the intake fan is still very important.
▼ The front of the chassis, the upper part is used to fix the power supply, supports ATX specifications, there is a fixed position of the 3.5-inch mechanical hard disk underneath, and the metal plate on the side can be fixed to the 2.5-inch hard disk.
▼ The back of the chassis looks very simple.
▼ The back line space of the chassis is wired, but the design has a special cable management slot.
▼ There is a hole on the back of the power supply fixed bit, here should be able to fix the hard disk, look at the hole size, it seems to be 2.5 inches.
4. JONSBO D40 silver ATX chassis installed
▼ The prepared hardware is stuffed into the chassis, the processor is 12700K, the motherboard is MSI's Z690 Blade Ti motherboard, ATX specifications, heat dissipation is MSI's Ice 240R white custom version.
▼ The motherboard is installed normally, the water cooling is installed, and the overall space performance is not bad.
▼ The power supply chooses Antic's HCG850 gold medal full module power supply, the length of this power supply is excellent, only 14cm, and the daily compatibility performance is excellent.
▼In order to match the white color theme of the whole machine, a white custom line was made here.
▼ In terms of details, the power supply of the Josper D40 uses an extension cable to extend the interface to the tail of the chassis, and a slot is specially designed in the part where the power is connected, which is convenient for matching different specifications of the power supply and bending. In addition, the power supply tail of this HCG850 gold medal full module power supply of Antec, in addition to the conventional power interface and switch, there is also a fan operation mode selection button, which can switch the operation mode of the power supply fan between the two modes of mute and temperature control, which is good.
▼ The graphics card selection is also a white Shadow Chi RTX3070Ti HOF Pro graphics card, the fan cover of the graphics card is white, and the cooling fan is also white.
▼ The graphics card is directly installed horizontally by default, and the Josper D40 is also very easy with this three-fan long graphics card.
▼ In terms of the back line, the difficulty of line management is almost non-existent, according to the pipe trough directly on the line, the light effect line and the like, choose the right socket, you can easily straighten the line.
▼Finally cover the glass back panel on the back of the chassis, and the glass back plate in pure black.
▼Cover the glass side panel of the chassis, as well as the top cover, and the whole machine is installed.
▼ Boot, light up at once, the whole machine effect is still very beautiful.
▼ The texture of the whole machine is very good, a large area of aluminum alloy material, with a large area of side glass, the effect is very good.
▼ The side glass on the side of the chassis has a blackening treatment, which can effectively suppress the light effect of the hardware inside the chassis and make the light effect look more exquisite.
▼ The memory adopts Weigang's D50 Longyao memory, and there is a whole RGB light strip at the top of the memory, and the appearance looks good.
▼ In addition, there is a special triangle shape in the middle of the lighting effect, which looks exquisite.
▼ The motherboard is MSI's Z690 Blade Ti motherboard, the power supply part of the motherboard has a large area of metal heat sink cover, the shape is very beautiful, not to mention, it is also printed with MSI's Dragon Shield LOGO, and supports ARGB lighting effects, which looks amazing.
▼ In addition, the metal heatsink on the front of the MSI Z690 Blade Ti motherboard are silver, and in the case of keeping the motherboard black PCB unchanged, the silver metal covering makes the color of this motherboard white as a whole, and it will be very beautiful with some white theme chassis.
▼ In the middle is MSI's cold ice 240R white customized version of water cooling, the shape of the water cooling head is very beautiful, and in the middle is MSI's classic Dragon Shield LOGO, which supports ARGB lighting effects, and there are three ARGB light strips designed around it, which surrounds the Dragon Shield LOGO in the middle, which is very beautiful.
▼ The RTX3070Ti HOF Pro graphics card has ARGB lighting effects on the sides and front, and the effect of horizontal installation is also OK.
JONSBO D40 Silver ATX Chassis Test
▼ The whole machine configuration list, the processor is 12700K, the motherboard is Z690 Blade Ti, and the graphics card is Yingchi's RTX3070Ti HOF Pro.
▼ Simple run a test, the whole machine score of 192W, of which the processor 84.3W, graphics card 61.7W, the performance is very good.
▼ Room temperature is about 22 ° C, daily standby, the temperature of the processor is around 37 ° C, the background has been updated, the processor occupancy rate does not go, but this standby temperature performance can be. In addition, the motherboard south bridge is 65 °C, the graphics card core temperature is 37 °C, and the SSD temperature is 34 °C.
▼ Simple run CPU-Z pressure test, processor power consumption of about 140W, large core turbo frequency 4.7GHz, processor temperature 68 °C, motherboard south bridge temperature 63 °C, graphics card core temperature 35 °C, solid state temperature 34 °C. The D40 uses a vertical duct design, the upper water cooling drain, the processor load comes up, the air outlet is more, the temperature of other hardware inside the chassis drops significantly, and the air duct is good.
▼ Single-baked FPU test, processor power consumption of about 190W, large core turbo frequency 4.7GHz, processor temperature 82 °C, MSI's cold ice 240R performance is good, easy to suppress the silent frequency 12700K. In addition, the south bridge temperature of the motherboard is 61 °C, the core temperature of the graphics card is 31 °C, and the solid state temperature is 33 °C. The cold exhaust fan speed continues to increase, and the temperature of other hardware inside the chassis continues to decrease, and the performance of this chassis air duct can be. This is still the case of not adding a chassis fan, if the chassis fan is added, the overall temperature performance will be better.
▼ Run the 3Dmark stress test, TS mode, frame rate stability rate of 98%, OK.
▼ The core temperature of the graphics card is up to 76°C, and the temperature of the processor is 52°C. In the case of high load on the graphics card, there is no active air intake fan in the lower part of the chassis, the temperature of the graphics card core will be higher, in addition, the processor will eat the graphics card exhaust, and the temperature will increase slightly.
6. Summary
The overall performance of the Josper D40 chassis is still very good, a very delicate, compact ATX specification chassis. The appearance of this chassis is very beautiful, with a large area of aluminum alloy material, with double-sided glass side panels, the overall texture is very good. The internal space design of the chassis is very thoughtful, compatible with the ATX specification of the motherboard, the upper part supports 240 water cooling, the power supply is fixed in the front, so that the height and width of the chassis can be fully utilized in the space of the two dimensions, the volume is more compact, and various hardware can be easily put in.
In terms of chassis air ducts, this chassis adopts the design of vertical air ducts, with bottom air inlet and upper air outlet. In the case of not matching the chassis fan and simply fixing the upper part of the 240 water cooling, the performance of the chassis air duct is already quite good. If the chassis fan is fully equipped, the internal duct performance of the chassis should be better. In addition, the chassis fan at the rear of the chassis can be considered not an outgoing fan, but an inlet fan, specifically taking care of the processor, power supply heat dissipation, and may have a better effect.
Don't worry about the details, the back line is also very good to walk. However, if the top of the chassis is installed with 280 water cooling, it is not impossible to install, it will be more compact, you need to pay attention to the installation order, the height of the motherboard heat sink, etc.
