WPF程式設計，Live Charts使用說明（15）——堆積面積

背景：

using System;
using System.Linq;
using System.Windows;
using System.Windows.Controls;
using LiveCharts;
using LiveCharts.Defaults;
using LiveCharts.Wpf;

namespace Wpf.CartesianChart.StackedArea
{
    public partial class StackedAreaExample : UserControl
    {
        public StackedAreaExample()
        {
            InitializeComponent();

            SeriesCollection = new SeriesCollection
            {
                new StackedAreaSeries
                {
                    Title = "Africa",
                    Values = new ChartValues<DateTimePoint>
                    {
                        new DateTimePoint(new DateTime(1950, 1, 1), .228),
                        new DateTimePoint(new DateTime(1960, 1, 1), .285),
                        new DateTimePoint(new DateTime(1970, 1, 1), .366),
                        new DateTimePoint(new DateTime(1980, 1, 1), .478),
                        new DateTimePoint(new DateTime(1990, 1, 1), .629),
                        new DateTimePoint(new DateTime(2000, 1, 1), .808),
                        new DateTimePoint(new DateTime(2010, 1, 1), 1.031),
                        new DateTimePoint(new DateTime(2013, 1, 1), 1.110)
                    },
                    LineSmoothness = 0
                },
                new StackedAreaSeries
                {
                    Title = "N & S America",
                    Values = new ChartValues<DateTimePoint>
                    {
                        new DateTimePoint(new DateTime(1950, 1, 1), .339),
                        new DateTimePoint(new DateTime(1960, 1, 1), .424),
                        new DateTimePoint(new DateTime(1970, 1, 1), .519),
                        new DateTimePoint(new DateTime(1980, 1, 1), .618),
                        new DateTimePoint(new DateTime(1990, 1, 1), .727),
                        new DateTimePoint(new DateTime(2000, 1, 1), .841),
                        new DateTimePoint(new DateTime(2010, 1, 1), .942),
                        new DateTimePoint(new DateTime(2013, 1, 1), .972)
                    },
                    LineSmoothness = 0
                },
                new StackedAreaSeries
                {
                    Title = "Asia",
                    Values = new ChartValues<DateTimePoint>
                    {
                        new DateTimePoint(new DateTime(1950, 1, 1), 1.395),
                        new DateTimePoint(new DateTime(1960, 1, 1), 1.694),
                        new DateTimePoint(new DateTime(1970, 1, 1), 2.128),
                        new DateTimePoint(new DateTime(1980, 1, 1), 2.634),
                        new DateTimePoint(new DateTime(1990, 1, 1), 3.213),
                        new DateTimePoint(new DateTime(2000, 1, 1), 3.717),
                        new DateTimePoint(new DateTime(2010, 1, 1), 4.165),
                        new DateTimePoint(new DateTime(2013, 1, 1), 4.298)
                    },
                    LineSmoothness = 0
                },
                new StackedAreaSeries
                {
                    Title = "Europe",
                    Values = new ChartValues<DateTimePoint>
                    {
                        new DateTimePoint(new DateTime(1950, 1, 1), .549),
                        new DateTimePoint(new DateTime(1960, 1, 1), .605),
                        new DateTimePoint(new DateTime(1970, 1, 1), .657),
                        new DateTimePoint(new DateTime(1980, 1, 1), .694),
                        new DateTimePoint(new DateTime(1990, 1, 1), .723),
                        new DateTimePoint(new DateTime(2000, 1, 1), .729),
                        new DateTimePoint(new DateTime(2010, 1, 1), .740),
                        new DateTimePoint(new DateTime(2013, 1, 1), .742)
                    },
                    LineSmoothness = 0
                }
            };

            XFormatter = val => new DateTime((long) val).ToString("yyyy");
            YFormatter = val => val.ToString("N") + " M";

            DataContext = this;
        }

        public SeriesCollection SeriesCollection { get; set; }
        public Func<double, string> XFormatter { get; set; }
        public Func<double, string> YFormatter { get; set; }

    }
}


前台：

<lvc:CartesianChart Grid.Row="2" Series="{Binding SeriesCollection}"  LegendLocation="Right">
  <lvc:CartesianChart.AxisX>
    <lvc:Axis Title="Year" LabelFormatter="{Binding XFormatter}"></lvc:Axis>
  </lvc:CartesianChart.AxisX>
  <lvc:CartesianChart.AxisY>
    <lvc:Axis Title="Population" LabelFormatter="{Binding YFormatter}"></lvc:Axis>
  </lvc:CartesianChart.AxisY>
</lvc:CartesianChart>
