LVM邏輯卷管理
公司生産環境中使用了LVM邏輯卷管理，是以今天花時間整理一下。
通過LVM技術整合所有的磁盤資源進行分區，然後建立PV實體卷形成一個資源池，再劃分卷組，最後在卷組上建立不同的邏輯卷，繼而初始化邏輯卷，挂載到系統中使用。
LVM對比傳統硬碟存儲的優點
1、 統一管理：整合多個磁盤或分區形成一個資源池
2、 靈活性：可以使用不同磁盤、不同分區來組成一個邏輯卷
3、 可伸縮性：邏輯卷和卷組的容量都可以使用指令來擴充或者縮減，且不會影響破壞原有資料，支援磁盤熱插拔。
4、 支援熱插拔
5、 支援線上資料移動
6、 裝置命名友善
7、 鏡像卷：可以很友善的做資料鏡像
8、 卷快照：把邏輯卷中的資料快照儲存到新的邏輯卷進行備份
邏輯分區與邏輯卷的差別
邏輯卷與邏輯分區不是同一概念，邏輯分區容量大小不能改變；邏輯卷容量大小可以改變（基于實體卷和卷組之上的邏輯卷）；邏輯卷管理器（LVM）可以更輕松的管理磁盤空間（整合的磁盤池）
LVM原理圖
Physical volume (PV實體卷)、Volume group (VG卷組)、Logical volume(LV邏輯卷)，通過圖解更容易讀懂實體磁盤、磁盤分區、實體卷、卷組、邏輯卷之間的關系（個人了解，僅供參考）
測試環境
核心
LVM1版本需要2.4（包括）以後的核心支援；LVM2需要2.6（包括）以後的核心版本支援。
[root@localhost ~]# cat /etc/redhat-release
CentOS Linux release 7.4.1708 (Core)
[root@localhost ~]# uname -r
3.10.0-693.el7.x86_64 新添加兩塊磁盤
[root@localhost ~]# fdisk -l
Disk /dev/sda: 21.5 GB, 21474836480 bytes, 41943040 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk label type: dos
Disk identifier: 0x0000457f
Device Boot Start End Blocks Id System
/dev/sda1 * 2048 2099199 1048576 83 Linux
/dev/sda2 2099200 41943039 19921920 8e Linux LVM
Disk /dev/sdb: 21.5 GB, 21474836480 bytes, 41943040 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk /dev/sdc: 21.5 GB, 21474836480 bytes, 41943040 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk /dev/mapper/centos-root: 18.2 GB, 18249416704 bytes, 35643392 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk /dev/mapper/centos-swap: 2147 MB, 2147483648 bytes, 4194304 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes 磁盤分區
第一塊磁盤
[root@localhost ~]# fdisk /dev/sdb
Command (m for help): n
Partition type:
p primary (0 primary, 0 extended, 4 free)
e extended
Select (default p): p
Partition number (1-4, default 1):
First sector (2048-41943039, default 2048):
Using default value 2048
Last sector, +sectors or +size{K,M,G} (2048-41943039, default 41943039): +10G
Partition 1 of type Linux and of size 10 GiB is set
Command (m for help): n
Partition type:
p primary (1 primary, 0 extended, 3 free)
e extended
Select (default p): p #主分區
Partition number (2-4, default 2):
First sector (20973568-41943039, default 20973568):
Using default value 20973568
Last sector, +sectors or +size{K,M,G} (20973568-41943039, default 41943039):
Using default value 41943039
Partition 2 of type Linux and of size 10 GiB is set
Command (m for help): p #第一塊磁盤劃分兩個主分區
Disk /dev/sdb: 21.5 GB, 21474836480 bytes, 41943040 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk label type: dos
Disk identifier: 0xfba75d9e
Device Boot Start End Blocks Id System
/dev/sdb1 2048 20973567 10485760 83 Linux
/dev/sdb2 20973568 41943039 10484736 83 Linux
Command (m for help): t #做LVM管理，需要修改分區類型為Linux LVM
Partition number (1,2, default 2): 1
Hex code (type L to list all codes): 8e
Changed type of partition 'Linux' to 'Linux LVM'
Command (m for help): t
Partition number (1,2, default 2): 2
Hex code (type L to list all codes): 8e
Changed type of partition 'Linux' to 'Linux LVM'
Command (m for help): p
Disk /dev/sdb: 21.5 GB, 21474836480 bytes, 41943040 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk label type: dos
Disk identifier: 0xfba75d9e
Device Boot Start End Blocks Id System
/dev/sdb1 2048 20973567 10485760 8e Linux LVM
/dev/sdb2 20973568 41943039 10484736 8e Linux LVM
Command (m for help): w #儲存分區資訊
The partition table has been altered!
Calling ioctl() to re-read partition table.
Syncing disks.
告訴核心
[root@localhost ~]# partprobe /dev/sdb #更新核心分區表
[root@localhost ~]# ls -l /dev/sdb*
brw-rw----. 1 root disk 8, 16 Oct 13 11:30 /dev/sdb
brw-rw----. 1 root disk 8, 17 Oct 13 11:30 /dev/sdb1
brw-rw----. 1 root disk 8, 18 Oct 13 11:30 /dev/sdb2
[root@localhost ~]# 第二塊磁盤
建立一個主分區和一個邏輯分區，用來測試擴充分區和邏輯分區是否能夠建立PV實體卷并加入VG卷組，實驗證明，擴充分區是無法建立PV和加入VG，主分區和邏輯分區可以。
[root@localhost ~]# fdisk /dev/sdc
Welcome to fdisk (util-linux 2.23.2).
Changes will remain in memory only, until you decide to write them.
Be careful before using the write command.
Device does not contain a recognized partition table
Building a new DOS disklabel with disk identifier 0x5d61bb7c.
Command (m for help): n
Partition type:
p primary (0 primary, 0 extended, 4 free)
e extended
Select (default p): p #主分區
Partition number (1-4, default 1):
First sector (2048-41943039, default 2048):
Using default value 2048
Last sector, +sectors or +size{K,M,G} (2048-41943039, default 41943039): +10G
Partition 1 of type Linux and of size 10 GiB is set
Command (m for help): n
Partition type:
p primary (1 primary, 0 extended, 3 free)
e extended
Select (default p): e #擴充分區，要建立擴充分區之後，才能建立邏輯分區；擴充分區隻能建立一個，分區表支援建立最多四分主分區，如果想要建立4個以上的分區，必須建立擴充分區，然後建立邏輯分區
Partition number (2-4, default 2):
First sector (20973568-41943039, default 20973568):
Using default value 20973568
Last sector, +sectors or +size{K,M,G} (20973568-41943039, default 41943039):
Using default value 41943039
Partition 2 of type Extended and of size 10 GiB is set
Command (m for help): n
Partition type:
p primary (1 primary, 1 extended, 2 free)
l logical (numbered from 5)
Select (default p): l #建立邏輯分區
Adding logical partition 5
First sector (20975616-41943039, default 20975616):
Using default value 20975616
Last sector, +sectors or +size{K,M,G} (20975616-41943039, default 41943039):
Using default value 41943039
Partition 5 of type Linux and of size 10 GiB is set
Command (m for help): p
Disk /dev/sdc: 21.5 GB, 21474836480 bytes, 41943040 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk label type: dos
Disk identifier: 0x5d61bb7c
Device Boot Start End Blocks Id System
/dev/sdc1 2048 20973567 10485760 83 Linux
/dev/sdc2 20973568 41943039 10484736 5 Extended
/dev/sdc5 20975616 41943039 10483712 83 Linux
Command (m for help): t #修改分區類型
Partition number (1,2,5, default 5): 1
Hex code (type L to list all codes): 8e
Changed type of partition 'Linux' to 'Linux LVM'
Command (m for help): t
Partition number (1,2,5, default 5): 2
Hex code (type L to list all codes): 8e
You cannot change a partition into an extended one or vice versa.
Delete it first.
Type of partition 2 is unchanged: Extended
Command (m for help): t
Partition number (1,2,5, default 5): 5
Hex code (type L to list all codes): 8e
Changed type of partition 'Linux' to 'Linux LVM'
Command (m for help): p
Disk /dev/sdc: 21.5 GB, 21474836480 bytes, 41943040 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk label type: dos
Disk identifier: 0x5d61bb7c
Device Boot Start End Blocks Id System
/dev/sdc1 2048 20973567 10485760 8e Linux LVM
/dev/sdc2 20973568 41943039 10484736 5 Extended
/dev/sdc5 20975616 41943039 10483712 8e Linux LVM
Command (m for help): w #儲存分區表資訊
The partition table has been altered!
Calling ioctl() to re-read partition table.
Syncing disks.
[root@localhost ~]# partprobe /dev/sdc
[root@localhost ~]# ls -l /dev/sdc*
brw-rw----. 1 root disk 8, 32 Oct 13 11:35 /dev/sdc
brw-rw----. 1 root disk 8, 33 Oct 13 11:35 /dev/sdc1
brw-rw----. 1 root disk 8, 34 Oct 13 11:35 /dev/sdc2
brw-rw----. 1 root disk 8, 37 Oct 13 11:35 /dev/sdc5 建立PV、VG、LV
建立PV實體卷
[root@localhost ~]# pvcreate /dev/sdc2 #sdc2是擴充分區，無法做成實體卷PV
Device /dev/sdc2 not found (or ignored by filtering).
[root@localhost ~]# pvcreate /dev/sdb1 #把sdb1做成實體卷PV，也可以用下面的寫法，一次性把所有主分區或邏輯分區做成實體卷PV
Physical volume "/dev/sdb1" successfully created.
[root@localhost ~]# pvcreate /dev/sdb2 /dev/sdc1 /dev/sdc5
Physical volume "/dev/sdb2" successfully created.
Physical volume "/dev/sdc1" successfully created.
Physical volume "/dev/sdc5" successfully created.
[root@localhost ~]# pvdisplay #檢視實體卷詳細資訊
--- Physical volume ---
PV Name /dev/sda2
VG Name centos
PV Size <19.00 GiB / not usable 3.00 MiB
Allocatable yes (but full)
PE Size 4.00 MiB
Total PE 4863
Free PE 0
Allocated PE 4863
PV UUID 610jgI-z9pr-N5H1-R1Qv-jVMh-cMOD-2VKNm5
"/dev/sdb1" is a new physical volume of "10.00 GiB"
--- NEW Physical volume ---
PV Name /dev/sdb1
VG Name
PV Size 10.00 GiB
Allocatable NO
PE Size 0
Total PE 0
Free PE 0
Allocated PE 0
PV UUID l65LfK-FxkO-I8ux-0Lj6-jQB1-ev6d-jl4D8v
"/dev/sdc1" is a new physical volume of "10.00 GiB"
--- NEW Physical volume ---
PV Name /dev/sdc1
VG Name
PV Size 10.00 GiB
Allocatable NO
PE Size 0
Total PE 0
Free PE 0
Allocated PE 0
PV UUID olFzUh-w2jf-sK32-i4lr-oYHP-zWTf-dKmgYw
"/dev/sdc5" is a new physical volume of "<10.00 GiB"
--- NEW Physical volume ---
PV Name /dev/sdc5
VG Name
PV Size <10.00 GiB
Allocatable NO
PE Size 0
Total PE 0
Free PE 0
Allocated PE 0
PV UUID 54wYXO-sN3e-Lyc6-2ZQg-YMkH-6khg-TqbKOA
"/dev/sdb2" is a new physical volume of "<10.00 GiB"
--- NEW Physical volume ---
PV Name /dev/sdb2
VG Name
PV Size <10.00 GiB
Allocatable NO
PE Size 0
Total PE 0
Free PE 0
Allocated PE 0
PV UUID aqkWHa-RIxf-15Y9-mgLw-x82r-thpL-kxzYhc
[root@localhost ~]# pvs #顯示所有的實體卷，大小都是10G（分區的時候配置設定的）
PV VG Fmt Attr PSize PFree
/dev/sda2 centos lvm2 a-- <19.00g 0
/dev/sdb1 lvm2 --- 10.00g 10.00g
/dev/sdb2 lvm2 --- <10.00g <10.00g
/dev/sdc1 lvm2 --- 10.00g 10.00g
/dev/sdc5 lvm2 --- <10.00g <10.00g 建立卷組
[root@localhost ~]# vgcreate VGtest1 /dev/sdb1 /dev/sdc1 #建立卷組1，卷組的PV實體卷，可以是不同磁盤，即整合了所有磁盤分區做成資源池
Volume group "VGtest1" successfully created
[root@localhost ~]# vgcreate VGtest2 /dev/sdb2 /dev/sdc5 #建立卷組2
Volume group "VGtest2" successfully created
[root@localhost ~]# vgs #顯示所有卷組資訊
VG #PV #LV #SN Attr VSize VFree
VGtest1 2 0 0 wz--n- 19.99g 19.99g
VGtest2 2 0 0 wz--n- 19.99g 19.99g
centos 1 2 0 wz--n- <19.00g 0
[root@localhost ~]# vgdisplay #檢視所有卷組的詳細資訊
--- Volume group ---
VG Name centos
System ID
Format lvm2
Metadata Areas 1
Metadata Sequence No 3
VG Access read/write
VG Status resizable
MAX LV 0
Cur LV 2
Open LV 2
Max PV 0
Cur PV 1
Act PV 1
VG Size <19.00 GiB
PE Size 4.00 MiB
Total PE 4863
Alloc PE / Size 4863 / <19.00 GiB
Free PE / Size 0 / 0
VG UUID FjdwU1-IYgt-Q6r2-uGm7-q1de-g0yh-EsGm64
--- Volume group ---
VG Name VGtest1
System ID
Format lvm2
Metadata Areas 2
Metadata Sequence No 1
VG Access read/write
VG Status resizable
MAX LV 0
Cur LV 0
Open LV 0
Max PV 0
Cur PV 2
Act PV 2
VG Size 19.99 GiB
PE Size 4.00 MiB
Total PE 5118
Alloc PE / Size 0 / 0
Free PE / Size 5118 / 19.99 GiB
VG UUID pk62Bc-lRQW-iXim-VUng-PrIk-s9WR-10uctH
--- Volume group ---
VG Name VGtest2
System ID
Format lvm2
Metadata Areas 2
Metadata Sequence No 1
VG Access read/write
VG Status resizable
MAX LV 0
Cur LV 0
Open LV 0
Max PV 0
Cur PV 2
Act PV 2
VG Size 19.99 GiB
PE Size 4.00 MiB
Total PE 5118
Alloc PE / Size 0 / 0
Free PE / Size 5118 / 19.99 GiB
VG UUID XsUyyE-1OSa-Xbno-L0W3-cL3E-XmeH-qb3QWW 建立邏輯卷
[root@localhost ~]# lvcreate -n LVtest1 -L 1G VGtest1 #-n表示建立邏輯卷名，-L表示配置設定邏輯卷的空間大小，VGtest1表示在卷組VGtest1上建立邏輯卷LVtest1
Logical volume "LVtest1" created.
[root@localhost ~]# lvcreate -n LVtest2 -L 1G VGtest2
Logical volume "LVtest2" created.
[root@localhost ~]# lvs #顯示邏輯卷的資訊（大小為1G，上面配置設定的）
LV VG Attr LSize Pool Origin Data% Meta% Move Log Cpy%Sync Convert
LVtest1 VGtest1 -wi-a----- 1.00g
LVtest2 VGtest2 -wi-a----- 1.00g
root centos -wi-ao---- <17.00g
swap centos -wi-ao---- 2.00g
[root@localhost ~]# lvdisplay #顯示邏輯卷的詳細資訊
--- Logical volume ---
LV Path /dev/centos/swap
LV Name swap
VG Name centos
LV UUID gS0ted-R1jU-NKWR-rpFb-quUd-Yu7w-c0VfGz
LV Write Access read/write
LV Creation host, time localhost, 2018-09-14 09:38:10 -0400
LV Status available
# open 2
LV Size 2.00 GiB
Current LE 512
Segments 1
Allocation inherit
Read ahead sectors auto
- currently set to 8192
Block device 253:1
--- Logical volume ---
LV Path /dev/centos/root
LV Name root
VG Name centos
LV UUID LTcnK5-ufCZ-5Cwx-Lpfi-Frgo-NMBm-OEE73C
LV Write Access read/write
LV Creation host, time localhost, 2018-09-14 09:38:10 -0400
LV Status available
# open 1
LV Size <17.00 GiB
Current LE 4351
Segments 1
Allocation inherit
Read ahead sectors auto
- currently set to 8192
Block device 253:0
--- Logical volume ---
LV Path /dev/VGtest1/LVtest1
LV Name LVtest1
VG Name VGtest1
LV UUID PMv1Zv-WtJy-13v4-1GBc-5WaB-mcpk-f7dN22
LV Write Access read/write
LV Creation host, time localhost.localdomain, 2018-10-13 11:48:28 -0400
LV Status available
# open 0
LV Size 1.00 GiB
Current LE 256
Segments 1
Allocation inherit
Read ahead sectors auto
- currently set to 8192
Block device 253:2
--- Logical volume ---
LV Path /dev/VGtest2/LVtest2
LV Name LVtest2
VG Name VGtest2
LV UUID HCk2OB-3iVy-Ryma-rKeH-kIie-NYKr-ZVkiIf
LV Write Access read/write
LV Creation host, time localhost.localdomain, 2018-10-13 11:48:47 -0400
LV Status available
# open 0
LV Size 1.00 GiB
Current LE 256
Segments 1
Allocation inherit
Read ahead sectors auto
- currently set to 8192
Block device 253:3
會建立對應的目錄和檔案
[root@localhost ~]# ls -l /dev/VGtest1/LVtest1
lrwxrwxrwx. 1 root root 7 Oct 13 11:48 /dev/VGtest1/LVtest1 -> ../dm-2
[root@localhost ~]# ls -l /dev/d
disk/ dm-0 dm-1 dm-2 dm-3 dmmidi dri/
[root@localhost ~]# ls -l /dev/dm-2
brw-rw----. 1 root disk 253, 2 Oct 13 11:48 /dev/dm-2 格式化LV邏輯卷
[root@localhost ~]# mke2fs -t ext4 /dev/VGtest1/LVtest1 #實體卷需要格式化之後才能使用，格式化為ext4格式
mke2fs 1.42.9 (28-Dec-2013)
Filesystem label=
OS type: Linux
Block size=4096 (log=2)
Fragment size=4096 (log=2)
Stride=0 blocks, Stripe width=0 blocks
65536 inodes, 262144 blocks
13107 blocks (5.00%) reserved for the super user
First data block=0
Maximum filesystem blocks=268435456
8 block groups
32768 blocks per group, 32768 fragments per group
8192 inodes per group
Superblock backups stored on blocks:
32768, 98304, 163840, 229376
Allocating group tables: done
Writing inode tables: done
Creating journal (8192 blocks): done
Writing superblocks and filesystem accounting information: done
[root@localhost ~]# mkfs.ext4 /dev/VGtest2/LVtest2 #也可以使用這種方式格式化
mke2fs 1.42.9 (28-Dec-2013)
Filesystem label=
OS type: Linux
Block size=4096 (log=2)
Fragment size=4096 (log=2)
Stride=0 blocks, Stripe width=0 blocks
65536 inodes, 262144 blocks
13107 blocks (5.00%) reserved for the super user
First data block=0
Maximum filesystem blocks=268435456
8 block groups
32768 blocks per group, 32768 fragments per group
8192 inodes per group
Superblock backups stored on blocks:
32768, 98304, 163840, 229376
Allocating group tables: done
Writing inode tables: done
Creating journal (8192 blocks): done
Writing superblocks and filesystem accounting information: done 挂載LV邏輯卷
[root@localhost ~]# mkdir /appdata
[root@localhost ~]# mkdir /applog
[root@localhost ~]# mount /dev/VGtest1/LVtest1 /appdata #把LV邏輯卷挂載到實際的目錄
[root@localhost ~]# mount /dev/VGtest2/LVtest2 /applog
[root@localhost ~]# df -h
Filesystem Size Used Avail Use% Mounted on
/dev/mapper/centos-root 17G 1.2G 16G 7% /
devtmpfs 482M 0 482M 0% /dev
tmpfs 493M 0 493M 0% /dev/shm
tmpfs 493M 6.8M 486M 2% /run
tmpfs 493M 0 493M 0% /sys/fs/cgroup
/dev/sda1 1014M 125M 890M 13% /boot
tmpfs 99M 0 99M 0% /run/user/0
/dev/mapper/VGtest1-LVtest1 976M 2.6M 907M 1% /appdata
/dev/mapper/VGtest2-LVtest2 976M 2.6M 907M 1% /applog
[root@localhost ~]# mount |grep VGtest
/dev/mapper/VGtest1-LVtest1 on /appdata type ext4 (rw,relatime,seclabel,data=ordered)
/dev/mapper/VGtest2-LVtest2 on /applog type ext4 (rw,relatime,seclabel,data=ordered)
永久挂載LV邏輯卷
[root@localhost ~]# vim /etc/fstab
#
# /etc/fstab
# Created by anaconda on Fri Sep 14 09:38:12 2018
#
# Accessible filesystems, by reference, are maintained under '/dev/disk'
# See man pages fstab(5), findfs(8), mount(8) and/or blkid(8) for more info
#
/dev/mapper/centos-root / xfs defaults 0 0
UUID=944557a0-3f7c-434d-8202-c960db70b860 /boot xfs defaults 0 0
/dev/mapper/centos-swap swap swap defaults 0 0
/dev/VGtest1/LVtest1 /appdata ext4 defaults 0 0
/dev/VGtest2/LVtest2 /applog ext4 defaults 0 0
~
~
"/etc/fstab" 13L, 617C written
[root@localhost ~]# mount -a #重新加載/etc/fstab檔案 VG卷組擴容
建立一個PV實體卷，然後加入VG即可（fdisk建立分區->修改分區類型Linux LVM->向核心注冊新分區->建立實體卷->把實體卷加入需要擴容的卷組）。
發現卷組pv空間不夠，我們需要擴大卷組空間，現在系統上新增了一塊20G的硬碟/dev/sdc。
[root@localhost ~]# fdisk /dev/sdd #把新添加的磁盤進行分區
Welcome to fdisk (util-linux 2.23.2).
Changes will remain in memory only, until you decide to write them.
Be careful before using the write command.
Device does not contain a recognized partition table
Building a new DOS disklabel with disk identifier 0xc29c0ac3.
Command (m for help): n
Partition type:
p primary (0 primary, 0 extended, 4 free)
e extended
Select (default p): p #主分區
Partition number (1-4, default 1):
First sector (2048-41943039, default 2048):
Using default value 2048
Last sector, +sectors or +size{K,M,G} (2048-41943039, default 41943039): +5G
Partition 1 of type Linux and of size 5 GiB is set
Command (m for help): t #修改分區類型
Selected partition 1
Hex code (type L to list all codes): 8e
Changed type of partition 'Linux' to 'Linux LVM'
Command (m for help): p
Disk /dev/sdd: 21.5 GB, 21474836480 bytes, 41943040 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk label type: dos
Disk identifier: 0xc29c0ac3
Device Boot Start End Blocks Id System
/dev/sdd1 2048 10487807 5242880 8e Linux LVM
Command (m for help): w #儲存分區資訊
The partition table has been altered!
Calling ioctl() to re-read partition table.
Syncing disks.
[root@localhost ~]# partprobe /dev/sdd #更新核心分區表
[root@localhost ~]# pvcreate /dev/sdd1 #建立實體卷PV
Physical volume "/dev/sdd1" successfully created.
[root@localhost ~]# pvs
PV VG Fmt Attr PSize PFree
/dev/sda2 centos lvm2 a-- <19.00g 0
/dev/sdb1 VGtest1 lvm2 a-- <10.00g <9.00g
/dev/sdb2 VGtest2 lvm2 a-- <10.00g <9.00g
/dev/sdc1 VGtest1 lvm2 a-- <10.00g <10.00g
/dev/sdc5 VGtest2 lvm2 a-- <10.00g <10.00g
/dev/sdd1 lvm2 --- 5.00g 5.00g
[root@localhost ~]# vgextend VGtest1 /dev/sdd1 #擴充VG卷組容量，把實體卷加入卷組
Volume group "VGtest1" successfully extended
[root@localhost ~]# vgs
VG #PV #LV #SN Attr VSize VFree
VGtest1 3 1 0 wz--n- <24.99g <23.99g
VGtest2 2 1 0 wz--n- 19.99g 18.99g
centos 1 2 0 wz--n- <19.00g 0
[root@localhost ~]# pvs
PV VG Fmt Attr PSize PFree
/dev/sda2 centos lvm2 a-- <19.00g 0
/dev/sdb1 VGtest1 lvm2 a-- <10.00g <9.00g
/dev/sdb2 VGtest2 lvm2 a-- <10.00g <9.00g
/dev/sdc1 VGtest1 lvm2 a-- <10.00g <10.00g
/dev/sdc5 VGtest2 lvm2 a-- <10.00g <10.00g
/dev/sdd1 VGtest1 lvm2 a-- <5.00g <5.00g LV邏輯卷擴容 (支援線上擴充)
線上将/dev/VGtest/LVtest1 擴充到4G，并且要求資料可以正常通路
[root@localhost ~]# echo "this is a test for LVM" >/appdata/test
[root@localhost ~]# cat /appdata/test #在挂載的邏輯卷裡添加資料，用來測試在邏輯卷擴容是否會破壞原有資料
this is a test for LVM
[root@localhost ~]# lvs
LV VG Attr LSize Pool Origin Data% Meta% Move Log Cpy%Sync Convert
LVtest1 VGtest1 -wi-ao---- 1.00g
LVtest2 VGtest2 -wi-ao---- 1.00g
root centos -wi-ao---- <17.00g
swap centos -wi-ao---- 2.00g
[root@localhost ~]# lvextend -L +2G /dev/VGtest1/LVtest1 #擴容邏輯卷LVtest1，增加2G空間容量（從對應的卷組中劃分空間容量）
Size of logical volume VGtest1/LVtest1 changed from 1.00 GiB (256 extents) to 3.00 GiB (768 extents).
Logical volume VGtest1/LVtest1 successfully resized.
[root@localhost ~]# lvs
LV VG Attr LSize Pool Origin Data% Meta% Move Log Cpy%Sync Convert
LVtest1 VGtest1 -wi-ao---- 3.00g
LVtest2 VGtest2 -wi-ao---- 1.00g
root centos -wi-ao---- <17.00g
swap centos -wi-ao---- 2.00g
[root@localhost ~]# resize2fs /dev/VGtest1/LVtest1 #使用resize2fs指令來進行确認增加容量，前面的步驟隻是初步配置設定，還不能實際使用，需要此步驟來确定實際配置設定使用
resize2fs 1.42.9 (28-Dec-2013)
Filesystem at /dev/VGtest1/LVtest1 is mounted on /appdata; on-line resizing required
old_desc_blocks = 1, new_desc_blocks = 1
The filesystem on /dev/VGtest1/LVtest1 is now 786432 blocks long.
xfs系統确認實際使用的指令
xfs_growfs /dev/VGtest1/LVtest1
檢視挂載目錄的空間容量大小
[root@localhost ~]# df -h|grep VGtest
/dev/mapper/VGtest2-LVtest2 976M 2.6M 907M 1% /applog
/dev/mapper/VGtest1-LVtest1 3.0G 3.1M 2.8G 1% /appdata
資料并沒有受損
[root@localhost ~]# cat /appdata/test
this is a test for LVM [root@localhost ~]# e2fsck -f /dev/VGtest1/LVtest1 #處于挂載狀态的LV邏輯卷無法強制檢查
e2fsck 1.42.9 (28-Dec-2013)
/dev/VGtest1/LVtest1 is mounted.
e2fsck: Cannot continue, aborting.
[root@localhost ~]# umount /dev/VGtest1/LVtest1 #取消邏輯卷挂載
[root@localhost ~]# e2fsck -f /dev/VGtest1/LVtest1 #檢查邏輯卷
e2fsck 1.42.9 (28-Dec-2013)
Pass 1: Checking inodes, blocks, and sizes
Pass 2: Checking directory structure
Pass 3: Checking directory connectivity
Pass 4: Checking reference counts
Pass 5: Checking group summary information
/dev/VGtest1/LVtest1: 12/196608 files (0.0% non-contiguous), 21309/786432 blocks
[root@localhost ~]# resize2fs /dev/VGtest1/LVtest1 1G #首先需要确定縮減邏輯卷到多大空間容量，-1G表示縮減1G大小，1G表示縮減至1G（原來空間是3G）
resize2fs 1.42.9 (28-Dec-2013)
Resizing the filesystem on /dev/VGtest1/LVtest1 to 262144 (4k) blocks.
The filesystem on /dev/VGtest1/LVtest1 is now 262144 blocks long.
[root@localhost ~]# lvreduce -L 1G /dev/VGtest1/LVtest1 #再進行邏輯卷LV容量縮減
WARNING: Reducing active logical volume to 1.00 GiB.
THIS MAY DESTROY YOUR DATA (filesystem etc.)
Do you really want to reduce VGtest1/LVtest1? [y/n]: y
Size of logical volume VGtest1/LVtest1 changed from 3.00 GiB (768 extents) to 1.00 GiB (256 extents).
Logical volume VGtest1/LVtest1 successfully resized.
[root@localhost ~]# mount /dev/VGtest1/LVtest1 /appdata #重新挂載邏輯卷
[root@localhost ~]# lvs
LV VG Attr LSize Pool Origin Data% Meta% Move Log Cpy%Sync Convert
LVtest1 VGtest1 -wi-ao---- 1.00g
LVtest2 VGtest2 -wi-ao---- 500.00m
root centos -wi-ao---- <17.00g
swap centos -wi-ao---- 2.00g
[root@localhost ~]# df -h|grep VGtest
/dev/mapper/VGtest2-LVtest2 460M 1.6M 424M 1% /applog
/dev/mapper/VGtest1-LVtest1 976M 2.6M 914M 1% /appdata
[root@localhost ~]# cat /appdata/test
this is a test for LVM [root@localhost appdata]# touch stu{0..100}
[root@localhost appdata]# pvs
PV VG Fmt Attr PSize PFree
/dev/sda2 centos lvm2 a-- <19.00g 0
/dev/sdb1 VGtest1 lvm2 a-- <10.00g <9.00g
/dev/sdb2 VGtest2 lvm2 a-- <10.00g <9.51g
/dev/sdc1 VGtest1 lvm2 a-- <10.00g <10.00g
/dev/sdc5 VGtest2 lvm2 a-- <10.00g <10.00g
/dev/sdd1 VGtest1 lvm2 a-- <5.00g <5.00g
[root@localhost appdata]# pvmove /dev/sdb1 #把sdb1磁盤分區的資料轉移到其它磁盤上
/dev/sdb1: Moved: 6.64%
/dev/sdb1: Moved: 100.00%
[root@localhost appdata]# vgreduce VGtest1 /dev/sdb1 #把分區sdb1從VG卷組中移除
Removed "/dev/sdb1" from volume group "VGtest1"
[root@localhost appdata]# pvremove /dev/sdb1 #把sdb1分區從PV實體卷中釋放出來
Labels on physical volume "/dev/sdb1" successfully wiped.
#如果磁盤劃分了多個分區，做成多個實體卷加入了卷組，那麼可以能重複以上步驟，把所有的空間都從卷組和實體卷中釋放，然後可以拿走這塊磁盤做它用
實作快照，進行備份還原
在/mnt/lvm目錄上，我們将原始的目錄檔案進行快照，然後将/LVtets1目錄中的内容清空，并進行還原
[root@localhost ~]# lvs
LV VG Attr LSize Pool Origin Data% Meta% Move Log Cpy%Sync Convert
LVtest1 VGtest1 -wi-ao---- 1.00g
LVtest2 VGtest2 -wi-ao---- 500.00m
root centos -wi-ao---- <17.00g
swap centos -wi-ao---- 2.00g
[root@localhost ~]# cat /appdata/test
this is a test for LVM
[root@localhost ~]# df -h|grep VGtest
/dev/mapper/VGtest2-LVtest2 460M 1.6M 424M 1% /applog
/dev/mapper/VGtest1-LVtest1 976M 2.6M 914M 1% /appdata
[root@localhost ~]# lvcreate -L 20M -n appdatabackup -s -p r /dev/VGtest1/LVtest1 #利用LVtest1邏輯卷，快照形成一個備份的實體卷appdatabackup（邏輯卷快照功能）
Using default stripesize 64.00 KiB.
Logical volume "appdatabackup" created.
[root@localhost ~]# lvs
LV VG Attr LSize Pool Origin Data% Meta% Move Log Cpy%Sync Convert
LVtest1 VGtest1 owi-aos--- 1.00g
appdatabackup VGtest1 sri-a-s--- 20.00m LVtest1 0.06
LVtest2 VGtest2 -wi-ao---- 500.00m
root centos -wi-ao---- <17.00g
swap centos -wi-ao---- 2.00g
[root@localhost ~]# mkdir /tmp/backup
[root@localhost ~]# mount /dev/VGtest1/appdatabackup /tmp/backup #把快照的邏輯卷挂載到目錄上
mount: /dev/mapper/VGtest1-appdatabackup is write-protected, mounting read-only
[root@localhost ~]# cat /tmp/backup/test
this is a test for LVM
[root@localhost ~]# ls -l /appdata/test
-rw-r--r--. 1 root root 23 Oct 13 12:33 /appdata/test
[root@localhost ~]# ls -l /tmp/backup/test
-rw-r--r--. 1 root root 23 Oct 13 12:33 /tmp/backup/test
[root@localhost ~]# rm -rf /appdata/test #删除LVtest1邏輯卷的資料
[root@localhost ~]# ls -l /appdata/test
ls: cannot access /appdata/test: No such file or directory
[root@localhost ~]# cp /tmp/backup/test /appdata/ #從快照中恢複資料到邏輯卷LVtest1上
[root@localhost ~]# ls -l /appdata/test
-rw-r--r--. 1 root root 23 Oct 13 13:06 /appdata/test
[root@localhost ~]# df -h|grep VGtest
/dev/mapper/VGtest2-LVtest2 460M 1.6M 424M 1% /applog
/dev/mapper/VGtest1-LVtest1 976M 2.6M 914M 1% /appdata
