PostgreSQL Oracle 相容性之 - nested table

标簽

PostgreSQL , Oracle , 相容性 , nested table

https://github.com/digoal/blog/blob/master/201901/20190113_01.md#%E8%83%8C%E6%99%AF 背景

Oracle nested table功能介紹如下

http://www.orafaq.com/wiki/NESTED_TABLE

NESTED TABLE is an Oracle data type used to support columns containing multivalued attributes, in this case, columns that can hold an entire sub-table.

Create a table with NESTED TABLE column:

CREATE OR REPLACE TYPE my_tab_t AS TABLE OF VARCHAR2(30);
/


CREATE TABLE nested_table (id NUMBER, col1 my_tab_t)
       NESTED TABLE col1 STORE AS col1_tab;


Insert data into table:

INSERT INTO nested_table VALUES (1, my_tab_t('A'));
INSERT INTO nested_table VALUES (2, my_tab_t('B', 'C'));
INSERT INTO nested_table VALUES (3, my_tab_t('D', 'E', 'F'));
COMMIT;


Select from nested table:

SQL> SELECT * FROM nested_table;
        ID COL1
---------- ------------------------
         1 MY_TAB_T('A')
         2 MY_TAB_T('B', 'C')
         3 MY_TAB_T('D', 'E', 'F')


Unnesting the subtable:

SQL> SELECT id, COLUMN_VALUE FROM nested_table t1, TABLE(t1.col1) t2;
        ID COLUMN_VALUE
---------- ------------------------
         1 A
         2 B
         2 C
         3 D
         3 E
         3 F
6 rows selected.


https://github.com/digoal/blog/blob/master/201901/20190113_01.md#postgresql-nested-table%E5%85%BC%E5%AE%B9---array-complex-type PostgreSQL nested table相容 - array, complex type

PostgreSQL 使用數組+複合類型，實作同樣場景需求。

1、建立複合類型(如果系統中曾經已經建立了這個類型，或者曾經已經建立過一個即将使用的TABLE，則不需要再次建立)

postgres=# create type thisisnesttable1 as (c1 int, c2 int, c3 text, c4 timestamp);
CREATE TYPE

or

create table nesttablename (...);  -- 隐含建立composite type


2、建立nested table (thisisnesttable1作為hello表的nested table)

postgres=# create table hello (id int, info text, nst thisisnesttable1[]);
CREATE TABLE


3、插入資料（多行以數組存入，一個nested table的最大限制1GB(即PostgreSQL varying type的存儲上限)）

postgres=# insert into hello values (1,'test',array['(1,2,"abcde","2018-01-01 12:00:00")'::thisisnesttable1,  '(2,3,"abcde123","2018-01-01 12:00:00")'::thisisnesttable1]);
INSERT 0 1

或使用row構造法

insert into hello values (
  1,
  'test',
  (array
    [
      row(1,2,'hello',now()),
      row(1,3,'hello',now())
    ]
  )::thisisnesttable1[]
);


https://www.postgresql.org/docs/11/sql-expressions.html#SQL-SYNTAX-ROW-CONSTRUCTORS

4、查詢

postgres=# select * from hello ;
 id | info |                                       nst
----+------+----------------------------------------------------------------------------------
  1 | test | {"(1,2,abcde,\"2018-01-01 12:00:00\")","(2,3,abcde123,\"2018-01-01 12:00:00\")"}
(1 row)


5、使用unnest可以解開nested table的内容

postgres=# select id,info,(unnest(nst)).* from hello ;
 id | info | c1 | c2 |    c3    |         c4
----+------+----+----+----------+---------------------
  1 | test |  1 |  2 | abcde    | 2018-01-01 12:00:00
  1 | test |  2 |  3 | abcde123 | 2018-01-01 12:00:00
(2 rows)

postgres=# select id,info,(unnest(nst)).c1 from hello ;
 id | info | c1
----+------+----
  1 | test |  1
  1 | test |  2
(2 rows)
