CentOS7.2下一鍵安裝Openstack

CentOS7.2下一鍵安裝Openstack

系統環境:

Oracle VirtualBox 4.38

CentOS-7.2-x86_64-bin-DVD1.iso

安裝前需要修改 /etc/hosts檔案,添加 127.0.0.1 dev-100 (dev-100為目前機器名)

否則會報如下錯誤:

Could not start Service[rabbitmq-server]: Execution of '/sbin/service rabbitmq-server start' returned 1: Starting rabbitmq-server: FAILED - check /var/log/rabbitmq/startup_{log, _err}

CentOS7.2下一鍵安裝Openstack

安裝步驟:

[root@dev-100 openstack]# sudo yum install -y http://rdo.fedorapeople.org/rdo-release.rpm

[root@dev-100 openstack]# sudo yum install -y openstack-packstack

[root@dev-100 openstack]# packstack --allinone

Welcome to Installer setup utility

Installing:

Clean Up [ DONE ]

Setting up ssh keys [ DONE ]

Discovering hosts' details [ DONE ]

Adding pre install manifest entries [ DONE ]

Preparing servers [ DONE ]

Adding AMQP manifest entries [ DONE ]

Adding MySQL manifest entries [ DONE ]

Adding Keystone manifest entries [ DONE ]

Adding Glance Keystone manifest entries [ DONE ]

Adding Glance manifest entries [ DONE ]

Adding Cinder Keystone manifest entries [ DONE ]

Adding Cinder manifest entries [ DONE ]

Checking if the Cinder server has a cinder-volumes vg[ DONE ]

Adding Nova API manifest entries [ DONE ]

Adding Nova Keystone manifest entries [ DONE ]

Adding Nova Cert manifest entries [ DONE ]

Adding Nova Conductor manifest entries [ DONE ]

Creating ssh keys for Nova migration [ DONE ]

Gathering ssh host keys for Nova migration [ DONE ]

Adding Nova Compute manifest entries [ DONE ]

Adding Nova Scheduler manifest entries [ DONE ]

Adding Nova VNC Proxy manifest entries [ DONE ]

Adding Openstack Network-related Nova manifest entries[ DONE ]

Adding Nova Common manifest entries [ DONE ]

Adding Neutron API manifest entries [ DONE ]

Adding Neutron Keystone manifest entries [ DONE ]

Adding Neutron L3 manifest entries [ DONE ]

Adding Neutron L2 Agent manifest entries [ DONE ]

Adding Neutron DHCP Agent manifest entries [ DONE ]

Adding Neutron LBaaS Agent manifest entries [ DONE ]

Adding Neutron Metering Agent manifest entries [ DONE ]

Adding Neutron Metadata Agent manifest entries [ DONE ]

Checking if NetworkManager is enabled and running [ DONE ]

Adding OpenStack Client manifest entries [ DONE ]

Adding Horizon manifest entries [ DONE ]

Adding Swift Keystone manifest entries [ DONE ]

Adding Swift builder manifest entries [ DONE ]

Adding Swift proxy manifest entries [ DONE ]

Adding Swift storage manifest entries [ DONE ]

Adding Swift common manifest entries [ DONE ]

Adding Provisioning Demo manifest entries [ DONE ]

Adding MongoDB manifest entries [ DONE ]

Adding Ceilometer manifest entries [ DONE ]

Adding Ceilometer Keystone manifest entries [ DONE ]

Adding Nagios server manifest entries [ DONE ]

Adding Nagios host manifest entries [ DONE ]

Adding post install manifest entries [ DONE ]

Installing Dependencies [ DONE ]

Copying Puppet modules and manifests [ DONE ]

Applying 192.168.1.105_prescript.pp

192.168.1.105_prescript.pp: [ DONE ]

Applying 192.168.1.105_amqp.pp

Applying 192.168.1.105_mysql.pp

192.168.1.105_amqp.pp: [ DONE ]

192.168.1.105_mysql.pp: [ DONE ]

Applying 192.168.1.105_keystone.pp

Applying 192.168.1.105_glance.pp

Applying 192.168.1.105_cinder.pp

192.168.1.105_keystone.pp: [ DONE ]

192.168.1.105_glance.pp: [ DONE ]

192.168.1.105_cinder.pp: [ DONE ]

Applying 192.168.1.105_api_nova.pp

192.168.1.105_api_nova.pp: [ DONE ]

Applying 192.168.1.105_nova.pp

192.168.1.105_nova.pp: [ DONE ]

Applying 192.168.1.105_neutron.pp

192.168.1.105_neutron.pp: [ DONE ]

Applying 192.168.1.105_neutron_fwaas.pp

Applying 192.168.1.105_osclient.pp

Applying 192.168.1.105_horizon.pp

192.168.1.105_neutron_fwaas.pp: [ DONE ]

192.168.1.105_osclient.pp: [ DONE ]

192.168.1.105_horizon.pp: [ DONE ]

Applying 192.168.1.105_ring_swift.pp

192.168.1.105_ring_swift.pp: [ DONE ]

Applying 192.168.1.105_swift.pp

Applying 192.168.1.105_provision_demo.pp

192.168.1.105_swift.pp: [ DONE ]

192.168.1.105_provision_demo.pp: [ DONE ]

Applying 192.168.1.105_mongodb.pp

192.168.1.105_mongodb.pp: [ DONE ]

Applying 192.168.1.105_ceilometer.pp

Applying 192.168.1.105_nagios.pp

Applying 192.168.1.105_nagios_nrpe.pp

192.168.1.105_ceilometer.pp: [ DONE ]

192.168.1.105_nagios.pp: [ DONE ]

192.168.1.105_nagios_nrpe.pp: [ DONE ]

Applying 192.168.1.105_postscript.pp

192.168.1.105_postscript.pp: [ DONE ]

Applying Puppet manifests [ DONE ]

Finalizing [ DONE ]

**** Installation completed successfully ******

Additional information:

* A new answerfile was created in: /root/packstack-answers-20140920-225753.txt

* Time synchronization installation was skipped. Please note that unsynchronized time on server instances might be problem for some OpenStack components.

* Did not create a cinder volume group, one already existed

* File /root/keystonerc_admin has been created on OpenStack client host 192.168.1.105. To use the command line tools you need to source the file.

* To access the OpenStack Dashboard browse to http://192.168.1.105/dashboard .

Please, find your login credentials stored in the keystonerc_admin in your home directory.

* To use Nagios, browse to http://192.168.1.105/nagios username: nagiosadmin, password: 784f5aec5c1f4ca9

* The installation log file is available at: /var/tmp/packstack/20140920-225753-P5aOiP/openstack-setup.log

* The generated manifests are available at: /var/tmp/packstack/20140920-225753-P5aOiP/manifests

CentOS7.2下一鍵安裝Openstack

如上面内容所示,安裝成功後,提示通路位址及登入賬戶資訊所存儲位置( /root/keystonerc_admin )

通過浏覽器通路 http://192.168.1.105/dashboard 登入後截圖如下:

CentOS7.2下一鍵安裝Openstack
